Summary of Contents for Vivosun AeroLight SE
- Page 1 USER MANUAL...
- Page 2 At Vivosun, quality craftsmanship and innovation are at the core of every product we create. Should you require further support or wish to share any suggestions, please don't hesitate to contact us.
- Page 3 PRODUCTS INCLUDED IN THIS MANUAL: Product AeroLight A100 SE VSA100SE AeroLight A150 SE VSA150SE AeroLight AW200 SE VSAW200SE AeroLight AW400 SE VSAW400SE AeroLight A100 SE (with E25) VSA100SE-E25 AeroLight A150 SE (with E25) VSA150SE-E25 AeroLight AW200 SE (with E25) VSAW200SE-E25 AeroLight AW400 SE (with E25) VSAW400SE-E25...
-
Page 4: Table Of Contents
CONTENTS Safety Information Key Features Product Contents Smart Grow System Spectrum Dimensions Specifications Installation Application Warranty Information FCC ID Statement... -
Page 5: Safety Information
SAFETY INFORMATION Please read the following information carefully before use. Failure to follow these safety instructions may result in serious injury and will release VIVOSUN of all liability and void all product warranties. IMPORTANT SAFETY INFORMATION: Handling: Set up the AeroLight in an operating environment that allows for adequate air circulation. - Page 6 VIVOSUN's instructions and express permission will not a ect your existing warranty. However, if you disassemble the light or install add-ons inside without express permission from VIVOSUN, you run the risk of damaging your light in a manner that is not covered by the warranty.
-
Page 7: Key Features
KEY FEATURES VSA100SE/VSA150SE 2 IN 1 GROW LIGHT BETTER CIRCULATION UNIFORM LIGHT & AIR Patented grow light design Strategically placed central fan Innovative hollow light design with integrated highly promotes exceptional air and integrated wind guide e icient circulation fan. circulation, ensuring optimal ensure uniform light levels and proper humidity... - Page 8 KEY FEATURES VSAW200SE/VSAW400SE 2 IN 1 GROW LIGHT BETTER CIRCULATION UNIFORM LIGHT & AIR Patented grow light design With the central placement of Creative light design and wind with integrated highly the fan you have better air, guide provide uniform light reliable circulation fan.
-
Page 9: Product Contents
PRODUCT CONTENTS VSA100SE/VSA150SE Power Cord RJ45 Network Cable LED Light x 1pc x 1pc x 1pc GrowHub E25 Rope Hanger Wire Ropes Controller* x 2pcs x 2pcs x 1pc * GrowHub E25 is included in VSA100SE E25/VSA150SE E25... - Page 10 PRODUCT CONTENTS VSAW200SE/VSAW400SE LED Light Power Cord RJ45 Network Cable x 1pc x 1pc x 1pc GrowHub E25 Rope Hanger Wire Ropes Controller* x 2pcs x 2pcs x 1pc *GrowHub E25 is included in VSAW200SE E25/VSAW400SE E25...
-
Page 11: Smart Grow System
E42A Vivosun GrowHub... -
Page 12: Spectrum
SPECTRUM The AeroLight SE is a full-spectrum device, covering all stages of plant growth. Wavelength (nm) -
Page 13: Dimensions
DIMENSIONS VSA100SE 4.5cm/1.8in 33cm/13.0in Top View Side View... - Page 14 DIMENSIONS VSA150SE 5.3cm/2.1in 33cm/13.0in Top View Side View...
- Page 15 DIMENSIONS VSAW200SE 66cm/26.0in Top View Side View...
- Page 16 DIMENSIONS VSAW400SE 5.6cm/2.2in 67cm/26.4in Top View Side View...
-
Page 17: Specifications
Samsung 2835 White with 660nm Deep Red & 730nm Far Red Spectrum Full spectrum; 380nm-780nm, rich 660nm Light Light 120° Adjustable Distribution Dimming 20%-100%/OFF (via GrowHub and VIVOSUN app) Bearing Dual Ball Bearing Speed 2200 RPM. Airflow 84 CFM 168 CFM Noise Level... -
Page 18: Installation
INSTALLATION STEP 1 Attach the wire ropes to the frame of the AeroLight SE. Next, clip the carabiners of the rope hangers to the wire ropes. - Page 19 INSTALLATION STEP 2 Loop the other end of the rope hangers around the crossbeam as shown in the diagram. Lock the carabiners to the rope to secure the grow light to the pole. STEP 3 Adjust the height of your grow light by pressing the buttons on the rope hangers and lifting until you find the correct height for your grown light .
- Page 20 INSTALLATION STEP 4 For VSAW200SE & VSAW400SE, please unfold the light board and adjust to an appropriate angle.
- Page 21 INSTALLATION VSAW200SE/VSAW400SE ADJUSTING THE LIGHT DISTRIBUTION Adjust the angle of the light board on the side to change the light distribution for larger coverage or higher light intensity for di erent grow stages. STANDARD Standard light coverage and uniformity. WIDTH Larger light coverage with more light for plants on the sides of your lights through improved coverage area.
- Page 22 INSTALLATION Search "VIVOSUN" in the Apple App Store or in the Google Play Store to download the VIVOSUN App. With the VIVOSUN App, you can check and control your AeroLight SE from anywhere in the world—whether you are on your couch, visiting your family, or traveling abroad.
- Page 23 INSTALLATION INSTALLATION GrowHub E25 Installation Insert E25 to the type C port of AeroLight SE. E25 will enter Wi-Fi configuration mode automatically.
- Page 24 During Wi-Fi configuration, the Green LED will flash quickly. Follow the Wi-Fi configuration instructions on the VIVOSUN App – Make sure there is a 2.4G Wi-Fi connection and that Bluetooth is enabled on your phone. The controller is not compatible with a 5G Wi-Fi connection.
- Page 25 INSTALLATION Step 3: Step 4:...
- Page 26 INSTALLATION After Wi-Fi has been successfully configured, the green LED will stop flashing. A slowly flashing green LED indicates the E25 controller is o line. This means it is not connected to a Wi-Fi network or there is no internet access. The green LED will continue flashing slowly until a Wi-Fi connection is established.
- Page 27 INSTALLATION CONNECTION OF CONTROLLER AND MULTIPLE LIGHTS Connect multiple AeroLight SE lights with RJ45 cables, and the first light to a VIVOSUN GrowHub E42/E25 controller to control all the lights for dimming, and ON/OFF cycle setting. Each light needs to connect to the AC power separately and the GrowHub controller only needs to connect to one AeroLight SE to run.
-
Page 28: Application
APPLICATION SUGGESTED HANGING DISTANCE & LIGHTING TIME Product Seedling Early Flower Late Flower PPFD Target 150-250 300-500 500-700 700-1000 Tent Size Time Distance 24" 18" 12" 12" VSA100SE 2'x2' Dimming 100% Level Distance 24" 18" 14" 14" VSA150SE 2'x2' Dimming 100% Level Distance... -
Page 29: Warranty Information
WARRANTY INFORMATION VIVOSUN provides a 3-year warranty against defects on all AeroLight SE products purchased directly from us or through our authorized dealers. This policy serves as our commitment to promptly address any manufacturing defects or premature breakage that may occur during normal use of our products. -
Page 30: Fcc Id Statement
FCC ID STATEMENT The GrowHub E25 controller complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
