Page 4: Welcome
We proudly offer the best, most innovative broadband gateways available. Learn more at www.SmartRG.com. Purpose & Scope This Gateway User Manual provides SmartRG customers with installation, configuration and monitoring information for the SR655ac gateway. Intended Audience The information in this document is intended for Network Architects, NOC Administrators, Field Service Technicians and other networking professionals responsible for deploying and managing broadband access networks.
Page 5: Getting Familiar With Your Gateway
Getting Familiar with your Gateway This section contains a quick description of the gateway's lights, ports, and buttons to help you get familiar with the SR655ac model. LED Status Indicators The indicator lights (LEDs) on the front of the SR655ac gateway can help you understand the state of your gateway.
Page 6: Connections
Connections Below is an illustration of the connectors located on the back of the SR655ac gateway. PHONE 1 LAN 1-4 PHONE 2 RESET On/Off RJ11 USB Data Card / LTE RJ45 The ports depicted above, and the buttons and ports located on the left side of the gateway, are described below.
Page 7: External Buttons
Wi-Fi radio on and off or reset the gateway. These controls are described below. 2.4GHz and 5GHz Buttons Note: On early production units of the SR655ac gateway, these buttons are labeled WiFi (instead of 2.4 GHz) and WPS (instead of 5 GHz).
Page 8: Installing Your Sr655Ac Gateway
Installing your SR655ac Gateway 1. Locate the splitter cable that is included with your SmartRG gateway. It has three parts. 2. Connect the splitter as follows: a. Connect the DSL port of the gateway and the Modem port of the splitter with a telephone cable b.
Page 9: Logging In To Your Gateway's Ui
Logging in to your Gateway's UI To configure the SmartRG SR655ac gateway's settings, access the gateway's embedded UI. 1. Open a Web browser on your computer. 2. In the address field, enter http://192.168.1.1 (the default IP address of the DSL gateway). The login page appears.
Page 10: Device Info
Device Info In this section, you can view data about your gateway and network, and configure DHCP, ARP, and WAN interfaces. Summary On this page, you can view device such as the board ID, software and voice service version, and information about your WAN connection such as the upstream rate and the LAN address.
Page 11: Wan
The WAN status screen provides a high level overview of the connection between your Internet Service Provider and your gateway device. The WAN interface can physically be DSL or Ethernet and supports a number of Layer 2 and later configuration options covered later in this document.
Page 12: Statistics
Statistics In this section, you can view network interface information for LAN, WAN Service, xTM and DSL. Data is updated at 15-minute intervals. On this page, you can view the received and transmitted bytes, packets, errors and drops for each LAN interface configured on your gateway.
Page 13: Xtm
The fields on this page are defined below. Field Name Description Interface Available WAN interfaces. Description The service description. Options are pppoe, ipoe, and b, followed by the identifier for each service. Received & Transmitted columns Bytes The total number of packets in bytes. Pkts The total quantity of packets.
Page 14: Xdsl
Field Name Description In Packets Total quantity of received Packets. Out Packets Total quantity of transmitted Packets. In OAM Cells Total quantity of received OAM Cells. Out OAM Cells Total quantity of transmitted OAM Cells. In ASM Cells Total quantity of received ASM Cells. Out ASM Cells Total quantity of transmitted ASM Cells.
Page 15 1. In the left navigation menu, click Device Info > Statistics > xDSL. The following page appears. 2. In the Bonding Line Selection field, select the line for which you want to view statistics or to run an xDSL Bit Error Rate (BER) test that determines the quality of the xDSL connection.
Page 16 The fields on this page are defined below. Field Name Description Synchronized Time Time when the last synchronization was performed. Number of Number of synchronizations performed. Synchronizations Mode xDSL mode that the modem has trained under, such as ADSL2+, G.DMT, etc. Traffic Type Connection type.
Page 17 Field Name Description S (ratio of FEC over PMD Ratio of FEC over PMD Data Frame length. Data Frame length) L (# of bits in PMD Data Number of bits from the latency path included per PMD. Frame) D (interleaver depth) Interleaving depth in the current latency path.
Page 18 Field Name Description Total number of Un-Aavailable Seconds. Total UAS This is a count of 1-second intervals for which the xDSL line is unavailable. The xDSL line becomes unavailable at the onset of 10 contiguous SESs (included in the unavailable time). Once unavailable, the xDSL line becomes available at the onset of 10 contiguous seconds with no SESs (excluded from unavailable time).
Page 19: Route
3. When the test completes, a success dialog box appears. Note: If the BER reaches e-5, you cannot access the Internet. Route On this page, you can view the LAN and WAN route table information configured in your gateway for both IPv4 and IPv6 implementation.
Page 20: Arp
The fields on this page are defined below. Field Name Description Destination Destination IP addresses. Next Hop (For IPv6 only) Identifies the next server in the IPv6 path, if any. Gateway Gateway IP address. Subnet Mask Subnet Masks. Flag Status of the flags. Metric Number of hops to reach the default gateway.
Page 21: Dhcp
The fields on this page are defined below. Field Name Description IP address IP address of the host. Flags Each entry in the ARP cache is marked with a status flag. Options are Complete, Permanent, and Published. MAC Address MAC address of the host. Device System level interface by which the host is connected.
Page 22: Cpu & Memory
CPU & Memory On this page, you can view the CPU and memory data for the gateway. In the left navigation bar, click Device Info > CPU & Memory. The following page appears, showing the current usage and history. The information refreshes automatically. SMARTRG INC.
Page 23: Advanced Setup
Advanced Setup In this section, you can configure network interfaces, UPnP, quality of service, and other features. Layer2 Interface In this section, you can configure the network interfaces for your gateway. ATM Interface On this page, you can configure Asynchronous Transfer Mode / Permanent Virtual Conduit (ATM/PVC) settings for your gateway. You can customize latency options, link type, encapsulation mode and more.
