Summary of Contents for Grizzly G0548
- Page 1 2 HP DUST COLLECTOR MODEL G0548 INSTRUCTION MANUAL COPYRIGHT © DECEMBER, 2003 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #5933 PRINTED IN TAIWAN...
- Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
SECTION 7: OPERATION ...22 Test Run...22 General...22 SECTION 8: MAINTENANCE ...23 General...23 Lubrication ...23 Bag and Canister Cleaning ...23 SECTION 9: REFERENCE INFO ...25 G0548 Data Sheet ...26 G0548 Parts Breakdown ...27 H5783 Parts Breakdown ...28 Warranty and Returns ...30... -
Page 4: Section 1: Safety
G0548 2 HP Dust Collector VISITORS... - Page 5 14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance. Follow instructions for lubri- cating and changing accessories. G0548 2 HP Dust Collector 15. USE RECOMMENDED ACCESSORIES. 16. REDUCE THE RISK OF UNINTENTION- LENGTH 17. MANY WOODWORKING TOOLS CAN...
-
Page 6: Additional Safety For Dust Collectors
A dust col- lector should NEVER be used as an air cleaner. For safest use, wear a respirator and use an air cleaner in addition to the dust collector. G0548 2 HP Dust Collector... -
Page 7: Section 2: General Information
Commentary Grizzly Industrial, Inc. is proud to offer the Model G0548 2 HP Dust Collector. This machine is part of Grizzly’s growing family of fine machinery. When used according to the guidelines stated in this manual, you can expect years of trouble-free, enjoyable operation. -
Page 8: Section 3: Circuit Requirements
SECTION 3: CIRCUIT REQUIREMENTS Amperage Draw The Model G0548 features a single phase 220V 2 HP motor. Amperage Draw 220V ... 12 Amps Circuit Breaker Use the following guidelines when choosing a cir- cuit breaker (circuit breakers rated any higher are... -
Page 9: Grounding
The outlet must be properly installed and grounded in accor- dance with all local codes and ordinances. G0548 2 HP Dust Collector Circuit Capacity Always check to see if the wires in your circuit are capable of handling the amperage draw from your machine, as well as any other machines that could be operating on the same circuit. -
Page 10: Section 4: Machine Features
SECTION 4: MACHINE FEATURES Figure 2. Main view of machine features. Canister Filter Cleaning Handle Canister Filter 6" Inlet with Three 4" Ports Clear Collection Bag G0548 2 HP Dust Collector... -
Page 11: Section 5: Set Up
Wear safety glasses dur- ing the entire set up process! The Model G0548 is a heavy machine (165 lbs. shipping NOT over-exert yourself while unpacking or mov- ing your machine—get assistance. - Page 12 (e.g. a nut or a washer), we would be glad to replace them, or, for the sake of expedi- ency, replacements can be obtained at your local hardware store. Figure 4. Main box items. G0548 2 HP Dust Collector...
