Specifications

Monitor
Specifications
Diagonal:
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Analog/Digital:
Display Colors
Horizontal:
Synchronization Range :
Landscape:
Resolutions Supported
(Analog/Digital)
Landscape: Horizontal:
Active Display
Area
Portrait: Horizontal:
Power Supply
Current Rating
Landscape:
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature:
Humidity:
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear
* 1
choppy or lines may appear to be bold. This is normal and necessary for all current flat panel technologies when displaying
non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to expand
resolutions to full screen, an interpolation of the resolution must be done. When the interpolated resolution is not an exact
multiple of the native resolution, the mathematical interpolation necessary may cause some lines to appear thicker than others.
The number of colors that can be displayed decreases.
* 2
NOTE: Technical specifications are subject to change without notice.
CN912A/LCD1810X/78135311
MultiSync LCD
®
Monitor
18.1 inch
18.1 inch
Landscape: 1280 x 1024
Portrait: 1024 x 1280
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positve) 0.7 Vp-p and sync.
Negative 0.3 Vp-p
16,777,216
31 kHz to 82 kHz
Vertical: 56.0 Hz to 85 Hz
720 x 400 : VGA text
* 1
640 x 480 @ 60Hz to 85Hz
* 1
800 x 600 @ 56Hz to 85Hz
* 1
832 x 624 * 1 @ 75Hz
1024 x 768 * 1 @ 60Hz to 85Hz
1152 x 900 * 1 * 2 @ 66Hz (SUN)
1280 x 960 1 2 @ 60Hz to 75Hz
* *
1280 x 1024 @ 60Hz to 75Hz .................. NEC cites recommended resolution at 60Hz
Portrait: 480 x 640 1 @ 60Hz to 85Hz
*
600 x 800 @ 56Hz to 85Hz
* 1
624 x 832 @ 75Hz
* 1
768 x 1024 @ 60Hz to 85Hz
* 1
960 x 1280 * 1 * 2 @ 60Hz to 75Hz
1024 x 1280 @ 60Hz to 75Hz .................. NEC cites recommended resolution at 60Hz
359 mm/14.1 inches
Vertical: 287 mm/11.3 inches
287 mm/11.3 inches
Vertical: 359 mm/14.1 inches
AC 100 – 120 V/220 – 240 V @ 50/60 Hz
0.6A @ 100 – 120 V/0.3A @ 220 – 240 V
454 mm (W) x 462 mm (H) x 218 mm (D)
17.9 inches (W) x 18.1 inches (H) x 8.6 inches (D)
Portrait: 382 mm (W) x 498 mm (H) x 218 mm (D)
15.0 inches (W) x 19.6 inches (H) x 8.6 inches (D)
70 mm/2.8 inches
8.4 kg
18.5 lbs
5 C to +35 C/41 F to 95 F
30% to 80%
Feet: 0 to 10,000 Feet
-10 C to +60 C/14 F to 140 F
10% to 85%
Feet: 0 to 45,000 Feet
14
16
Notes
™
1810X
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.28 mm dot
pitch; XtraView ™ technology; 200cd/m
luminence; 300:1 contrast ratio, typical
Digital Input: TMDS ™
Depends on display card and timing used.
Automatically
Automatically
for optimal display and color performance.
for optimal display and color performance.