Page 24 2. Modify the settings as needed, using the information in the table below. 3. Click Apply/Save to commit your changes. The new interface appears on the DSL ATM Interface Configuration page. 4. To remove an interface, click the Remove checkbox next to it and then click the Remove button.
Page 25 Field Name Description Enter a Virtual Channel Identifier. A VCI is a 16-bit identifier for a unique channel. Options are 32-65535. The default is 35. Note: 1-31 are reserved for known protocols. Select DSL Latency Select the level of DSL latency. Options are: Path0 (Fast): No error correction and can provide lower latency on error-free lines.
Page 26: Ptm Interface
Field Name Description Select Scheduler Select the algorithm used to schedule queue behavior. VC scheduling is different than scheduling done for for Queues of Equal default queues. Options are: Precedence as the Weighted Round Robin: Packets are accessed in a round robin style and classes can be Default Queue assigned.
Page 27 2. Modify the settings as desired, using the information in the table below. 3. Click Apply/Save to commit your changes. The new interface appears on the PTM Configuration page. 4. To remove an interface, click the Remove checkbox next to it and then click the Remove button.
Page 28: Eth Interface
Field Name Description Default Queue Weight Enter the default weight of the specified queue. Options are 1-63. The default is 1. Default Queue Precedence Enter the precedence of the specified group. The lower the value, the higher the priority. Options are 1-8.
Page 29 1. In the left navigation, click Advanced Setup > Service. The following page appears, showing the services already configured. 2. To add a service, click Add. The following page appears. 3. Modify the settings as desired, using the information in the topics listed below: "PPP over Ethernet WAN Service"...
Page 30: Ppp Over Ethernet Wan Service
PPP over Ethernet WAN Service There are several parts to configuring a PPP over Ethernet (PPPoE) WAN service. You will progress through several pages to complete the configuration. Note: You can configure 7 services. If 7 services are configured, you must remove 1 of the services before configuring a new one. 1.
Page 31 3. Click Next. The following page appears. 4. In the WAN Service Type field, accept the default of PPP over Ethernet (PPPoE). 5. (Optional) Modify the other fields, using the information in the following table. Field Name Description Enter Service (Optional) Enter a name to describe this configuration.
Page 32 Field Name Description Network Protocol Different scheduling priorities can be applied to statistically multiplexed data flows. Since Selection each data flow has its own queue, an ill-behaved flow (which has sent larger packets or more packets per second than the others) will only punish itself and not other sessions. Options are IPv4 Only, IPv4&IPv6 (Dual Stack), and IPv6 Only.
Page 34 7. Modify the fields as needed, using the information in the table provided below. Field Name Description PPP Username Enter the username required for authentication to the PPP server. PPP Password Enter the password required for authentication to the PPP server. PPPoE Service Name (Optional) Enter a description for this service.
Page 35 Field Name Description Dial on Demand Click to enable dialing on-demand. The Inactivity Timeout (minutes) field appears. Enter the of minutes before a session is timed out. Options are 1 - 4320. The default is zero (0). When this option is enabled, connection automatically starts when there is outbound traffic to the Internet.
Page 36 9. Click the arrows to move your selections from left to right or from right to left. 10. (Optional) For IPv6 environments, in the Selected WAN Interface field, select the preferred WAN interface for the default IPv6 gateway. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 37 11. Click Next. The following page appears where you will select DNS Server settings. 12. Do one of the following to configure the DNS: Select the DNS server interface: Select interface entries and click the arrows to move the entries right or left.
Page 38: Ip Over Ethernet Wan Service
Define a static IPv6 DNS IP address: Click Use the following Static IPv6 DNS address and enter the DNS server IP addresses. 13. Click Next. The summary page appears indicating that your PPPoE WAN setup is complete. 14. Review the summary and either click Apply/Save to commit your changes or click Back...
Page 39 1. In the left navigation bar, click Advanced Setup > WAN Service and then click Add. The following page appears. 2. Select an ATM interface to use for the WAN service and click Next. The following page appears. 3. Select IP over Ethernet.
Page 40 4. Modify the other fields as needed, using the information in the following table. Field Name Description Enter Service (Optional) Enter a name to describe this configuration. Description Enter 802.1P Options are 0 - 7. The default is -1 (disabled). Priority For tagged service, enter values in this field and the 802.1Q VLAN ID...
Page 41 5. Click Next. The following page appears. 6. Enter the relevant WAN IP Settings, using the information provided in the table below. The fields on this page are defined below. Field Name Description Obtain an IP address This option is selected by default. DHCP is enabled in MER mode. Click to prevent automatically the ISP automatically assigning the WAN IP to the gateway.
Page 42 Field Name Description Option 58 Renewal Time Enter the number of hours before the DHCP client begins to renew its address lease with the DHCP server. Option 59 Rebinding Time Enter the number of hours before the DHCP client enters the rebinding state if it has not renewed its current address lease with the DHCP server.
Page 43 Field Name Description Use the following Static IPv6 Select this option to manually declare the v6 Static IP information provided by your address ISP. WAN IPv6 Address/Prefix (Available only when Static IPv6 address is selected) If entering a static IP Length address, enter the IP address / prefix length.
Page 44 computers on your Local Area Network (LAN). If you do not want to enable NAT (atypical) and wish the user of this gateway to access the Internet normally, you need to add a route on the uplink equipment. Failure to do so will cause access to the Internet to fail.
Page 45 9. Click Next. The following page appears. 10. Select a WAN interface to act as the system default gateway or accept the default interface. 11. (Optional) For IPv6 environments, in the Selected WAN Interface field, select the preferred WAN interface for the default IPv6 gateway.
