MODEL G0785
WALL-MOUNT DUST COLLECTOR
w/CANISTER FILTER
OWNER'S MANUAL
(For models manufactured since 3/15)
COPYRIGHT © MARCH, 2015 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#BB17317 PRINTED IN TAIWAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G0785 and is the answer not in the manual?

Questions and answers

Related Manuals for Grizzly G0785

Summary of Contents for Grizzly G0785

  • Page 1 OWNER'S MANUAL (For models manufactured since 3/15) COPYRIGHT © MARCH, 2015 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #BB17317 PRINTED IN TAIWAN...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........2 SECTION 5: ACCESSORIES ......21 Contact Info............ 2 SECTION 6: MAINTENANCE ......22 Manual Accuracy ........... 2 Schedule ............22 Identification ........... 3 Lubrication ........... 22 Machine Data Sheet ........4 Cleaning Bags..........22 SECTION 1: SAFETY ........

  • Page 4: Introduction

    Before calling, please write down the Manufacture Date and Serial Number stamped into the machine ID label (see below). This infor- mation helps us determine if updated documenta- tion is available for your machine. Manufacture Date Serial Number Model G0785 (Mfd. Since 3/15)

  • Page 5: Identification

    Identification Safety Wall Paddle Bracket Switch Motor Inlet Filter Cleaning Canister Handle Filter Collection To reduce your risk of serious injury, read this entire manual BEFORE using machine. Model G0785 (Mfd. Since 3/15)

  • Page 6: Machine Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0785 WALL-MOUNT DUST COLLECTOR WITH CANISTER FILTER Product Dimensions: Weight................................62 lbs. Width (side-to-side) x Depth (front-to-back) x Height..............19-1/2 x 22 x 46 in.
  • Page 7 The information contained herein is deemed accurate as of 3/24/2015 and represents our most recent product specifications. Model G0785 PAGE 2 OF 2 Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. Model G0785 (Mfd. Since 3/15)

  • Page 8: Section 1: Safety

    Everyday ery. Never operate under the influence of drugs or eyeglasses are NOT approved safety glasses. alcohol, when tired, or when distracted. Model G0785 (Mfd. Since 3/15)
  • Page 9 Contact our debris. Make sure they are properly installed, Technical Support at (570) 546-9663. undamaged, and working correctly. Model G0785 (Mfd. Since 3/15)

  • Page 10: Additional Safety For Dust Collectors

    Model G0785 (Mfd. Since 3/15)

  • Page 11: Section 2: Power Supply

    Nominal Voltage ..208V, 220V, 230V, 240V meets the specified circuit requirements. Cycle ............60 Hz Phase ........... Single-Phase Power Supply Circuit ......15 Amps Plug/Receptacle ......NEMA 6-15 Model G0785 (Mfd. Since 3/15)
  • Page 12 The plug must only be inserted into a matching receptacle (see following figure) that is properly installed and grounded in accordance with all local codes and ordinances. -10- Model G0785 (Mfd. Since 3/15)

  • Page 13: Voltage Conversion To 240V

    Items Needed • Phillips Head Screwdriver #2 ..... 1 • Electrical Tape ......As Needed Figure 4. Model G0785 rewired to 240V. • Wire Nut (14 AWG x 3) ....... 1 • 6-15 Plug ............ 1 Close and secure motor junction box.

  • Page 14: Section 3: Setup

    Discard immediately. Description • Safety Glasses and Respirator ....1 • Mounting Fasteners ....As Needed • Tape Measure..........1 • Drill w/Bits ........As Needed -12- Model G0785 (Mfd. Since 3/15)

  • Page 15: Inventory

    If you cannot find an item on this list, care- fully check around/inside the machine and packaging materials. Often, these items get lost in packaging materials while unpack- ing or they are pre-installed at the factory. -13- Model G0785 (Mfd. Since 3/15)

  • Page 16: Site Considerations

    Wall Wall 23" Minimum Side View Front View Power Minimum 3" Motor Cooling 59" Air Gap Minimum Wall Keep Area Clear Wall Floor Floor Figure 7. Minimum working clearances. -14- Model G0785 (Mfd. Since 3/15)

  • Page 17: Assembly

    56" Install dust collection bag with bag clamp Minimum (see Figure 8), then connect ducting. Refer to Collection System on next page for grounding requirements. Floor Figure 9. Wall bracket positioning. -15- Model G0785 (Mfd. Since 3/15)

