HF-430NEO
PROFINET for Communication option
Model: P1-PN
Operating and Maintenance Manual
1. Make sure that this operating and maintenence manual is
delivered to the end user of inverter unit.
2. Read this manual before installing or operating the inverter
unit, and store it in a safe place for reference.
Series
NOTICE
Manual DM3403E
-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumitomo Drive Technologies P1-PN
Summary of Contents for Sumitomo Drive Technologies P1-PN
- Page 1 HF-430NEO Series PROFINET for Communication option Model: P1-PN Operating and Maintenance Manual NOTICE 1. Make sure that this operating and maintenence manual is delivered to the end user of inverter unit. 2. Read this manual before installing or operating the inverter unit, and store it in a safe place for reference. Manual DM3403E...
- Page 2 Copyright © 2020 Sumitomo Heavy Industries,Ltd. All rights reserved. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of Sumitomo.
- Page 3 If future updated descriptions differ from the Basic Guide, the description in the User's Guide will have higher priority. Always use the P1-PN strictly within the range described in the User's Guide and perform proper inspection and maintenance to prevent failures or accidents.
-
Page 4: Table Of Contents
Table of Contents ● Introduction ・・・・・・・・・・・・・・・・・・・・・・・・・・・・1 ● Table of Contents ・・・・・・・・・・・・・・・・・・・・・・・・・・2 1. Precautions 1.1 Please be Careful！ ・・・・・・・・・・・・・・・・・・・・・・・・3 1.2 Precautions during the installation！ ・・・・・・・・・・・・・・・・3 1.3 Precautions during the wiring！ ・・・・・・・・・・・・・・・・・・・4 1.4 Precautions during operation！ ・・・・・・・・・・・・・・・・・・・5 1.5 Precautions during Maintenance/Inspection！ ・・・・・・・・・・・・6 1.6 Precautions for disposal！... -
Page 5: Precautions
1. Precautions 1.1 Please be Careful！ Danger ・If handled incorrectly or improperly, it might cause death, serious physical injuries, or damage to the inverter, motor or even the entire system. Caution ・Before installation, wiring, operation, inspection, or usage please read and fully understand this guide. -
Page 6: Precautions During The Wiring！ ・・・・・・・・・・・・・・・・・・・4
1.3 Precautions during the wiring! Danger ● Risk of an electric shock and/or fire！ ・Be sure to ground the inverter. Electric ・Entrust the wiring work only to a qualified electrician. shock and Fire ・Before the wiring work make sure to turn off the power supply and wait for more than 10 or 15 hazard minutes depending on the inverter model* . -
Page 7: Precautions During Operation！ ・・・・・・・・・・・・・・・・・・・5
1.4 Precautions during operation! Danger ● Risk of an electric shock or fire！ Electric ・DO NOT touch the inside of this device, check the signal, do any wiring or plug/unplug the shock connectors while it energized. and Fire hazard ・DO NOT insert any sick or rod like objects inside this device while it is energized. Prohibited ●... -
Page 8: Precautions During Maintenance/Inspection！ ・・・・・・・・・・・・6
1.5 Precautions during Maintenance /Inspection! Danger ● Risk of an electric shock！ ・Before any maintenance or inspection make sure to turn off the power supply and wait for more Electric than 10 or 15 minutes depending on the inverter model *. shock (Confirm that the charge lamp is OFF and the DC voltage between terminals P and N is 45 V or less.) -
Page 9: The Enclosed Items
Check that the items were not smashed or damaged during the delivery. Check that there is a P1-PN, there is an Instruction Manual, there are 2 ferrite cores, when unpacking. Please check again that your order match with the name plate of the device. -
Page 10: External Features
＊＊＊＊＊＊＊△□□□□ Manufacture number (MFG No) 7．Installation 7.1 Installation The P1-PN can be attached to any of the 3 option slots of the HF-430NEO inverter. It can be attached to either SLOT1, 2 or 3. Option cassette connection slots SLOT3 SLOT1... -
Page 11: How To Install ・・・・・・・・・・・・・・・・・・・・・・・・・・・9
Before installing the P1-PN, please refer to the chapter 7“Inverter setting” of the user's guide and configure the inverter. For explanation purposes, it will be assumed that the P1-PN is going to be installed in the SLOT1. (1) Remove the cover of the option cassette connection slot. - Page 12 (3) Secure the P1-PN with the screw removed in (1) Option cassette connection slots SLOT1 SLOT2 SLOT3 RJ45 Keypad Fasten the screw. USB(micro-B) (4) Connect the FG terminal to functional ground. Option cassette connection slots SLOT1 SLOT2 SLOT3 RJ45 Keypad Connect to functional ground.
- Page 13 10．GSDML File In order to use the P1-PN, it is necessary to install the P1-PN GSDML file into the PROFINET master Configuration tool. The GSDML file is an xml file that has the specific information of the PROFINET slave device.
-
Page 14: Device Specifications
P1-PN telegram 103 (PPO3 of PROFIdrive version 2) Telegram P1-PN telegram 104 (PPO4 of PROFIdrive version 2) PROFIdrive P1-PN telegram 105 (like PPO5 of PROFIdrive version 2) Configuring of telegram oH-24 and From oJ-01 to oJ-60 of HF-430NEO parameters Operating mode... -
Page 15: Dimensions After Installed
12．Dimensions after installed The dimensions of the P1-PN after it is installed on the HF-430NEO are shown in the image below. As shown on the image a part of this device will stand out from the HF-430NEO. Please be cautious when installing the device. -
Page 16: Warranty
Warranty Warranty Warranty The warranty shall be 18 months from date of shipment or 12 months after initial period operation, whichever is shorter. In the event that any problem or damage to the Product arises during the “Warranty Period” from defects in the Product whenever the Product is properly installed and combined with the Buyer’s equipment or machines maintained as specified in the maintenance manual, and properly operated under the conditions described in the catalog or as otherwise agreed upon in writing between the Seller and Buyer or its... - Page 17 Worldwide Locations U.S.A Austria Korea Sumitomo (SHI) Cyclo Drive Germany GmbH Sumitomo (SHI) Cyclo Drive Korea, Ltd. (SCK) Sumitomo Machinery Corporation of America (SMA) (SCG) Royal Bldg. 19 Rm. 913, 5 Saemunan-ro 5-Gil Jongro-Gu SCG Branch Austria O ce 4200 Holland Blvd. Chesapeake, VA 23323, U.S.A. Seoul, Korea 03173 Gruentalerstraße 30A, 4020 Linz, Austria TEL (1)757-485-3355...