Page 47: Bridging
14. Click Next. The following page appears. 15. Review the IPoE settings. You can modify the settings by clicking the Back button. 16. Click Apply/Save to save and apply the settings. Bridging Before you can configure a bridge WAN service, you must create the related ATM interface. SMARTRG INC.
Page 48 1. In the left navigation bar, click Advanced Setup > WAN Service and then click Add. The following page appears. 2. Select the interface for the WAN service and then click Next. The following page appears. 3. Select Bridging. Multicast source fields appear. SMARTRG INC.
Page 49 4. Modify the other fields as needed, using the information in the following table. Field Name Description Allow as IGMP Multicast Select to enable this service to act as an IGMP multicast source. Source Allow as MLD Multicast Select to enable this service to act as an MLD multicast source. Source Enter Service (Optional) Enter a different name to describe this configuration.
Page 50: Usb Mobile Service
6. Review the summary and either click Apply/Save to commit your changes or click Back to step through the pages in reverse order to make any necessary alterations. USB Mobile Service On this page, you can configure a USB Mobile interface for your gateway. A WWAN (Wireless WAN) card must be connected to a USB port on your gateway and you can only configure one connection at a time.
Page 51 b. Click Add. The following page appears. c. Fill in the fields, using the information provided in the table below. You can also click the Auto Setting button to automatically configure the 3G connection. Field Name Description Support NDIS This option is enabled by default. It enables the USB modem for accessing the Internet via the 3G network card.
Page 52 Field Name Description Dial Number Enter the dial number provided by your 3G ISP. Net Select Select an available 3G network. Options are EVDO, WCDMA, CDMA2000, TD- SCDMA, GSM, LTE, and AUTO. The default is AUTO. Dial on demand Select to enable dial on demand feature. If the gateway does not detect data flow continuously within the designated time limit, the gateway automatically stops the 3G connection.
Page 53 6. To edit a connection: a. Click the button in the Edit column. The setup page for the connection appears. b. Modify the fields as necessary, using the information in the table below. You can also click Auto Setting to use the default configuration. c.
Page 54: Vpn
In this section, you can configure tunneling protocols (L2TP or PPTP clients) for your network. The settings are usually specific to a customer's ISP. L2TP Client Configuration On this page, you can configure the L2TP (Layer 2 Tunneling Protocol) client. 1. In the left navigation menu, click Advanced Setup >...
Page 55 3. Click Next. The following page appears. 4. Select the default gateway by selecting interface entries and clicking the arrows to move the entries right or left. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 56 5. Click Next. The following page appears. 6. Do one of the following to configure the DNS server: Select the DNS server interface by selecting interface entries and clicking the arrows to move the entries right or left. Click Use the following Static DNS IP address and enter the DNS server IP addresses.
Page 57: Pptp Client
7. Click Next. The summary page appears. 8. Click Apply / Save to implement your settings. PPTP Client On this page, you can configure the PPTP (Point-to-Point Tunneling Protocol) client. 1. In the left navigation menu, click Advanced Setup > >...
Page 58 2. Fill in the fields, using the information in the table below. The Description, Interface, and PPTP Server IP/Domain fields are required. Field Name Description Description Enter a useful description of this configuration. WAN Interface Select the WAN interface for this client. PPTP Server IP/Domain Enter the IP address of the PPTP server.
Page 59 5. Click Next. The following page appears. 6. Do one of the following to configure the DNS server: Select the DNS server interface by selecting interface entries and clicking the arrows to move the entries right or left. Click Use the following Static DNS IP address and enter the DNS server IP addresses.
Page 60: Ethernet Mode
7. Click Next. The summary page appears. 8. Click Apply / Save to implement your settings. Ethernet Mode On this page, you can configure the Ethernet speed for your gateway. 1. In the left navigation menu, click Advanced Setup > Ethernet Mode.
Page 61: Lan
Options are Auto, 100 Full, 100 Half, 10 Full, and 10 Half. The default is Auto. 3. Click Apply/Save to apply your changes. In this section, you can configure an IP address for the DSL gateway, enable IGMP snooping, enable or disable the DHCP server, edit the DHCP options, configure the DHCP advanced setup, and set the binding between a MAC address and an IP address.
Page 62 2. (Optional) In the GroupName field, select the interface group for this configuration. If there are no groupings defined, the only option is Default. 3. Modify the other fields using the information in the following table. The default configuration settings work for most scenarios.
Page 63 Field Description Enable IGMP Snooping This option is enabled by default. Options are Standard Mode and Blocking Mode. The default is Blocking Mode. To disable this option, clear the check box. Enable LGMP LAN to LAN This option is disabled by default. To enable this option, select Enable. Multicast Enable LAN side firewall Click to enable the LAN-side firewall.
Page 64: Ipv6 Autoconfig
5. To add addresses to the Static IP Lease List: a. Click Add Entries below the MAC Address field. The DHCP Static IP Lease page appears. b. Enter the MAC address of the LAN host. c. Enter the static IP address that is reserved for the host. d.
Page 65 1. In the left navigation bar, click Advanced Setup > > IPv6 Autoconfig . The following page appears. 2. To enable advertisement of the ULA prefix, click Enable ULA Prefix Advertisement. Additional fields appear. 3. Modify these and the other fields as needed, using the information in the table below. 4.
Page 66 Field Name Description Enable ULA Prefix Check this option to enable unique local address (ULA) advertisement on the LAN. Options are Randomly Advertisement Generate and Statically Configure. The default is Randomly Generate which enables the gateway to generate a random IPv6 prefix. If you select Statically Configure, additional fields appear.
Page 67: Local Vlan Setting
Field Name Description Enable Relay Click to enable the relay function. Additional fields appear. Do the following: 1. Enter the DHCPv6 Server IP Address. 2. Select a interface. The default is Default. 3. Enter a limit.The default is zero (0). Local VLAN Setting On this page, you can select a LAN port and enable VLAN mode on it.
