Summary of Contents for Vivosun AeroLight SE
- Page 1 USER MANUAL...
- Page 2 At Vivosun, quality craftsmanship and innovation are at the core of every product we create. Should you require further support or wish to share any suggestions, please don't hesitate to contact us.
- Page 3 PRODUCTS INCLUDED IN THIS MANUAL: Product AeroLight A100 SE VSA100SE AeroLight A150 SE VSA150SE AeroLight AW200 SE VSA200SE AeroLight AW400 SE VSAW400SE...
-
Page 4: Table Of Contents
CONTENTS Key Features Product Contents Smart Grow System Spectrum Dimensions Specifications Installation Application Warranty Information FCC ID Statement Warning... -
Page 5: Key Features
KEY FEATURES VSA100SE/VSA150SE UNIFORM LIGHT & AIR 2 IN 1 GROW LIGHT BETTER CIRCULATION Patented grow light design Strategically placed central fan Innovative hollow light design with integrated highly promotes exceptional air and integrated wind guide e icient circulation fan. circulation, ensuring optimal ensure uniform light levels and proper humidity... - Page 6 KEY FEATURES VSA200SE/VSAW400SE UNIFORM LIGHT & AIR 2 IN 1 GROW LIGHT BETTER CIRCULATION Patented grow light design With the central placement of Creative light design and wind with integrated highly the fan you have better air, guide provide uniform light reliable circulation fan.
-
Page 7: Product Contents
PRODUCT CONTENTS VSA100SE/VSA150SE Power Cord RJ45 Network Cable LED Light x 1pc x 1pc x 1pc Rope Hanger Wire Ropes x 2pcs x 2pcs... - Page 8 PRODUCT CONTENTS VSA200SE/VSAW400SE LED Light Power Cord RJ45 Network Cable x 1pc x 1pc x 1pc Rope Hanger Wire Ropes x 2pcs x 2pcs...
-
Page 9: Smart Grow System
Control devices via Wi-Fi or Bluetooth Vivosun App GrowHub GrowHub E42A/E25 A10/A22 GrowHub easily monitors and Power devices remotely controls from a single screen via GrowHub’s smart plugs Connect Devices via GrowHub & Mobile App... -
Page 10: Spectrum
SPECTRUM The AeroLight SE is a full-spectrum device, covering all stages of plant growth. Wavelength (nm) -
Page 11: Dimensions
DIMENSIONS VSA100SE 4.5cm/1.8in 33cm/13.0in Top View Side View... - Page 12 DIMENSIONS VSA150SE 5.3cm/2.1in 33cm/13.0in Top View Side View...
- Page 13 DIMENSIONS VSA200SE 66cm/26.0in Top View Side View...
- Page 14 DIMENSIONS VSAW400SE 5.6cm/2.2in 67cm/26.4in Top View Side View...
-
Page 15: Specifications
White with 660nm Deep Red & 730nm Far Red Spectrum Full spectrum; 380nm-780nm, rich 660nm Light Light 120° Adjustable Distribution Dimming 20%-100%/OFF (via GrowHub and VIVOSUN app) Bearing Dual Ball Bearing Speed 2200 RPM. Airflow 84 CFM 168 CFM Noise Level... -
Page 16: Installation
INSTALLATION STEP 1 Attach the wire ropes to the frame of the AeroLight SE. Next, clip the carabiners of the rope hangers to the wire ropes. - Page 17 INSTALLATION STEP 2 Loop the other end of the rope hangers around the crossbeam as shown in the diagram. Lock the carabiners to the rope to secure the grow light to the pole. STEP 3 Adjust the height of your grow light by pressing the buttons on the rope hangers and lifting until you find the correct height for your grown light .
- Page 18 INSTALLATION STEP 4 For VSA200SE & VSAW400SE, please unfold the light board and adjust to an appropriate angle.
- Page 19 INSTALLATION VSA200SE/VSAW400SE ADJUSTING THE LIGHT DISTRIBUTION Adjust the angle of the light board on the side to change the light distribution for larger coverage or higher light intensity for di erent grow stages. STANDARD Standard light coverage and uniformity. WIDTH Larger light coverage with more light for plants on the sides of your lights through improved coverage area.
