- Page 1 INSTRUCTION MANUAL 25L Dehumidifier I 50L Dehumidifier Models: DC25DEHUM & DC50DEHUM For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance DETAILS OF TYPE AND RATING OF FUSES : T; 3.15A; 250VAC. CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place.
- Page 3 from traffic areas and where it will not be a tripping hazard. DO NOT COVER. Never cover or obstruct in any way the outlet at the top of the • dehumidifier or the air inlet slots at the rear of the dehumidifier. Only operate this appliance with a minimum of 50cm clearance all around i.e.
- Page 4 WARNING: For using R290 refrigerant. ThIs symbol shows that this appliance uses a flammable refrigerant. If the refrigerant is leaked and exposed to an external ignition source, there is a risk of fire. CAUTION: RISK OF FIRE/FLAMMABLE MATERIALS. THE APPLIANCE MUST BE INSTALLED, USED &...
- Page 5 1. Transport of equipment containing flammable refrigerants - see transport regulations 2. Marking of equipment using signs - see local regulations 3. Disposal of equipment using flammable refrigerants - see national regulations. 4. Storage of equipment/appliances - The storage of equipment should be in accordance with the manufacturer's instructions.
- Page 6 • Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance.
- Page 7 • Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
- Page 8 • Charging procedures In addition to conventional charging procedures, the following requirements shall be followed. Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. Cylinders shall be kept upright.
- Page 9 • Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available.
- Page 10 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left unattended lead may become cable may be overloaded damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 11: Specification
Specification Model no. DC25DEHUM DC50DEHUM Power supply 220-240V~, 50Hz Dehumidification capacity at 30°C, 80% Operating Temperature 5-32°C, 30%RH-90%RH Modes Refrigerant R290 Handle & Castors Continuous Drainage Y (Draimage hose included) Water Tank 3.4L 6.5L Timer 24 hours W365 x H500 x... -
Page 12: How It Works
How It Works This product is a dehumidifier. It controls relative humidity by passing the air through the unit, forcing the excess moisture to condensate over the cooling elements. Contact with this cold surface causes the moisture in the air to condense. This condensed water then drains safely into the water tank. - Page 13 Parts DC25DEHUM 小 箱 体 大箱体（无 水泵 ） DC50DEHUM Handle Control Panel 大 箱体（有水 泵） Water Tank Water Level Window Castors Power Cord Drainage Holes Hooks Storage Socket Air Outlet Air Intake Grille...
- Page 14 Accessories Note: Before use, please ensure to remove the water tank from the appliance, take out the plug and any other accesories and then place the tank back into the slot. Some accesso- ries will be found in the tank, and some in the product packaging. 1.
-
Page 15: Control Panel
Control Panel Function indicator Mode indicator Display screen lights lights 银色 PANTONE 877 C Decrease Increase On/Off... -
Page 16: Operation
Operation 1. Press the ON/OFF button to control the start up or shut down of the unit. 2. Press the MODE button to choose between DRY, TURBO, COMFORT or CONTINUOUS mode. • DRY Mode - Press the MODE button until the DRY indicator light is on. Press the INCREASE or DECREASE buttons to select the desired humidity. - Page 17 Operation • PROGRAM SHUT DOWN - When the unit is running, press the TIMER button and the screen will begin to flash. Once flashing, press the INCREASE or DECREASE button to set your desired time between 0.5-24 hours. 5 seconds post setting the desired time, the timer function will begin and the indicator light will switch on.
- Page 18 Drainage Water Tank Full Alarm When the water tank is full, the compressor will shut off and stop for a few minutes. The unit will make a beeping noise, and the TANK FULL indicator light will be flashing. • The unit will not run again until the tank is emptied and properly placed back inside the unit.
- Page 19 Drainage Continuous Drainage Note: There are two methods to allow the unit to complete continuous drainage. Connector Drain Connect the drain pipe to the back of the unit. The unit will be able to continuously run without cleaning the bucket. 1.
-
Page 20: Other Functions
Other Functions Child Lock To use the child lock function, hold the INCREASE and DECREASE buttons simultaneously for about 3 seconds. When locked, the child lock indicator light will be on. To turn off, press the INCREASE and DECREASE buttons again simultaneously for around 3 seconds. - Page 21 Cleaning Note: After an extended period of time, when you plan on using the device again, ensure to: • Check the power cord and plug are both undamaged and the earth system is efficient. • Follow the installation instructions precisely. Note: Before cleaning or maintanence, turn the appliance off by pressing the ON/OFF button.
- Page 22 Cleaning End of season: When you do not plan to use the appliance for an extended period of time, ensure: • To unplug the unit from the mains socket, empty the water tank and remove the cap from the back of the unit. •...
-
Page 23: Troubleshooting
Trouble shooting THE UNIT DOES NOT OPERATE: • Is the unit plugged in? • Is the fuse blown or circuit breaker tripped? • Is the water tank full or has the dehumidifer reached its present level? • Is the water tank in the proper position? •... -
Page 24: Error Codes
Trouble shooting ERROR CODES: • EH - Humidity Sensor Failure • E1 - Temperature Sensor Failure • E2 - Temperature Sensor Failure • E3 - Gas Leakage POSSIBLE CAUSES: • EH - Humidity Sensor is damaged • E1 - Temperature Sensor is damaged •... - Page 28 Supplied by Glen Dimplex Australia 1340 Ferntree Gully Road, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