Page 68: Nat
In this section, you can configure the NAT (Network Address Translation) settings. Virtual Servers Firewall can prevent unexpected traffic on the Internet from your host on the LAN. The virtual server can create a channel that can pass through the firewall. In that case, the host on the Internet can communicate with a host on your LAN within certain port range. On this page, you can add or remove virtual server entries.
Page 69 2. To add a virtual server: a. Click Add. The following page appears. b. Modify the fields as needed, using the information in the table below. Field Description Use interface Select the interface that you want to configure. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 70: Port Triggering
Field Description Service Name Select or enter the service for which you want to forward IP packets. Options are: Select a Service: Select from services defined for your network. The port table at the bottom of the page is updated with the default port ID defined for the service.
Page 71 1. In the left navigation bar, click Advanced Setup > > Port Triggering. The following page appears. 2. To add a port trigger, click Add. The following page appears. 3. Modify the fields as needed, using the information in the following table. SMARTRG INC.
Page 72: Dmz Host
4. To remove a trigger, click the Remove check box next to it and then click the Remove button. The list is refreshed. 5. Click Apply /Save to implement the settings. Field Name Description Use Interface Select the interface for which the port triggering rule will apply. Application Name Select or enter the application that requires a port trigger.
Page 73: Alg
4. To deactivate a DMZ host, delete the IP address from the DMZ Host IP Address field, and then click Apply. 5. Click Apply to commit the new or changed address. On this page, you can enable Session Initiation Protocol (SIP) for your NAT. SIP is a communications protocol for signaling and controlling multimedia communication sessions.
Page 74: Security
1. In the left navigation bar, click Advanced Setup > > Multi NAT and then click Add. The following page appears. 2. Modify the fields as needed, using the information in the table below. Field Description Rule Type Select the type of rule. Options are One to One, One to Many, Many to One, and Many to Many.
Page 75 1. In the left navigation bar, click Advanced Setup > Security and then click Add. The following page appears. You can also reach this page by clicking Advanced Setup > Security > IP Filtering > Outgoing. 2. Fill in the fields, using the information in the table below. 3.
Page 76: Ip Filtering - Incoming
Field Name Description Destination IP Enter the destination IP address of a LAN side host for which you wish to filter/block outgoing traffic using the address specified protocol(s). Note: The address specified here can be a particular address or a block of IP address on a given network subnet. This is done through appending the address with the associated routing "/prefix"...
Page 77: Mac Filtering
Field Name Description IP Version For the filter to be configured and effective for IPV6, the gateway must be installed on a network that is either a pure IPV6 network (with that protocol enabled) or is both IPV4 and IPV6 dual protocol enabled/configured.
Page 78 1. In the left navigation bar, click Advanced Setup > Security > Filtering. The following page appears. 2. To modify settings for an existing policy, click the Change checkbox next to it, and then click Change Policy. Options are BLOCKED and FORWARD. The page refreshes, showing that the action has changed. The Change Policy button acts like a toggle switch, clicking it switches the policy from BLOCKED to FORWARD and back again.
Page 79: Parental Control
1. On the MAC Filtering Setup page, click Add. The following page appears. 2. Fill in the fields, using the information provided in the following table. The Protocol field is required. 3. Click Apply/Save to commit your changes. The fields on this page are defined below. Field Name Description Protocol Type...
Page 80 1. In the left navigation menu, click Advanced Setup > Parental Control and then click Add. The following page appears. 2. Enter a descriptive name for the rule. 3. (Optional) Enter an additional MAC address by clicking Other MAC Address and entering the address in the adjacent field.
Page 81: Url Filter
Url Filter On this page, you can prevent the LAN users from accessing some Web sites in the WAN. 1. 1. Click Advanced Setup > Parental Control > Filter, and the following page appears. 2. Select whether to exclude or include the URLs in the list you are going to create. If you select Exclude, users cannot access the URLs in the list.
Page 82: Quality Of Service
Quality of Service Quality of Service (QoS) enables prioritization of Internet content to help ensure the best possible performance. This is particularly useful for streaming video and audio content with minimized potential for drop-outs. QoS becomes significant when the sum of all traffic (audio, video, data) exceeds the capacity of the line.
Page 83: Qos Queue
3. (Optional) Select the default DSCP Mark (Differentiated Services Code Point) classification value to be used. The default is No Change(-1). 4. Click Apply/Save to save your settings. QoS Queue On this page, you can configure a queue and add it to a selected Layer2 interface. You can also edit and delete queues. A number of standard queues are already defined.
Page 84 b. Fill in the fields, using the information in the following table. The visible fields vary by interface and queue precedence selections. In most cases, you can use the default values. c. Click Apply/Save. You are returned to the Qos Queue Setup page. 3.
Page 85: Qos Classification
Note: Make sure that wireless connection is active by going to Wireless and clicking Apply/Save. In the left navigation bar, click Advanced Setup > Quality Of Service > QoS Queue > Wlan Queue. The following page appears. QoS Classification On this page, you can create classifications (traffic class rules) for assigning ingress traffic to a priority queue. 1.
Page 86 2. Fill in the fields, using the information in the table below. 3. Click Apply/Save to commit your changes. The fields on this page are defined below. Field Name Description Add Network Traffic Class Rule section Traffic Class Name Enter a descriptive name for this rule. Rule Order This option is set to Last and cannot be changed.
Page 87: Qos Port Shaping
Field Name Description Ingress Interface Select an interface for incoming traffic. Options are LAN, WAN, Local, and any interface defined for your network. Ether Type Select the Ethernet interface type for this classification. Options include IP, ARP, IPV6, PPPoE, and any other Ethernet interface defined for your network.
Page 88: Routing
2. (Optional) For each interface in the table, enter a Shaping Rate (in Kbps) and a Burst Size (in bytes). The default settings work for most scenarios. 3. Click Apply/Save to commit your changes. Routing In this section, you can configure default gateway, static routing, policy routing and RIP settings. Default Gateway On this page, you can select the WAN interface for the default gateway.