-
Page 13: Hardware Recognition Chart
Hardware Recognition Chart G0548 2 HP Dust Collector -11-... -
Page 14: Clean Up
-12- Site Considerations Floor Load The Model G0548 weighs 145 lbs and has a base footprint of 31 ⁄ " x 37 ⁄ ". Most commercial floors are suitable for the machine. Some residential floors may require additional reinforcement to support both the machine and operator. -
Page 15: Base
Secure the casters into the mounting brack- ets under the base with the flange bolts (Figure 7). Figure 7. Caster installed on the base mounting bracket. G0548 2 HP Dust Collector Motor and Impeller Components and Hardware Needed: Base ...1 Motor and Impeller ...1 Flange Bolts ⁄... -
Page 16: Outlet
To install the canister support brace: Place the canister support over the holes on the base edge (Figure 11). Figure 11. Canister support attached to base. Secure the canister support in place with the flange bolts. ⁄ "...2 G0548 2 HP Dust Collector... -
Page 17: Collector
8 flange bolts, (Figure 12). Figure 12. Collector installed. Attach the canister support to the side of the collector with the 2 remaining flange bolts. G0548 2 HP Dust Collector Canister Filter Components and Hardware Needed: Canister Filter ...1 Canister Filter Cleaning Handle ...1 Belt Clamp ...1... -
Page 18: Collection Bag
Hook the clear collection bag on the hooks around the bottom of the collector. (Figure 18). Collector Hooks Figure 18. Trimmed foam strip and collector hook locations. G0548 2 HP Dust Collector... -
Page 19: Inlet
Tighten the metal belt clamp around the nar- row foam strip to seal and secure the lower collection bag (Figure 19). Figure 19. Lower collection bag installed. G0548 2 HP Dust Collector Inlet Components and Hardware Needed: 6" Inlet with Three 4" Ports ...1... -
Page 20: Section 6: Collection System
SECTION 6: COLLECTION SYSTEM General The Model G0548 can be operated as either a stationary or a mobile unit. There are advantages and disadvantages to both set-ups. The advan- tage of the mobile system is eliminating the cost of many ducts and fittings. On the other hand, the stationary system is more versatile and conve- nient. -
Page 21: System Grounding
However, the cost of specifically designed flexible duct can vary greatly. Grizzly offers polyethylene hose which is well suited for the removal of particulate matter, especially saw- dust, since it is durable and completely flexible. - Page 22 23. Ensure that each machine is continuously grounded to the grounding terminal in your elec- tric service panel. Plastic Blast Gate Flex-Hose Metal Duct Internal Ground Wire Figure 23. Flex-hose grounded to machine. Ground Screw External Ground Wire G0548 2 HP Dust Collector...
-
Page 23: Design Suggestions
The simpler the system, the more efficient and less costly it will be. G0548 2 HP Dust Collector The best way to plan your new system is to draw a bird’s eye view (as shown in Figure 24) of your... -
Page 24: Section 7: Operation
Operating your Model G0548 is simple and straightforward. Blast gates located at each of the machines controls the air flow from the wood- working machine to the dust collector. If a... -
Page 25: Section 8: Maintenance
General Regular periodic maintenance on your Model G0548 Dust Collector will ensure its optimum per- formance. Make a habit of inspecting your machine each time you use it. Check for the fol- lowing conditions and repair or replace when nec- essary: Loose mounting bolts. - Page 26 Install a new collection bag. -24- While the Model G0548 excels at collecting the majority of wood dust produced by your machines, it is not an air filter; therefore, we strongly recommend the supplemental aid of a shop air filter such as the Grizzly G5955 or G9956.
-
Page 27: Section 9: Reference Info
Grizzly Service Department. Trained ser- vice technicians will be glad to help you. If you have any comments regarding this manual, please write to Grizzly at the address below: Grizzly Industrial, Inc. Technical Documentation P.O. Box 2069... -
Page 28: G0548 Data Sheet
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 MODEL G0548 2 HP DUST COLLECTOR Design Type ...Single Stage Floor Model Overall Dimensions: Base ...21 Height ...78" Shipping Weight ...165 lbs. Net Weight ...145 lbs. -
Page 29: G0548 Parts Breakdown
G0548 Dust Collector Parts Motor Components 17-1 17-3 17-2 17-4 17-5 G0548 2 HP Dust Collector 29-1 A IT -27-... -
Page 30: H5783 Parts Breakdown
H5783 Canister Filter Parts -28- G0548 2 HP Dust Collector... - Page 31 READ MANUAL LABEL PLABEL-11 SAFETY GLASSES LABEL PLABEL-39 RESPIRATOR LABEL P0548039 NO HAND IN INLET LABEL PLABEL-14 ELECTRICITY LABEL G0548 2 HP Dust Collector H5783 Parts List PART # DESCRIPTION PH5783001 HANDLE PB83M HEX BOLT M6-1 X 16 PH5783003 CANISTER FILTER...
-
Page 32: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
Page 33: Warranty Card
Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Industrial to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:__________________________________________________... - Page 34 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
