Quick Start

To attach the MultiSync
instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable
to the connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD
(Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the
MultiSync LCD
1530V
NOTE: To obtain the MultiSync LCD
call NEC-Mitsubishi Electronics Display at (800) 820-1230.
Remove connector cover and cable cover on back of monitor.
3. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector on
the back of the monitor (Figure C.1).
NOTE: Incorrect cable connections may result in irregular operation, damage
display quality/components of LCD module and/or shorten the module's life.
4. Connect one end of the power cord to the MultiSync LCD Series monitor and the other
end to the power outlet. Place the Video Signal Cable and AC power cord under Clips
(Figure C.1). Replace connector cover and cable cover. (Figure E.1)
NOTE: Adjust position of cable that place under clips, to avoid damage for cable or
monitor.
5. Turn on the monitor (Figure D.1) and the computer.
6. To complete the setup of your MultiSync LCD monitor, use the following OSM
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User's Manual for a full description of these OSM controls.
NOTE: For download information on the Windows 95/98 INF file for your MultiSync
LCD monitor, refer to the References section of this User's Manual.
1530V
NOTE: If you have any problems, please refer to the Troubleshooting section of
this User's Manual.
NOTE: For easy removal of the cable cover or signal cable, place the monitor face
down. (Figure R.2)
1530v
ブラック
LCD monitor to your system, follow these
®
™
1530V
Macintosh cable adapter (Figure B.1). Tighten all screws.
Macintosh cable adapter,
1530V
3
5
Macintosh cable adapter to the computer