Page 89: Static Route
1. In the left navigation bar, click Advanced Setup > Routing. The following page appears. 2. (Optional) Select entries in the lists and click the arrows to move your selections from left to right or right to left. 3. (Optional) In the Selected WAN Interface field, select the appropriate interface.
Page 90: Policy Routing
2. Fill in the fields, using the information in the table below. 3. Click Apply/Save to commit your changes. The fields on this page are defined below. Field Name Description IP Version Select the IP version associated with the static route you wish to create. Options are IPv4 and IPv6. Destination IP Enter the destination network address / subnet mask for this route.
Page 91: Rip
2. Fill in the fields, using the information in the table below. 3. Click Apply/Save to commit your changes. You are returned to the Policy Routing Setting page. 4. To remove a route, click the Remove check box next to it and then click the Remove button.
Page 92: Dns
1. In the left navigation bar, click Advanced Setup > Routing > RIP. The following page appears. 2. For the interface that you want to modify, select values using the information in the table below. 3. To enable a configuration, click the Enabled checkbox next to the interface.
Page 93: Dynamic Dns
Define a static DNS IP address: Click Use the following Static DNS IP address and enter the DNS server IP addresses. Obtain IPv6 DNS information from a WAN interface: Select the interface in the WAN Interface Selected field. If no WAN interface is configured, this field is disabled. Define a static IPv6 DNS IP address: Click Use the following Static IPv6 DNS address and enter the...
Page 94: Dns Config
DNS Config On this page, you can configure DNS domains. 1. In the left navigation bar, click Advanced Setup > > Config. The following page appears. 2. To add a DNS domain, click Add. The following page appears. 3. Enter a domain name and IP address for the domain. Only letters, numbers, dashes, and periods are allowed. 4.
Page 95 1. In the left navigation menu, select Advanced Setup > DSL. The following page appears. 2. Modify the settings as needed. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 96: Dsl Bonding
3. To modify additional parameters, click Advanced Settings. The following page appears. 4. Select the test mode that you want to run. 5. To view the tone selection table, click Tone Selection. Changing these settings arbitrarily is not recommended. Close the window to return to the DSL Advanced Settings page. 6.
Page 97: Upnp
1. In the left navigation bar, click Advanced Setup > Bonding. The following page appears. 2. To disable bonding, click xDSL Bonding Capability. This action is not recommended. 3. Click Save/Reboot to commit your changes. Your gateway is rebooted. UPnP On this page, you can enable or disable the UPnP function.
Page 98: Print Server
1. In the left navigation menu, click Advanced Setup > Proxy. The following page appears. 2. To disable the DNS Proxy, click the Enable DNS Proxy check box to clear it. 3. To modify the host and domain, enter the host name of the new broadband gateway and the domain name of the LAN network.
Page 99: Dlna
8. Click Apply/Save to save and apply the settings. For more information about configuring your PC to access this printer, see the related How-To article in the SmartRG Customer Portal. DLNA On this page, you can manage on-board digital media servers. 1.
Page 100: User Accounts
User Accounts On this page, you can manage user accounts for the storage devices. 1. In the left navigation menu, click Advanced Setup > Storage Service > User Accounts. The following page appears. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 101: Interface Grouping
2. To add a new account: a. Click Add. the following page appears. b. Enter a user name and enter the password twice. The password cannot contain spaces. c. Click Apply/Save to save your settings. You are returned to the User Accounts page. 3.
Page 103: Ip Tunnel
2. To add a new grouping, click Add. The following page appears. 3. Follow the on-screen instructions and then click Apply/Save. 4. To remove a grouping from the list, click the Remove checkbox next to the group name and then click the Remove button.
Page 104: Ipv6Inipv4
In this section, you can configure connections of IPv6 networks across the IPv4 internet or IPv4 in IPv6. IPv6inIPv4 On this page, you can configure a tunnel for IPv6inIPv4. 1. In the left navigation bar, click Advanced Setup > IP Tunnel and then click Add.
Page 105: Ipsec
2. Enter a Tunnel Name. In the Mechanism field, the only option is DS-Lite. 3. Select the interfaces associated with the tunnel you wish to establish. 4. In the AFTR (Address Family Transition Router) field, do either of the following: To configure manually, enter the remote address in the AFTR field.
Page 106 2. Click Add New Connection. The following page appears. 3. Fill in the fields, using the information in the field description table below. Field Name Description IPSec Connection Name Enter a descriptive name for this connection. IP Version Select the IP version for this connection. Options are IPv4 and IPv6. The default is IPv4. Tunnel Mode Select the encapsulation method to be used.
Page 107 Field Name Description Remote IPSec Gateway Enter the WAN IP address for the tunnel. Address Tunnel Access From Select whether to allow access to the entire LAN or a single host for local IP addresses. Local IP Addresses Options are: Subnet: Allows access to the entire LAN.
Page 108: Certificate
Field Name Description Encryption Algorithm Select the encryption algorithm. Options are 3DES, AES - 128, AES - 192, and AES - 256. The default is A3DES. Integrity Algorithm Select the integrity algorithm. Options are MD5 and SHA1. Select Diffie-Hellman Select the encryption group for exchanging keys. Options range from 768 bit Group for Key - 8192 bit.
Page 109 2. Click Create Certificate Request. The following page appears. 3. Enter your connection details, using the information provided in the table below. 4. Click Apply to complete the request. 5. Submit your certificate request to a certificate authority for signature. The fields on this page are defined below.
