- Page 1 Lorem ipsum Lorem ips Lorem ips Lorem ipsum SR905acv Quick Start Guide...
-
Page 2: Installation
Installation 1. Connect the gateway to incoming services: For Ethernet services, connect one end of an Ethernet cable to the WAN port on the gateway and connect the other end of the cable to the wall jack installed by your provider. For fiber services: a. - Page 3 PHONE POWER...
-
Page 4: Led Indicators
LED Indicators Your SR905acv gateway has several status indicators (LEDs) on its top which are described below. Legend: White Green White blinking Green blinking Action Explanation Power Device in CFE mode Device powered on and ready for use Internet DSL sync acquired and gateway on line... - Page 5 Action Explanation Device online (at 1000 BASE-T) Device online (at 10/100 BASE-T) WAN Ethernet connected (at 1000 BASE-T) Data being transferred (at 1000 BASE-T) WAN Ethernet connected (at 10/100BASE-T) Data being transferred (at 10/100BASE-T) 2.4 GHz WiFi enabled 5 GHz Data being transferred WPS enabled Data being transferred...
-
Page 6: Logging In To Your Gateway
Logging in to Your Gateway To change the settings on your gateway, you must log into the gateway's interface. Make sure that you have completed the steps in "Installation" before you begin. 1. Open your Internet browser and type 192.168.1.1 into the address line. The Sign in dialog box appears. 2. -
Page 7: Configuring The Wan Manually
Then, enter the credentials provided with the gateway when you first received it. Configuring the WAN Manually If the automatic connect process is unsuccessful, refer to the "Ethernet WAN" section of the SmartRG SR905acv Gateway User Manual to manually establish a connection. - Page 8 Wi-Fi Setup 1. In the left menu, click WiFi > Networks. The following page appears, showing information for the primary network. The dual-band option is enabled by default.
- Page 9 2. Accept the default ID shown in the SSID field or enter the SSID for the network that you want to configure. You will need this ID for Step 8. 3. Choose a passphrase and type it in to the Password field.
-
Page 10: Optional Wall Mount
Optional Wall Mount Using a Phillips-head screwdriver, remove the mount Gateway from the bottom of the gateway. Front Insert the mount into the back of the gateway and tighten the screw located in the bottom of the mount. Using the template below, attach the two included screws to the wall. -
Page 11: Additional Support
Record Your SR905acv Wi-Fi Settings Predefined wireless settings If you change the wireless settings Primary WiFi network name (SSID) Primary WiFi Network key (password) Guest WiFi network name (SSID) Guest WiFi network key (password) Video WiFi network name (SSID) Video WiFi network key (password) Additional Support If you require further instructions, please contact your local ISP Support.
