GB70
User Guide & Warranty
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to
follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which
may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not cut power
cords. Do not submerge in water or get wet.
Explosion. Unmonitored, incompatible, or damaged batteries can explode if used with product. Do not leave
product unattended while in use. Do not attempt to jump start a damaged or frozen battery. Use product only
with batteries of recommended voltage. Operate product in well ventilated areas.
Fire. Product is an electrical device that emits heat and is capable of causing burns. Do not cover product.
Do not smoke or use any source of electrical spark or fire when operating product. Keep product away from
combustible materials.
Eye Injury. Wear eye protection when operating product. Batteries can explode and cause flying debris.
Battery acid can cause eye and skin irritation. In the case of contamination of eyes or skin, flush affected area
with running clean water and contact poison control immediately.
Explosive Gases. Working in the vicinity of a lead-acid is dangerous. Batteries generate explosive gases
For more information and
during normal battery operation. To reduce risk of battery explosion, follow all safety information instructions and
support visit:
those published by the battery manufacturer and manufacturer of any equipment intended to be used in the
vicinity of battery. Review wcautionary markings on these products and on engine.
www.no.co/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOOST HD GB70 and is the answer not in the manual?

Questions and answers

Related Manuals for NOCO Genius BOOST HD GB70

Summary of Contents for NOCO Genius BOOST HD GB70

  • Page 1 GB70 User Guide & Warranty DANGER READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE. Electrical Shock.

  • Page 2: Important Safety Warnings

    Important Safety Warnings Proposition 65. WARNING: This product can expose you to chemicals including lead and exhaust fumes, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Personal Precaution. Only use product as intended. Someone should be within range of your voice or close enough to come to your aid in case of emergency.
  • Page 3 injury. Always allow adequate ventilation around power adapters when using them.To ensure maximum battery life, avoid charging your product for more than a week at a time, as overcharging may shorten battery life. Over time, an unused product will discharge and must be recharged before use. Disconnect the product from power sources when not in use. Use the product only for their intended purposes.

  • Page 4: How To Use

    How To Use Step 1: Charge the GB70. Charger Rating: The GB70 comes partially charged out of the box and needs to be fully charged prior to use. Connect the GB70 using the included USB Charge Cable to the USB IN port and the USB car charger. It can also be recharged from any USB powered port, like an AC adapter, car charger, laptop and more.
  • Page 5 Connect the positive (red) HD battery clamp to the positive (POS,P,+) battery terminal. Connect the negative (black) HD battery clamp to the negative (NEG,N,-) battery terminal or vehicle chassis. When disconnecting, disconnect in the reverse sequence, removing the negative first (or positive first for positive ground systems). Step 3: Jump Starting.
  • Page 6 1.) Internal Battery Level Indicates the charge level of the internal battery. 2.) Error LED Illuminates Red if reverse polarity is detected, or blinks “On” and “Off” when the internal battery temperature is too high. 3.) Power Button Push to turn unit "On" & "Off". 4.) Power LED Illuminates White when unit is "On".

  • Page 7: Troubleshooting

    Troubleshooting Error Reason/Solution Error LED: Solid Red Reverse polarity/Reverse the battery connections. Error LED: Blinking Red w/Cables Connected The internal battery is too hot/ Allow the unit to cool. Bring the unit into cooler environment. Properly Boost Light Does Not Come On w/Cables Connected battery is below 2-volts/ Remove all loads, and try again, or use Manual Override Mode.

  • Page 8: Warranty

    Warranty NOCO One (1) Year Limited Warranty. NOCO warrants that this product (the "Product") will be free from defects in material and workmanship for a period of one (1) year from the date of purchase (the "Warranty Period"). For defects reported during the Warranty Period, NOCO will, at its discretion, and subject to NOCO's technical support analysis, either repair or replace defective Products.
  • Page 9 GB70 Brugervejledning og garanti FARE LÆS OG FORSTÅ ALLE SIKKERHEDSINFORMATIONER, FØR DU ANVENDER DETTE PRODUKT. Hvis Dansk du ikke følger disse sikkerhedsanvisninger, kan det resultere i ELEKTRISK STØD, EKSPLOSION, BRAND, som kan resultere i alvorlig skade, død eller ejendomsskade. Elektrisk stød. Produktet er en elektrisk enhed, der kan give stød, og forårsage alvorlig skade. Skær ikke i strømledninger.