Page 110 2. In the Certificate Name field, type "cpecert". 3. Paste the Certificate details between the BEGIN markers. 4. Paste the Private Key information between the BEGIN markers. 5. Click Apply to commit this certificate. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 111: Trusted Ca
Trusted CA On this page, you can import Trusted Certificates to identity other gateways to your gateway as a trusted source. 1. In the left navigation bar, click Advanced Setup > Certificate > Trusted CA. The following page appears. 2. To import a certificate, click Import Certificate.
Page 112 1. In the left navigation menu, click Advanced Setup > Multicast. The following page appears. 2. Fill in the fields, using the information in the table below. The fields provided for the IGMP and MLD configurations are largely the same. 3.
Page 113 The fields on this page are defined below. Field Name Description Source Specific Select whether a specific multicast source is used. Options are Disable and Enable. The default is Disable. Multicast Multicast Select whether IGMP packets are given priority handling and at what level. Options are: Precedence Enable: IGMP packets are prioritized using the multicast precedence value.
Page 114: Managing Group Exception Lists
Managing group exception lists You can manage exceptions for multicast groups using the IGMP Group Exception List MLD Group Exception List tables. The first two entries are created by default; you cannot change these entries. To add an exception, type the IP address in the Group Address field, enter the mask information in the Mask / Mask bits...
Page 115: Wireless
Wireless In this section, you can configure the wireless interface settings for your gateway, including basic and advanced settings, MAC filtering, and wireless bridging. Basic On this page, you can configure basic features of the WiFi LAN interface. You can enable or disable the WiFi LAN interface, hide the network from active scans, set the WiFi network name (also known as SSID) and restrict the channel set based on country requirements.
Page 116 4. (Optional) Define up to three virtual access points for guest access using the information from the Wireless - Guest/Virtual Access Points section of the table below. 5. Click Apply/Save to commit your settings. The fields on this page are defined below. Field Name Description Enable Wireless...
Page 117: Security
Security On this page, you can configure network security settings of a wireless LAN interface, either by using the WiFi Protected Setup (WPS) method or by setting the network authentication mode. For WiFi Protected Setup, the following methods are supported: PIN entry: Mandatory method of setup for all WPS-certified devices.
Page 118: Open And Shared Authentication
2. Modify the settings as needed, using the information provided in the field description table below and in the sections that explain each authentication method. The fields in the WPS Setup section are described in the following table. Field Name Description Enable WPS This option is enabled by default.
Page 119: 802.1X Authentication
Modify the fields as needed and then click Apply/Save. The fields on this page are defined below. Field Name Description WEP Encryption Select the Wired Equivalent Privacy (WEP) mode. Options are Enabled and Disabled. The default is Disabled for Open authentication and Enabled for Shared authentication. Encryption Strength (Appears when WEP Encryption is set to Enabled) Select the length of the encryption method.
Page 120: Wpa2 And Mixed Wpa2/Wpa Authentication
Modify the fields as needed, using the information provided in the table below, and then click Apply/Save. Field Name Description RADIUS Server IP Enter the IP address of the RADIUS (Remote Authentication Dial In User Service) server associated with your address network.
Page 121: Wpa2-Psk And Mixed Wpa2/Wpa-Psk Authentication
Modify the fields as needed, using the information provided in the table below, and then click Apply/Save. Field Name Description Protected Management Select whether management frames are protected. Options are Disabled, Capable, and Required. The Frames default is Disabled. WPA2 Preauthentication Select whether clients can pre-authenticate with the gateway while still connected to another AP. Options are Enabled and Disabled.
Page 122: Mac Filter
Modify the fields as needed, using the information provided in the table below, and then click Apply/Save. Field Name Description Protected Management Select whether management frames are protected. Options are Disabled, Capable, and Required. The Frames default is Disabled. WPA/WAPI passphrase Enter the security password to be used by this security configuration.
Page 123 1. In the left navigation bar, click Wireless > Filter. The following page appears. 2. In the Select SSID field, select the access point that you want to configure. 3. Select the MAC Restrict Mode. Options are: Disabled: Disable wireless MAC address filtering. This is the default. Allow: Allow the wireless clients in the MAC Address list to access the wireless network.
Page 124: Wireless Bridge
Wireless Bridge On this page, you can configure the wireless bridge features of the wireless LAN interface. 1. In the left navigation menu, click Wireless > Wireless Bridge. The following page appears. 2. Modify the fields as needed, using the information provided in the table below. Field Name Description Bridge Restrict...
Page 125 1. In the left navigation bar, click Wireless > Advanced. The following page appears. 2. Modify the fields as needed, using the information in the following table. 3. Click Apply/Save to commit your changes. Field Name Description Band The band you are configuring: 2.4 GHz or 5 GHz. Channel Select the Wi-Fi channel you want to use.
Page 126 Field Name Description Auto Channel Enter the frequency (in minutes) at which the gateway scans channels for interference. If a threshold of Timer (min) inference is detected, a new channel will be selected automatically. Options are 0 - 65535 minutes. The default is 15 minutes.
Page 127 Field Name Description Multicast rate Select the multicast transmission rate for the network according to the speed of your wireless network. Select from a range of transmission speeds or select Auto to have the gateway automatically use the fastest possible data rate and enable the Auto-Fallback feature.
Page 128: Station Info
Field Name Description WMM No The acknowledge policy used at the MAC level. Enabling this option allows better throughput but, in a noisy RF Acknowledgment environment, higher -963 error rates may result. The default is Disabled, meaning that an acknowledgment packet is returned for every packet received.
Page 129 1. In the left navigation menu, click Wireless > Wifi Insight. The following page appears. You can also reach this page by clicking Wireless > Wifi Insight > Configure. 2. In the Sample Interval section, select the number of seconds for sampling to occur. Options are 5, 10, 15, and 20 seconds.
Page 130: Site Survey
3. In the Start/Stop Data Collection section, configure the data sample: a. Click Start collecting data every. b. Select the days of the week when the data should be collected. c. In the From fields, enter the start and end times for collection. a.
