- Page 1 USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS Key Features Product Contents Safety Information Spectrum Dimensions Specifications Specifications Fan Application Installation Options Warranty Information... -
Page 4: Key Features
KEY FEATURES 2-IN-1 GROW LIGHT BETTER CIRCULATION UNIFORM LIGHT Patented grow light design With the central placement of Creative hollow light design with integrated highly the fan you have better air, and wind guide provide reliable circulation fan. circulation, and humidity uniform light and wind on plants’... -
Page 5: Product Contents
PRODUCT CONTENTS 100W LED Light Rope Hanger Hook x 2pcs x 1pc x 2pcs Power Cord RJ45 Network Cable x 1pc x 1pc... -
Page 6: Safety Information
Never allow objects to obstruct or enter the ventilation openings. For Indoor Use Only: The AeroLight is not waterproof; protect your lights from moisture. Do not expose to dripping water or spray. Do not expose the lights to physical harm such as impacts or severe weather conditions. - Page 7 SAFETY INFORMATION Cleaning: When cleaning the outside of your light and its components, first shut down your light, then unplug the power cord. Then dampen a clean, soft, lint-free cloth to wipe the light down. Avoid allowing any moisture in any openings. DO NOT use water or any detergent to clean this product.
-
Page 8: Spectrum
SPECTRUM The AeroLight is spectrum-tunable and provides 3 spectral ranges for different growth stages (programmed via the GrowHub). SEEDLING SPECTRUM: More blue light promotes rooting and prevents overstretching. VEG SPECTRUM: Balanced spectrum for leaves growing. FLOWER SPECTRUM: Rich in 660nm red and 730nm far-red light promote budding &... -
Page 9: Dimensions
DIMENSIONS SIDE VIEW 4.5cm/1.8in 33cm/13.0in... -
Page 10: Specifications
SPECIFICATIONS Light Source Samsung 301B include UVA, Far Red Dimming 20%-100%/OFF (via GrowHub and VIVOSUN app) Full spectrum; 380nm-780nm, rich 660nm , Seedling/Veg/Flower spectrum tunable Spectrum (via GrowHub and VIVOSUN app) Input Power 100W/120-240V Frequency 50-60HZ Fix Dimensions 33*33*4.5CM (L x W x H) Weight 2.6 kg... -
Page 11: Specifications Fan
SPECIFICATIONS (FAN) Bearing Dual Ball Bearing Rated Voltage 12 VDC Current 0.18 A (MAX~ 0.27A） Power 2.16 W (MAX~3.24 W) Speed 2200 RPM. (REF.) Speed Adjustment 4 levels, OFF to Max Air Flow 73.84 CFM Air Pressure 50.56 Pa Acoustical Noise 35.5 dB-A Insulation Type UL: Class A... -
Page 12: Application
APPLICATION SUGGESTED HANGING DISTANCE & SUGGESTED LIGHTING TIME Distance Stage Time Inch (In.) Centimeter (cm.) Germination 24-30 61-76 18 Hours ON Seeding 61-76 16 Hours ON 18-24 46-61 18 Hours ON Flower 12-18 30-46 12 Hours ON Note: This suggestion is for reference only, and can be freely adjusted according to the actual situation. Set the LED power on high and place the light further away from your plants to cover a wider area, or set the LED at a lower power and place the light closer to your plants for less coverage but a more eco-friendly solution. -
Page 13: Installation Options
INSTALLATION OPTIONS 1. Pass the rope hangers through the LED's hooks, and then fix the other end of rope hangers to the ceiling. 2.Remove the hooks from the LEDs, then fit them onto the ceiling bracket before installing them back onto the LED. - Page 14 ON/OFF cycle setting. Each light needs to connect the AC power separately and the GrowHub controller only need to connect to an AeroLight to run. Please see the VIVOSUN GrowHub controller manual for information about light control and more.
-
Page 15: Warranty Information
WARRANTY INFORMATION WARRANTY TERMS 1. We offer a 3-year warranty against manufacturing defects for all of our products from the date of purchase. If you need warranty assistance, please contact us as soon as possible. 2. The warranty does not cover damage due to high moisture levels, water damage, power surges, improper hanging/mounting, improper use, dust build-up, or users’...
