Controls
-continued
Linearity: This selection allows you to adjust the spacing of the area on the screen. The
purpose of this control is to ensure that a one-inch circle is a true one-inch circle wherever
it is on the screen. The best way to determine the vertical linearity is as follows:
• Draw equally spaced horizontal lines using a drawing application that has a ruler.
• Use the Vertical Balance control to adjust the lines near the top and bottom of your screen.
• Use the LINEARITY (VER.) control to adjust the spacing between the lines near the center and
top of your screen.
GlobalSync ® Control: Eliminates picture impurities that may result from the
earth's magnetic field. While in the sub-menus, use the –/+ control buttons to fine
tune the GlobalSync corrections.
NOTE:NEC recommends that you perform GlobalSync correction while running
a typical application such as a spreadsheet or text document.
Tools 2
Language: OSM controls menus are available in six languages.
OSM Position: You can choose where you would like the OSM controls menu to
appear on your screen. Selecting OSM Position allows you to manually adjust the
OSM controls menu left, right, up or down.
OSM Turn Off: The OSM controls menu will stay on as long as it is in use. In the
OSM Turn Off sub-menu, you can select how long the monitor waits after the last
touch of a button for the OSM controls menu to disappear. The preset choice is in
5 seconds step between 5–120 seconds.
OSM Lock Out: This control completely locks out access to all OSM controls
functions except Brightness and Contrast. When attempting to activate OSM
controls while in the lock out mode, a screen will appear indicating that OSM
controls are locked out. To activate the OSM Lock Out function, press SELECT, then
press + and hold down simultaneously. To deactivate the OSM Lock Out, press
SELECT, then press + and hold down simultaneously.
IPM System Off Mode:
™
NOTE: For standard systems and graphics boards, keep the factory setting at ENABLE.
NOTE: Don't keep the MultiSync monitor on when 'No Signal' is applied. This
could cause image burn in on the screen due to the 'No Signal'
message being displayed.
EdgeLock ™ Control: Operating your monitor at a nonstandard timing may cause
images to appear darker than normal or have color distortion. Use of the
EdgeLock control will adjust images to their normal state.
Hot Key: This selection allows you to use
as contrast control.
Enable: The IPM System works normally
all stages of energy savings are utilized.
Disable: The Off Mode reset
7
as brightness control and –/+
and