Page 131: Channel Statistics
1. In the left navigation menu, click Wireless > Wifi Insight > Site Survey. The following page appears. 2. In the first field above the chart, select the wireless network that you want to review. 3. In the Channel field, select the channel that you want to review. 4.
Page 132: Metrics
Metrics On this page, you can view glitch counter, chanim, associated stations, and packet queue statistics for your wireless networks. In the left navigation menu, click Wireless > Wifi Insight > Metrics. The following page appears. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 134: Voice
Voice In this section, you can view status, enable features, and configure settings for VoIP. VoIP Status On this page, you can view status data for your SIP accounts. In the left navigation menu, click Voice. The following page appears. In the Registration Status field, Up means registered successfully, Down means unregistered, Disabled means the account is not...
Page 135 1. In the left navigation menu, click Voice > SIP Basic Setting. The following page appears. 2. Modify the fields as needed, using the information in the following table. 3. Click Apply to implement your changes. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 136 The fields on this page are defined below. FIELD NAME DESCRIPTION Bound Interface Name Select the bound interface name. Options are LAN, Any_WAN, and any other interfaces configured for your network. Country Select the country or region for this voice configuration. SIP local port Enter the local port of the gateway which is the SIP UA (user agent) port.
Page 137: Sip Advanced Setting
FIELD NAME DESCRIPTION ptime [ms] The 2nd and 6th columns identify the packetization time (ptime) which is the length of the digital voice segment that each packet holds. Enter the ptime in milliseconds. The default is 20 millisecond packets. Note: Selecting 10 millisecond packets improves voice quality; less information is lost, but there is more load on the network traffic.
Page 139 2. Modify the fields as needed, using the information provided in the table below. 3. Click Apply to implement the settings. The fields on this page are defined below. FIELD NAME DESCRIPTION Line The VoIP line you want to configure. SMARTRG INC.
Page 140 FIELD NAME DESCRIPTION Call waiting Select to enable call waiting notification. When users hear the call waiting tone during a call, they press FLASH to put the first call on hold and to answer the second call. Pressing FLASH again switches back to the previous call.
Page 141 FIELD NAME DESCRIPTION Enable VAD support Select to enable VAD support. Select the VAD mode in signal value. Options are None, Silencsupp, and annexa/annexb/vad. Enable RTCP Flow Ctrol Select to enable RTCP flow control for improved quality of service. Enable Echo Cancellation Select to enable echo cancellation for improved quality of service. Enable # to ASCII Select to enable conversion of numbers to their ASCII equivalents.
Page 142: Sip Star Code Setting
FIELD NAME DESCRIPTION Complementary business Options are Local model, Server model, IMS model, and Undefined. models If you select IMS model, the ETSI Malicious call tracing field appears. To enable malicious call tracing option, click the checkbox. SIP Star Code Setting On this page, you can set the numbers that are used with the * key to enable and disable various features.
Page 143 1. In the left navigation menu, click Voice > SIP Extra Setting. The following page appears. 2. Modify the fields as needed, using the information in the table below. 3. Click Apply to implement the settings. The fields on this page are defined below. Field Description Line...
Page 144: Sip Debug Setting
SIP Debug Setting On this page, you can configure the debugging settings. 1. In the left navigation menu, click Voice > SIP Debug Setting. The following page appears. 2. Modify the fields as needed, using the information in the table below. 3.
Page 145 Field Description Protocol Stack Log (Optional) Select the level of detail stored in these logs. Options are SPY_GEN_INFO, SPY_FNENTER, SPY_ Level EVENT, SPY_MINOR_ERR, SPY_MAJOR_ERR, SPY_FATAL_ERR, and SPY_LEVEL_OFF. The default is SPY_ Call Control Log Level MAJOR_ERR. Register Log Level DSP Log Level Tele Log Level Dialplan Log Level Restart Log Level...
Page 146: Diagnostics
Diagnostics Line performance diagnostic tools are supported by your SmartRG gateway. Three legs of the data path are included in the available tests: LAN connectivity, DSL connectivity, and Internet connectivity tests. Diagnostics On this page, you can test the connection to your local network, the connection to your DSL service provider, and the connection to your Internet service provider.
Page 147: Ethernet Oam
Ethernet OAM On this page, you can view diagnostics regarding your VDSL PTM or Ethernet WAN connection. Fault Management is compliant with IEEE 802.1ag for Connectivity Fault Management. 1. In the left navigation bar, click Diagnostics > Ethernet OAM. The following page appears. 2.
Page 148 b. Modify the fields, using the information provided in the Ethernet Service OAM (802.1ag/Y.1731) section of the table below. 4. Click Apply/Save to commit your changes. 5. To run a loopback test, enter a MAC address in the Target MAC field and click Send Loopback at the bottom of the...
Page 149 Field Name Description Remote Loopback Click to enable on-demand link diagnostics, including bit-error-rate approximation. Active Mode Click to enable this feature. Ethernet Service OAM (802.1ag/Y.1731) section WAN Interface Select the WAN interface that you want to test. MD Level (Appears for the 802.1ag option only) Select the domain level for this maintenance domain. Options are 0 - 7.
Page 150: Diagnostic Tools
Diagnostic Tools In this section, you can ping or trace the communication route, and start or stop your DSL connection. Ping On this page you can ping a server by host name or IP address. 1. In the left navigation menu, click Diagnostics Tools >...
Page 151: Traceroute
Traceroute On this page, you can use the traceroute utility to trace a connection. 1. In the left navigation menu, click Diagnostics Tools > Traceroute. The following page appears. 2. Enter the host name or IP address. 3. Click Submit. The details of the trace appear on the page. 4.
Page 152 1. In the left navigation menu, click Diagnostics Tools > Start/Stop DSL. The following page appears. 2. To connect to your DSL, click Start. A message appears, with instructions for refreshing the page. When the connection is ready, the "DSL connection is up" message appears. 3.
