Summary of Contents for Vivosun AeroZesh
- Page 1 USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS Key Features Product Contents Dimension Specifications Application Installation Maintenance Safety Information Warranty Information... -
Page 4: Key Features
PWM provide low noise conditions for your stator blades in high static and energy saving. AeroZesh via the VIVOSUN pressure. GrowHub and App remotely. MULTIPLE MODES DUAL BALL BEARINGS PWM TUNING Dual ball bearings in motor... -
Page 5: Product Contents
PRODUCT CONTENTS Duct Fan System Type C Extension Cable x 1pc x 1pc Duct Fan Screw Set Wall Anchor x 4pcs x 4pcs... - Page 6 PRODUCT CONTENTS Buckle Intake Flange Stator Blades Exhaust Flange EC Motor Fan Unit Wind Circle...
-
Page 7: Dimension
DIMENSION Series No. Part Quantity ① Flange ② Fan Unit ③ Impeller ④ Terminal Box ⑤ Buckle Long hole Unit: mm ΦB Model No. VSV-AZS4 VSV-AZS6 VSV-AZS8 ΦB Φ98 Φ147 Φ195 10x5 10x5 10x5 Long hole... -
Page 8: Specifications
SPECIFICATIONS VSV-AZS4 VSV-AZS6 VSV-AZS8 Size 4 inch 6 inch 8 inch Input 110-120V/60Hz 110-120V/60Hz 110-120V/60Hz Average Power 35 W 70 W Usage Airflow 208 CFM 405 CFM 810 CFM Noise 39 dB(A) 45 dB(A) 50 dB(A) Fan Speed 3000RPM 3100RPM 2700RPM Electric Motor EC-motor... -
Page 9: Application
APPLICATION AeroZesh can be used as an exhaust fan or an intake fan for your grow space, and each has different setup position for optimal ventilation. Exhaust fan: Hung or mounted on the highest opposite corner inside your grow space. Airflow arrow points away from your grow space. -
Page 10: Installation
INSTALLATION 1. MOUNTING AS AN INTAKE FAN STEP 1 Unscrew and loosen the buckles on the fan unit. STEP 2 Remove the fan unit from the flange bracket. Fan Unit Flange Flange... - Page 11 INSTALLATION STEP 3 Drill four holes and fixed the two flange brackets on the desired position of a wood support or stud with four wood screws. For mounting on a surface other than wood, fix the wall anchors in the holes before screwing the wood screws to fix the flange brackets.
- Page 12 INSTALLATION STEP 5 Put the buckles back on the fan unit and fix with Buckle screws.
- Page 13 INSTALLATION 2. HANGING AS AN EXHAUST FAN A. HANGING UPWARD STEP 1 Use two rope hangers loop around the flanges as showed in picture, lock the hooks on the ropes to secure the fan. STEP 2 Loop the other end of two rope hangers around a pole as showed in picture, lock the hooks on the ropes to secure on the pole.
- Page 14 INSTALLATION B. HANGING DOWNWARD Loop the two rope hangers around a pole and the flange brackets of the fan. Secure two hooks on the same rope for both rope hangers. Press the yellow button on the rope hangers and pull the ropes to adjust the height of the fan.
- Page 15 INSTALLATION 3. CONNECTING TO THE VIVOSUN GROWHUB CONTROLLER Use a type C extension cord to connect an AeroZesh to a GrowHub controller(A). A GrowHub controller has two type C ports to control two AeroZesh(B).
-
Page 16: Maintenance
MAINTENANCE Regular cleaning each year is suggested. Make sure to turn off power before cleaning. STEP 1 Unscrew and loosen the buckles on the fan unit and remove it from the flange brackets. STEP 2 Use a damp cloth to clean the fan blades and the impeller. -
Page 17: Safety Information
SAFETY INFORMATION Please read the manual carefully and follow the instructions before installing and operating the fan. The input voltage of this fan is 110Vac~120Vac. DO NOT use the fan under higher input voltages. The air transferred shall not be flammable, explosive, corrosive. The environment temperature shall not exceed 40°C. -
Page 18: Warranty Information
In the USA, if any AeroZesh duct fan ceases working within 30 days of use, you can choose: Exchange: We will email you a pre-paid return label. Please ship the light back to our USA warranty center and a replacement will be sent to you free of charge as soon as we receive the defective product.
