Controls cont.
AUTO ADJUST
Automatically sets the Horizontal and Vertical Image Position within the
display area of the LCD.
Image Adjust Controls (Analog input only)
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this
setting.
AUTO ADJUST
Automatically adjust H.SIZE and FINE settings.
AccuColor Control System
®
Five color presets select the desired color setting. Each color setting is
adjusted at the factory.
R,G,B: Increases or decreases Red, Green or Blue color depending upon
which is selected. The change in color will appear on screen and the
direction (increase or decrease) will be shown by the bars.
Tools 1
SMOOTHING: Select one of three image sharpness settings. This function is
only valid when the expanded display function (expansion function) is on.
TEXT MODE: Use this to display text clearly.
NORMAL: This sharpness is between TEXT and GRAPHIC MODE.
GRAPHIC MODE: This mode is suited for images and photographs.
EXPANSION MODE: Sets the zoom method.
FULL SCREEN: The image is expanded to 1280 x 1024, regardless
of the resolution.
KEEP ASPECT: The image is expanded without changing the aspect ratio.
EXPANSION OFF: The image is not expanded.
CUSTOM (DIGITAL INPUT ONLY): Select one of four expansion rates.
In this mode the resolution may be low and there may be blank
areas. This mode is for use with special video cards.
VIDEO DETECT: Selects the method of video detection when more than one
computer is connected.
NONE: The Monitor will not search the other video input port unless
the monitor is turned on.
FIRST DETECT: The video input has to be switched to "FIRST DETECT"
mode. When current video input signal is not present, then the
monitor searches for a video signal from the other video input port. If
the video signal is present in the other port, then the monitor switches