  • Page 10: Vigtige Sikkerhedsadvarsler

    Vigtige sikkerhedsadvarsler Forslag 65. Batteriposter, terminaler og tilhørende tilbehør indeholder kemikalier, herunder bly. Disse materialer er kendt for i staten Californien, at forårsage kræft og fødselsdefekter, samt anden reproduktiv skade. Personlig sikkerhedsforanstaltning. Brug kun produktet som anvist. Nogen skal være indenfor rækkevidden af din stemme, eller tæt nok til at komme til din hjælp, i tilfælde af en nødsituation.
  • Page 11 det i stikkontakten. Strømadaptere kan blive varme under normal brug, og langvarig hudkontakt kan forårsage personskade. Sørg altid for tilstrækkelig ventilation omkring strømadapterne, når du bruger dem. For at sikre maksimal batterilevetid, skal du undgå at oplade dit produkt i mere end en uge ad gangen, da overopladning kan forkorte batteriets levetid.
  • Page 12 Sådan bruges det Trin 1: Oplad GB70-enheden. Opladning vurdering: GB70 leveres delvis opladet i kassen, og skal være fuldt opladet før brug. Tilslut GB70 med det medfølgende USB-opladningskabel til USB IN-porten og USB-bil opladeren. Den kan også oplades fra enhver USB-port som en vekselstrømsadapter, biloplader, bærbar pc, m.m.
  • Page 13 Tilslut den positive (røde) HD batteriklemme til den positive (POS, P, +) batteriterminal. Tilslut den negative (sorte) HD-batteriklemme til den negative (NEG, N, -) batteriterminal eller køretøjets chassis. Når du afbryder forbindelsen, skal du frakoble i omvendt rækkefølge, fjerne den negative første (eller positive først for positive jordsystemer). Trin 3: Kabel start Sørg for, at alle køretøjets strømbelastninger (forlygter, radio, klimaanlæg, osv.) er slukket, før du forsøger at starte bilen.
  • Page 14 1.) Internt batteriniveau Angiver opladningsniveauet for det interne batteri. 2.) Fejl LED lyser rødt, hvis omvendt polaritet detekteres, eller blinker "On" og "Off", når den interne batteritemperatur er for høj. 3.) Tryk på Tænd/sluk-knap, for at at tænde for "On" & "Off". 4.) Strøm LED'en Lyser Hvid når enheden er "Tændt"...

  • Page 15: Tekniske Specifikationer

    Fejlfinding Fejl Årsag / Løsning Fejl LED: Fast rød Omvendt polaritet /Slår batteriets tilslutninger tilbage. Fejl LED: Blinker rød med cabler forbundet Det interne batteri er for varmt /Lad enheden køle af. Opbevar enheden i køligere omgivelser. korrekt Boost lys tændes ikke med kabler korrekt Tilsluttet batteri er under 2 volt /Fjern alle belastninger, og prøv igen, eller brug manuel overstyringstilstand.
  • Page 16 Garanti NOCO One (1) års begrænset garanti. NOCO virksomheden ("NOCO") garanterer, at dette produkt ("Produktet") er fri for fejl i materiale og udførelse, i en periode på et (1) år fra købsdatoen ("Garantiperioden"). For mangler, der indberettes i garantiperioden, vil NOCO efter eget skøn og underlagt NOCOs tekniske supportanalyse enten reparere eller udskifte defekte Produkter. Udskiftningsdele og produkter vil blive brugt som nyt eller anvendeligt, sammenlignelige i funktion og ydeevne til den oprindelige del og garanteret for den resterende del af den oprindelige garantiperiode.
