Installation and Operating Instructions
Model: DXDH10N
Model: DXDH16N
Model: DXDH20N
For domestic household use only.
_________________________________________________________________________________________________________________________________________________
Products comply with the European Safety Standard EN60335-2-40 and the relevant parts of the European Standards for Electromagnetic Compatibility (EMC) EN55014, and
EN61000 along with EN62233 covering Electromagnetic Field (EMF) requirements. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC.
_________________________________________________________________________________________________________________________________________________
10L
Dehumidifier
16L
Dehumidifier
20L
Dehumidifier
08/35430/0 Issue 4
Advertisement
Table of Contents
Related Manuals for Dimplex DXDH10N
Summary of Contents for Dimplex DXDH10N
- Page 1 Installation and Operating Instructions Model: DXDH10N Dehumidifier Model: DXDH16N Dehumidifier Model: DXDH20N Dehumidifier 08/35430/0 Issue 4 For domestic household use only. _________________________________________________________________________________________________________________________________________________ Products comply with the European Safety Standard EN60335-2-40 and the relevant parts of the European Standards for Electromagnetic Compatibility (EMC) EN55014, and EN61000 along with EN62233 covering Electromagnetic Field (EMF) requirements.
-
Page 2: Safety Information
SAFETY INFORMATION Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place. Never immerse the appliance in water or other liquids. Never operate the appliance if a cable or connector has been damaged, after appliance malfunction or if the appliance was dropped or is otherwise damaged. - Page 3 To prevent spillage, empty the water tank before relocating the appliance. Do not tip the appliance to any side as escaping water could damage the appliance. Only operate the product in a level upright position. “WARNING: Never leave water in the reservoir when the appliance is not in use, microorganisms can grow in stagnant water, the water tank should be emptied and cleaned regularly and properly.
- Page 4 OPERATING INSTRUCTIONS 1. Control panel 2. Air outlet 3. Handle 4. Front panel 5. Back panel 6. Water outlet tube (continuous use) 7. Water tank CONTROL PLATE DESCRIPTION OPERATION INSTRUCTION Starting the unit Allow the unit to stand upright for 24hrs to let the compressor stabilize before use.
-
Page 5: Notes And Precautions
Turning off the unit 1. Turn the humidity control switch fully anticlockwise to the “OFF” position and the power supply is cut off and the unit stops operating. 2. If the dehumidifier is not in use for a long time, please disconnect the power cord plug from the supply outlet. -
Page 6: Drainage Instruction
DRAINAGE INSTRUCTION Switch off before carrying out any of these operations Fig 01 and leave for 3 minutes before switching on again. The extracted water is collected by the water tank (set up as supplied), or can be set up to drain continuously using a PVC hose (not included) connected to a drain outlet, the drain point must be lower than the unit outlet (see details below). -
Page 7: Specifications
5. 5. Every 2 weeks, remove the air filter and clean it with warm water, below 40° C. Allow it to dry naturally and then replace by reversing the removal instruction above. Never operate the product without the filter SPECIFICATIONS MODEL DXDH10N DXDH16N DXDH20N SPECIFICATION POWER SUPPLY... - Page 8 Dimplex product, which is found to be defective due to faulty materials or workmanship within the Guarantee Period, this Dimplex Guarantee will cover repair or - at the discretion of Dimplex – replacement with a functionally equivalent Dimplex product.
- Page 9 You must provide to Dimplex or its authorised agents on request the original receipt as proof of purchase and - if required by Dimplex - proof of delivery. If you are unable to provide this documentation, you will be required to pay for any repair work required.
- Page 10 The Dimplex Guarantee is in addition to your statutory rights as a consumer and your statutory rights are not affected by this Dimplex Guarantee.