Page 153: Management
Management In this section, you can configure server and system log settings, control access, and configure clients. Settings In this section, you can back up the current settings, restore saved settings, or reset the gateway to default settings. Backup On this page, you can back up the current settings for your gateway in a file stored on your computer. 1.
Page 154: Update
Update On this page, you can restore previously backed-up gateway settings. 1. In the left navigation bar, click Management > Settings > Update. The following page appears. 2. To update settings from a file that you saved previously: a. Click the Browse button to locate either a customized setting file or the default setting file (.conf file) on your local system and click Open.
Page 155: Restore Default
1. In the left navigation menu, click Management > Settings > Auto Update. The following page appears. 2. Click Enable Auto Update Settings. 3. In the Update Period (hours) field, enter the number of hours between automatic updates. The default is 36 hours. Provisioning Using Protocol, configure Server...
Page 156 1. In the left navigation bar, click Management > Settings > System Log. The following page appears. 2. To view the system log details: a. Click View System Log. The log appears in a separate window. b. To update the data, click Refresh. SMARTRG INC.
Page 157: Security Log
3. To configure the log settings: a. Click Configure System Log. The following page appears. b. Modify the fields as needed, using the information in the table below. c. Click Apply/Save to save and apply your changes. You are returned to the System Log page. The fields on this page are defined below.
Page 158: Snmp Agent
Authorized user logged out Security lockout added / removed Authorized / unauthorized resource access Software update 1. In the left navigation bar, click Management > Security Log. The following page appears. 2. Do any of the following: To view the log, click View. The log appears in a separate window. To purge the log entries and start fresh, click Reset.
Page 159: Management Server
1. In the left navigation bar, click Management > SNMP Agent. The following page appears. 2. Modify the fields as needed, using the information provided in the table below. 3. Click Save/Apply to commit your changes. The fields on this page are defined below. Field Name Description SNMP Agent...
Page 160 the default settings, consult the materials provided by your ACS vendor to determine the appropriate parameters and server settings. SmartRG products can accommodate several ACS products, including: Calix Consumer ACS Cisco Prime Home ClearVision Device Manager by SmartRG 1. In the left navigation bar, click Management >...
Page 161: Stun Config
Field Name Description Inform Interval Enter the frequency (in seconds) at which the CPE (gateway) checks in with the ACS to sync and exchange data. A typical production environment has CPEs informing to the ACS once a day or every 86,400 seconds. ACS URL Enter the URL for the CPE to connect to the ACS using the CPE WAN Management Protocol.
Page 162 STUN is most commonly used with older modems under ACS management connected via a NAT gateway. NAT accommodates a LAN- side device that has been allocated a Private IP address such as a CPE device on a private network behind an ONT. In this instance, the regular CWMP Connection Request mechanism to talk to the modem gateway cannot be used to initiate a session with that ACS.
Page 163: Xmpp Connection
The fields on this page are defined below. Field Name Description STUN Server Address Enter the physical STUN server’s assigned network address. An invalid address will produce an immediate on-page error message from the gateway. You can enter a maximum of 256 characters An ACS server may also have STUN functionality running on the same physical box.
Page 164 1. In the left navigation bar, click Management > XMPP Connection. The following page appears. 2. To add a connection, click Add. The following page appears. 3. In the XMPP Connection field, select whether to use TLS and then click Enable. 4.
Page 165: Internet Time
Field Description XMPP Server Address Enter the IP address for the server. XMPP Server Port Enter the port for the IP address entered above. 5. Click Apply/Save to save and apply the settings. 6. To remove a connection, click the Remove checkbox to the right of the entry and then click the Remove...
Page 166: Passwords
"admin" has unrestricted access "support" has general access rights plus additional rights to perform maintenance tasks and run diagnostics. "user" can view settings and statistics and update the firmware. Passwords On this page, you can modify the username and password of your users. 1.
Page 167: Services Control
1. In the left navigation bar, click Management > Access Control > Access List. The following page appears. 2. Click Add. The following page appears. 3. Enter the IP address and mask of the station allowed to access local management services. 4.
Page 168: Logout Timer
1. In the left navigation bar, click Management > Access Control > Services Control. The following page appears. 2. Select or clear the enable checkbox next to each service and interface that you want to change. 3. (Optional) In the LAN Port Port fields, modify the port numbers for the services.
Page 169: Update Software
2. In the Logout Timer Period field, type the number of minutes after which a session will be ended. Options are 0 - 60 minutes. The default is 15 minutes. To disable this feature, enter a zero (0) in the field. Update Software On this page, you can update the firmware of your gateway.
Page 170 1. In the left navigation, click Management > Reboot. The following page appears. 2. Click Reboot. The gateway reboots and, after a few minutes, the Login dialog box appears. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 171: Logout
Logout 1. To log out of your gateway, click Logout in the left navigation menu. The Logout page appears. 2. Click the Logout button. A success message appears. SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...
Page 172: Appendix: Fcc Statements Fcc Interference Statement
Appendix: FCC Statements FCC Interference Statement This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
Page 173: Fcc - Part 68
FCC - PART 68 This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom case of this equipment is a label that contains, among other information, a product identifier in the format US: VW7DL01BSR555A. This equipment uses the following USOC jacks: RJ-11/RJ45/USB/Power Jacks.
Page 174: 5Ghz
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Page 175: Revision History
Revision History Revision Date LAN ports July 2017 Updated to match release 1.0.0.76. May 2017 Corrected wireless radio button instructions. March 2017 Multiple updates to match current environment. AugustOctober Initial release of this user manual. 2016 SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2017...

SMART/RG SR655ac User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMART/RG SR655ac

Summary of Contents for SMART/RG SR655ac

Table of Contents
