Summary of Contents for Vivosun AeroLight SE
- Page 1 USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS Safety Information Key Features Product Contents Spectrum Dimensions Specifications Installation Application Warranty Information... -
Page 4: Safety Information
SAFETY INFORMATION Please read the following information carefully before use. Failure to follow these safety instructions may result in serious injury and will release VIVOSUN of all liability and void all product warranties. IMPORTANT SAFETY INFORMATION: Handling: Set up the AeroLight in an operating environment that allows for adequate air circulation. - Page 5 VIVOSUN's instructions and express permission will not affect your existing warranty. However, if you disassemble the light or install add-ons inside without express permission from VIVOSUN, you run the risk of damaging your light in a fashion that is not covered by the limited warranty.
-
Page 6: Key Features
KEY FEATURES UNIFORM LIGHT & AIR 2-IN-1 GROW LIGHT BETTER CIRCULATION Patented grow light design With the central placement of Creative hollow light design with integrated highly the fan you have better air, and wind guide provide reliable circulation fan. circulation, and humidity. -
Page 7: Product Contents
PRODUCT CONTENTS Power Cord RJ45 Network Cable 100W LED Light x 1pc x 1pc x 1pc Rope Hanger Wire Ropes x 2pcs x 2pcs x 1pc... -
Page 8: Spectrum
SPECTRUM The AeroLight SE is a full-spectrum device, covering all stages of plant growth. Wave length (nm) -
Page 9: Dimensions
DIMENSIONS 4.5cm/1.8in 33cm/13.0in Top View Side View... -
Page 10: Specifications
2835 White with 660nm ETL & FCC & CE Light Source Certifications Deep Red & 730nm Far Red 20%-100%/OFF (via Grow Dimming Warranty 3-Year Standard Warranty Hub and VIVOSUN app) Full-spectrum Spectrum Bearing Dual Ball Bearing Sunlike Lighting Rated Input Power 100W/120-240V... -
Page 11: Installation
INSTALLATION Attach the wire hangers to the frame of the AeroLight SE. Next, clip the carabiners of the rope hangers to the wire hangers. Finally, wrap the opposite end of the rope hangers around a crossbar and clip the carabiner to its respective rope. Adjust the height of your grow light by pressing the buttons on the rope hangers and lifting until you find the correct height for your light. - Page 12 INSTALLATION Search "VIVOSUN" in the Apple App Store or in the Google Play Store to download the VIVOSUN App. With the VIVOSUN App, you can check and control your GrowHub from anywhere in the world—whether you are on your couch, visiting your family, or traveling abroad.
- Page 13 INSTALLATION E25 Installation Insert E25 to the type C port of AeroLight. E25 will enter WiFi configuration.
- Page 14 INSTALLATION WiFi Configuration During WiFi configuration, the Green LED will flash fast. Then follow the WiFi configuration process on the Vivosun APP Step 1: Step 2: Searching for nearby devices. Make sure your device has entered pairing mode. Wi-Fi Password...
- Page 15 INSTALLATION Step 3: Step 4:...
- Page 16 INSTALLATION After WiFi configuration success, the green LED stops flashing and goes off. If E25 is offline (i.e., no Wi-Fi connection or you do not have internet access), the green LED will flash slowly. It will continue flashing until E25 has a Wi-Fi connection again. Status Indicator Quick press the button.
- Page 17 Each light needs to connect the AC power separately and the GrowHub controller only need to connect to an AeroLight to run. Please see the VIVOSUN GrowHub controller E42 manual for information about light control and more if connected to E42.
-
Page 18: Application
APPLICATION SUGGESTED HANGING DISTANCE & SUGGESTED LIGHTING TIME Distance Time Stage Inch (In.) Centimeter (cm.) 18 Hours ON Germination 24-30 61-76 Seeding 24-30 61-76 16 Hours ON 18-24 46-61 18 Hours ON Flower 12-18 30-46 12 Hours ON Note: This suggestion is for reference only, and can be freely adjusted according to the actual situation. -
Page 19: Warranty Information
WARRANTY INFORMATION WARRANTY TERMS We offer a 3-year warranty against manufacturing defects for all of our products from the date of purchase. If you need warranty assistance, please contact us as soon as possible. The warranty does not cover damage due to high moisture levels, water damage, power surges, improper hanging/mounting, improper use, dust build-up, or users' unauthorized modifications.