  • Page 18: Collection System

    Ground Wire and plastics. However, the cost of specifically designed flexible duct can vary greatly. Grizzly offers polyethylene and steel flex hose. Figure 12. Ground jumper wire when using plastic blast gates or elbows and metal duct.
  • Page 19 Widebelt Sander (24"_51" double head) . 5 x 4" 7" 1203 Figure 15. Typical ducting sizes and port sizes 8" 1570 for various machines. 9" 1990 10" 2456 Figure 14. Approximate CFM reduction, based on machine dust port size. -17- Model G0785 (Mfd. Since 3/15)

  • Page 20: Power Connection

    Figure 17. Disconnecting power. Turn the machine power switch OFF. Insert the power cord plug into a matching power supply receptacle. The machine is now connected to the power source. Figure 16. Connecting power. -18- Model G0785 (Mfd. Since 3/15)

  • Page 21: Test Run

    The switch disabling feature is not working correctly. This safety feature The motor should run smoothly and without must work properly before proceeding with unusual problems or noises. regular operations. Call Tech Support for help. -19- Model G0785 (Mfd. Since 3/15)

  • Page 22: Section 4: Operations

    SECTION 4: OPERATIONS General To reduce your risk of serious injury, read this Operating your Model G0785 is simple and entire manual BEFORE straightforward. Position the machine near the using machine. dust collector where it will not interfere with the...

  • Page 23: Section 5: Accessories

    To reduce this risk, only install accessories recommended for this machine by Grizzly. NOTICE Refer to our website or latest catalog for additional recommended accessories.

  • Page 24: Section 6: Maintenance

    Any other unsafe condition. it is not an air filter; therefore, we strongly rec- ommend the supplemental aid of a shop air filter such as the Grizzly G0572 or G9956. Air filters Lubrication are designed to collect the smaller dust particles that dust collector bags cannot trap.

  • Page 25: Replacing Bags

    Cleaning Canister Filter Replacement collection bags are available through Grizzly as Model T24268. To clean the canister filter on the Model G0785, move the canister cleaning handle back-and-forth To replace collection bag: to free the trapped dust particles from the filter pleats (see Figure 22).

  • Page 26: Section 7: Service

    2. Fix/replace fan cover; replace loose/damaged fan. 3. Motor bearings at fault. 3. Test by rotating shaft; rotational grinding/loose shaft requires bearing replacement. 4. Tighten impeller (Page 28). 4. Impeller loose on motor shaft. -24- Model G0785 (Mfd. Since 3/15)
  • Page 27 2. Bag clamp is loose or damaged. 2. Retighten bag clamp. -25- Model G0785 (Mfd. Since 3/15)

  • Page 28: Tightening Impeller

    Tighten set screw loosened in Step 3. (see Figure 23) that secure inlet housing cover, then set inlet cover aside. Re-install inlet housing cover. Inlet Housing Cover x 12 Figure 23. Inlet housing cover completely installed. -26- Model G0785 (Mfd. Since 3/15)

  • Page 29: Section 8: Wiring

    Technical Support at (570) 546-9663. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. -27- Model G0785 (Mfd. Since 3/15)

  • Page 30: Wiring Diagram

    200MFD 240 Volt Motor 125VAC Capacitor 30MFD 250VAC Safety Paddle Switch Figure 27. 240V Grizzly Model G8988 junction box. Ground 240 VAC 6-15 Plug (As Recommended) Ground READ ELECTRICAL SAFETY -28- Model G0785 (Mfd. Since 3/15) ON PAGE 27!

  • Page 31: Section 9: Parts

    SECTION 9: PARTS Main Breakdown 10-3 10-2 10-1 10-4 10-5 10-6 10-7 10-8 10-10 10-9 -29- Model G0785 (Mfd. Since 3/15)
  • Page 32 CAP SCREW M6-1 X 30 LH P0785046 AMPUTATION HAZARD LABEL P0785016 BAG CLAMP P0785047 ELECTRICITY LABEL P0785017 CLEANOUT FLAPPER P0785048 MACHINE ID LABEL P0785018 BEARING PLATE P0785049 TOUCH-UP PAINT, GRIZZLY BEIGE P0785019 PHLP HD SCR M5-.8 X 10 -30- Model G0785 (Mfd. Since 3/15)
  • Page 33 Would you recommend Grizzly Industrial to a friend? _____ Yes _____No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times. _____ Yes _____No 10.
  • Page 34 FOLD ALONG DOTTED LINE Place Stamp Here GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE...

  • Page 35: Warranty & Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
