Summary of Contents for ICE Games Go Ballistic
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Warnings Setup Game Play Setup Volume Controls Programming Sensor Test Assembly Service Assembly Diagrams Sensor Array Front Assembly Main Cabinet 11-12 Marquee 13-14 15-30 Wiring Diagrams Main Board Connector Layout REVISION A 7-15-09... -
Page 3: Safety And Warnings
SAFETY AND WARNINGS BEFORE YOU BEGIN WARNING: WHEN INSTALLING THIS GAME, A GROUNDED A.C. RECEPTACLE MUST BE USED. FAILURE TO DO SO COULD RESULT IN INJURY TO YOURSELF OR OTHERS. FAILURE TO USE A GROUNDED RE- CEPTACLE COULD ALSO CAUSE IMPROPER GAME OPERATION, OR DAMAGE TO THE ELECTRONICS. DO NOT DEFEAT OR REMOVE THE GROUNDING PRONG ON THE POWER CORD FOR THE SAME REA- SON AS GIVEN ABOVE. -
Page 4: Game Play
SETUP - INTRODUCTION Game play: The player has five exciting games to choose from when they insert their money to play. In “Wood Chucker”, the player throws at as many wood chucks as possible to score the most points. Beware, as the Wood Chucks fight back and throw logs, axes and stones at you! In “Sweet Shop”... -
Page 6: Programming
SETUP - ASSEMBLY METERS LOCATION The meters are located through the coin door. Both coin and ticket meters can be found there. LOADING TICKETS If during game play the ticket dispenser runs out of tickets, the screen will display “Error Tickets” Af- ter loading tickets into the dispenser, press the ticket reset button found below the dispenser at the game floor. -
Page 7: Service
SERVICE CAUTION This game uses complex electronic components that are very sensitive to static electricity. Observe precau- tions below before handling these electronics. Failure to do so may void the warranty and damage electronic assemblies. Before servicing electronics, turn off AC power to the game. Wait for capacitors to discharge. DO NOT remove any of the components on the main board (e.g. - Page 30 I/O BOARD LAYOUT...
- Page 31 Contacts at SEGA Machine Sales Telephone: +44 (0) 208 391 8090 Fax: +44 (0) 208 391 8099 www.sega-amusements.co.uk SEGA Spares Telephone: +44 (0) 208 391 8060 Fax: +44 (0) 208 391 8096 www.segatotalsolutions.com Customer Services Telephone: +44 (0) 208 391 8065 Fax: +44 (0) 208 391 8096...
