GBX
User Guide & Warranty
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to
follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which
may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not cut
power cords. Do not submerge in water or get wet.
Explosion. Unmonitored, incompatible, or damaged batteries can explode if used with product. Do not
leave product unattended while in use. Do not attempt to jump start a damaged or frozen battery. Use
product only with batteries of recommended voltage. Operate product in well ventilated areas.
Fire. Product is an electrical device that emits heat and is capable of causing burns. Do not cover
product. Do not smoke or use any source of electrical spark or fire when operating product. Keep
product away from combustible materials.
Eye Injury. Wear eye protection when operating product. Batteries can explode and cause flying debris.
Battery acid can cause eye and skin irritation. In the case of contamination of eyes or skin, flush affected
area with running clean water and contact poison control immediately.
For more information and
Explosive Gases. Working in the vicinity of a lead-acid is dangerous. Batteries generate explosive
support visit:
gases during normal battery operation. To reduce risk of battery explosion, follow all safety information
instructions and those published by the battery manufacturer and manufacturer of any equipment
www.no.co/support
intended to be used in the vicinity of battery. Review precautionary markings on these products and on
engine.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for NOCO Genius BOOST X GBX
Summary of Contents for NOCO Genius BOOST X GBX
- Page 1 User Guide & Warranty DANGER READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE. Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not cut power cords.
-
Page 2: Important Safety Warnings
Important Safety Warnings CAUTION: Manual Override Mode disables all safety measures. When used improperly and/or against our recommended use, it may result in injury or death and will void your warranty. Risk of fire, explosion, and burns. Do not disassemble, crush, heat above 60ºC (140ºF) or incinerate. This device is intended for temporary use outdoors and reasonable care should be exercised when using this device in wet conditions. - Page 3 party responsible for compliance could void the user’s authority to operate this device. Accessories. This product is only approved for use with NOCO accessories. NOCO is not responsible for user safety or damage when using accessories not approved by NOCO. Location. Prevent battery acid from coming in contact with the product.
-
Page 4: How To Use
immediately if it comes in contact with liquid or any type of contaminant. Use a soft, lint-free (microfiber) cloth. Avoid getting moisture in openings. Explosive Atmospheres. Obey all signs and instructions. Do not operate product in any area with a potentially explosive atmosphere, including fueling areas or areas which contain chemicals or particles such as grain, dust or metal powders. - Page 5 Fast Charge. Fast Charge: The GBX is equipped with fast charging technology that allows it to be recharged at a rate of up to 60W. A compat- Recharge Time: Charger Rating: ible charger, capable of 60W USB-C Power Delivery 3.0, is required to fully utilize this feature. The fast charge LED 0.8h will illuminate when rate of charge exceeds 15W, indicating USB Power Delivery 3.0 is active.
- Page 6 Step 3: Jump Starting. 1. Make sure all of the vehicle’s power loads (headlights, radio, air conditioning, etc.) are turned off before attempting to jump start the vehicle. 2. Press the power button to begin jump starting, and all LEDs will flash once. If you are properly connected to the battery, the white boost LED will illuminate and the battery charge LEDs will chase.
- Page 7 Interface 1. Power LED Illuminates White when unit is “On”. Will illuminate orange after the 60-second timeout countdown until the clamps are removed from the Car Battery or the GBX is power cycled ‘off’ and back ‘on’ again. 2. Power Button Push to turn unit “on” & “off” or restart boost after 60-second timeout. 3.
-
Page 8: Troubleshooting
Troubleshooting Error Reason/Solution Solid Red Reverse polarity detected. / Reverse the battery connections. Single (1) Flash Short circuit detected on battery clamps. / Remove all loads, reconnect clamps to battery. Double (2) Flash High voltage detected at clamps (the GBX is connected to a voltage system greater than 12V, such as 24V). Triple (3) Flash Bad battery cell detected. -
Page 9: Technical Specifications
Technical Specifications Internal Battery: 31Wh Lithium Ion USB-C (Out): 5V 3A/9V 3A/12V 3A/15V 3A/20V 3A Peak Current Rating: 1250A USB (Output): 5VDC 2.1A Max / 10W Max Operating Temperature: -20°C to +50°C Housing Protection: IP65 (w/Ports Closed) Charging Temperature: 0ºC to +40ºC Cooling: Natural Convection Storage Temperature: -20ºC to +50ºC (avg Temp.) Dimensions (L x W x H): 6.8 x 3.3 x 2.1 Inches... - Page 10 RMA number, and receipt to the Return Location. DO NOT SEND IN PRODUCT WITHOUT FIRST OBTAINING AN RMA FROM NOCO SUPPORT. THE ORIGINAL PURCHASER IS RESPONSIBLE (AND MUST PREPAY) ALL PACKAGING AND TRANSPORTATION COSTS TO SHIP PRODUCTS FOR WARRANTY SERVICE. NOTWITHSTANDING THE ABOVE, THIS HASSLE-FREE WARRANTY IS VOID AND DOES NOT APPLY TO PRODUCTS THAT: (a) are misused, mishandled, subjected to abuse or careless handling, accident, improperly stored, or operated under conditions of extreme voltage, temperature, shock, or vibration beyond NOCO’s recommendations for safe and effective use;...
- Page 11 For more information and support visit: www.no.co/support...
- Page 12 GBX35.09142022A...
