Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to
read through this manual completely.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The specifications of this product and the contents of this operation manual are subject to change without
notice.
• The operation manual and the product have been prepared and tested as much as possible. If you find any
misprints or errors, please inform us.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur
through use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur
with respect to any article made using this product.
Company names and product names are trademarks or registered trademarks of their re-
spective holders.
Copyright © 2022 Roland DG Corporation
http://www.rolanddg.com/
R2-221202
FA03620

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrueVIS SG3-540 and is the answer not in the manual?

Questions and answers

Elize van Rensburg
January 23, 2025

Is it possible to set or adjust the start and end points for printing in Versaworks 6 for a Truevis SG3-540 printer, without using the "Move" function on the printer?

0
1 comments:
Mr. Anderson
May 14, 2025

No, the context only describes adjusting the output-start location by using the "Move" function. There is no mention of setting or adjusting start and end points for printing in VersaWorks 6 without using the "Move" function.

This answer is automatically generated

0

Related Manuals for Roland TrueVIS SG3-540

Summary of Contents for Roland TrueVIS SG3-540

  • Page 1 • Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through use of this product, regardless of any failure to perform on the part of this product.

  • Page 2: Table Of Contents

    3. Network Settings ......................45 Setting a Fixed IP Address....................45 Directly Connecting to the Computer ..................47 4. Downloading and Installing Software ..................52 Downloading Roland DG Connect Hub ..................52 Installing the Software .....................53 Setting the Software RIP ....................55 Appendix........................ 56 Location of the Power Rating and Serial Number Label ..............57...

  • Page 3: Introduction

    Introduction 1. Checks before Installation................. 3 About the User's Manuals for This Machine............ 3 About Placement and Installation Work ............3 Deciding On an Installation Site..............4 Temperature and Humidity ..............5 Installation Space ................. 6 2. Checking the Included Items..............7 Introduction...

  • Page 4: Checks Before Installation

    1. Checks before Installation About the User's Manuals for This Machine The following documentation is included with the machine. Paper Manuals • Safety Precautions This manual contains points that must be observed. • Regular Maintenance Guidelines This manual provides URLs where procedures can be found for the machine's daily maintenance as well as for the maintenance that must be performed periodically.

  • Page 5: Deciding On An Installation Site

    1. Checks before Installation Deciding On an Installation Site Install the machine in a quiet, stable location offering good operating conditions. An unsuitable location can cause accidents, fire, faulty operation, or breakdown. WARNING Install the machine in a location that is level, stable, and able to bear the weight of the machine. The total weight of the machine may reach 220 kg (485 lb.) (30-inch model: 182 kg [401 lb.]) or more.

  • Page 6: Temperature And Humidity

    1. Checks before Installation Temperature and Humidity Maintain the specified temperature and humidity even when the machine is not in use. Failure to do so may result in malfunction. • During operation: Temperature: 20 to 32°C (68 to 89.6°F), humidity: 35 to 80%RH (no condensa- tion) •...

  • Page 7: Installation Space

    1. Checks before Installation Installation Space The space shown in the figure is required in order to use this machine. SG3-540 SG3-300 4,000 mm (157.5 in.) 3,750 mm (147.6 in.) 3,000 mm (118.1 in.) 2,750 mm (108.3 in.) 1,000 mm (39.4 in.) 2,000 mm (78.7 in.) Unit Unit space...

  • Page 8: Checking The Included Items

    2. Checking the Included Items The following items are included with the machine. Make sure they are all present and accounted for. Stand legs (1 each for right and Stand stay (1) Shafts (4) Casters (2) left) Control box and motorized me- Dancer roller (1) Paper tube (1) Left stay (1)

  • Page 9: Installation

    Installing the Cutting Tool ..............43 3. Network Settings...................45 Setting a Fixed IP Address ..............45 Directly Connecting to the Computer ............47 4. Downloading and Installing Software ............52 Downloading Roland DG Connect Hub............52 Installing the Software ................53 Setting the Software RIP ................55 Installation...

