Controls
the video source input port to the new found video source automati-
cally. The monitor will not look for other video signals while the
current video source is present.
LAST DETECT: The video input has to be switched to the "LAST
DETECT" mode. When the monitor is displaying a signal from the
current source and a new secondary source is supplied to the monitor,
then the monitor will automatically switch to the new video source.
When current video input signal is not present, then the monitor
searches for a video signal from the other video input port. If the video
signal is present in the other port, then the monitor switches the video
source input port to the new found video source automatically.
DVI SELECTION: This function selects the DVI input mode. When the DVI
selection has been changed, you must restart your computer.
DIGITAL: DVI digital input is available.
ANALOG: DVI analog input is available.
SOUND: Adjusts the volume of the earphones jack.
Tools 2
LANGUAGE: OSM
OSM POSITION: You can choose where you would like the OSM control
image to appear on your screen. Selecting OSM Location allows you to
manually adjust the position of the OSM control menu left, right, up or
down.
OSM TURN OFF: The OSM control menu will stay on as long as it is use.
In the OSM Turn Off submenu, you can select how long the monitor waits
after the last touch of a button to shut off the OSM control menu. The
preset chocies are 10, 20, 30, 60 and 120 seconds.
OSM LOCK OUT: This control completely locks out access to all OSM
control functions. When attempting to activate OSM controls while in the
Lock Out mode, a screen will appear indicating the OSM controls are
locked out. To activate the OSM Lock Out function, press PROCEED, then
and hold down simultaneously. To de-activate the OSM Lock Out, press
PROCEED, then
FACTORY PRESET: Selecting Factory Preset allows you to reset all OSM
control settings back to the factory settings. The RESET button will need to
be held down for several seconds to take effect.
Individual settings can be reset by highlighting the control to be reset and
pressing the RESET button.
RESOLUTION NOTIFIER: This optimal resolution is 1280 x 1024. If ON is
selected, a message will appear on the screen after 30 seconds, notifying
you that the resolution is not at 1280 x 1024.
CN912A/LCD1810X/78135311
cont.ols
control menus are available in seven languages.
™
and hold down simultaneously.