-
Page 20: Application
APPLICATION SUGGESTED HANGING DISTANCE & LIGHTING TIME Product Seedling Early Flower Late Flower PPFD Target 150-250 300-500 500-700 700-1000 Tent Size Time Distance 24" 18" 12" 12" VSA100SE 2'x2' Dimming 100% Level Distance 24" 18" 14" 14" VSA150SE 2'x2' Dimming 100% Level Distance... -
Page 21: Warranty Information
WARRANTY INFORMATION VIVOSUN provides a 3-year warranty against defects on all AeroLight SE products purchased directly from us or through our authorized dealers. This policy serves as our commitment to promptly address any manufacturing defects or premature breakage that may occur during normal use of our products. -
Page 22: Fcc Id Statement
FCC ID STATEMENT The GrowHub E25 controller complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 23: Warning
WARNING ● This appliance can be used by children aged 8 years and above, as well as by individuals with reduced physical, sensory, or mental capabilities, or those lacking experience and knowledge, provided they have been supervised or instructed on the safe use of the appliance and understand the associated hazards. ●... - Page 24 AVERTISSEMENT ● L'appareil peut être utilisé par des enfants de 8 ans et plus, ainsi que par des personnes ayant des capacités physiques, sensorielles ou mentales réduites, ou un manque d'expérience et de connaissances, à condition qu'elles soient sous surveillance ou qu'elles aient reçu des instructions concernant l'utilisation sécurisée de l'appareil et qu'elles comprennent les dangers associés.
- Page 25 WARNUNG ● Das Gerät kann von Kindern ab 8 Jahren sowie von Personen mit eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten oder mangelnder Erfahrung und Wissen verwendet werden, sofern sie unter Aufsicht stehen oder Anweisungen zum sicheren Gebrauch des Geräts erhalten haben und die damit verbundenen Gefahren verstehen.
- Page 26 AVVERTENZA ● L'apparecchio può essere utilizzato da bambini di 8 anni e più, nonché da persone con capacità fisiche, sensoriali o mentali ridotte o mancanza di esperienza e conoscenza, se sono sotto supervisione o hanno ricevuto istruzioni sull'uso sicuro dell'apparecchio e comprendono i pericoli associati. ●...
- Page 27 ADVERTENCIA ● El aparato puede ser utilizado por niños de 8 años en adelante, así como por personas con capacidades físicas, sensoriales o mentales reducidas, o con falta de experiencia y conocimientos, siempre que estén bajo supervisión o hayan recibido instrucciones sobre el uso seguro del aparato y comprendan los riesgos involucrados. ●...
- Page 28 WAARSCHUWING ● Het apparaat kan worden gebruikt door kinderen van 8 jaar en ouder en door personen met verminderde fysieke, zintuiglijke of mentale capaciteiten, of gebrek aan ervaring en kennis, mits zij toezicht of instructies hebben ontvangen over het veilige gebruik van het apparaat en de bijbehorende risico's begrijpen. ●...
- Page 29 VAROVÁNÍ ● Toto zařízení mohou používat děti starší 8 let a osoby se sníženými fyzickými, smyslovými nebo duševními schopnostmi nebo osoby bez zkušeností a znalostí, pokud byly pod dohledem nebo byly poučeny o bezpečném používání zařízení a rozumí souvisejícím rizikům. ●...
- Page 30 OSTRZEŻENIE ● To urządzenie może być używane przez dzieci w wieku 8 lat i starsze oraz przez osoby z ograniczonymi możliwościami fizycznymi, sensorycznymi lub umysłowymi lub brakującym doświadczeniem i wiedzą, pod warunkiem, że są nadzorowane lub poinstruowane o bezpiecznym użytkowaniu urządzenia i rozumieją związane z nim zagrożenia. ●...
- Page 31 VARNING ● Denna apparat kan användas av barn från 8 år och uppåt, samt av personer med nedsatta fysiska, sensoriska eller mentala förmågor, eller de som saknar erfarenhet och kunskap, förutsatt att de har övervakat eller instruerats om hur man använder apparaten på ett säkert sätt och förstår de tillhörande riskerna. ●...