  • Page 10: Assembly And Ink Filling

    1. Assembly and Ink Filling Checks before Operations CAUTION Unloading and emplacement are operations that must be performed by 6 persons or more. Tasks that require undue effort when performed by a small number of persons may result in physical injury. Also, if dropped, such items may cause injury.

  • Page 11: Step 1: Assembling The Stand

    1. Assembly and Ink Filling Step 1: Assembling the Stand Procedure Place the caster on the stand leg. Place the stand leg with the tabletop plate (A) facing down, and then place the caster on top of the stand leg. The casters have no particular front and rear orientation. Use eight bolts to secure the caster.
  • Page 12 1. Assembly and Ink Filling Assemble the opposing stand leg by following the same procedure from step 1 to step 2. Position the left and right stand legs parallel to each other and separated by approximately 1,550 mm (61 in.) for the 54-inch model or approximately 930 mm (36.6 in.) for the 30-inch model. Position the legs so that the L-shaped brackets face the inside and the side of the tabletop plate with the hole (A) faces down for each leg.
  • Page 13 1. Assembly and Ink Filling Fully tighten the bolts in the four locations indicated with B. Tighten the bolts securely. Loose bolts may cause the stand to wobble. Set the stand upright. IMPORTANT Be sure to perform this operation with two workers, each one holding one stand leg. If only one worker per- forms this operation, the stand stay may bend.

  • Page 14: Step 2: Attaching The Printer Unit And The Stand

    1. Assembly and Ink Filling Step 2: Attaching the Printer Unit and the Stand Procedure With six or more workers, lift up the printer unit. CAUTION Unpacking and installation must be carried out by 6 persons or more. Failure to observe this instruction may cause the machine to fall over, resulting in injury. Move the stand under the printer unit.
  • Page 15 1. Assembly and Ink Filling Align the surface of the printer unit (A) and the center position of the rhombus mark (B) on the stand as seen from the inside to the outside. (Align the front and rear sides.) Place the printer unit on the stand. IMPORTANT Be sure to have workers support the printer unit right up to step 6.
  • Page 16 1. Assembly and Ink Filling Secure the printer unit on the stand. Lift the back of the printer up slightly to make it level. Temporarily tighten the eight bolts. Fully tighten the eight bolts. Installation...

  • Page 17: Step 3: Installing The Media Holders And Media Stays

    1. Assembly and Ink Filling Step 3: Installing the Media Holders and Media Stays 1. Attach the arms. Procedure Temporarily tighten the bolts on the left stand as seen from the rear of the printer. Tighten the bolts in the holes on the side of the stand until you can see approximately 5 mm (0.2 in.) of their threads (A).
  • Page 18 1. Assembly and Ink Filling IMPORTANT Hold the pieces together so there is no gap between the left arm and stand when tightening the bolts. Make sure the protrusions on the stand leg (A) are in the center of the holes on the arm (B). Move the arm to the left and right until these protrusions are centered.
  • Page 19 1. Assembly and Ink Filling 2. Attach the media holders. Procedure Place the two shafts on the arms. Pass the rear shaft through the two media stays. Attach the left media holder. Pass the front shaft through the left media holder. Catch the left media holder on the rear shaft.
  • Page 20 1. Assembly and Ink Filling Position the media holders approximately 100 mm (3.94 in.) from the edges. Attach the shaft clamps, securing the shafts with two bolts. IMPORTANT Ensure the media holders do not get caught in the shaft clamps. Installation...

  • Page 21: Step 4: Assembling The Media Take-Up Unit

    1. Assembly and Ink Filling Step 4: Assembling the Media Take-up Unit 1. Attach the arms. Procedure Temporarily tighten the bolts on the left stand as seen from the front of the printer. Tighten the bolts in the holes on the side of the stand until you can see approximately 5 mm (0.2 in.) of their threads (A).
  • Page 22 1. Assembly and Ink Filling Move the arm to the left and right until these protrusions are centered. Temporarily tighten the bolts at the bottom of the left arm. Use a hexagonal wrench to fully tighten the upper bolts followed by the lower bolts In the same manner, attach the right arm to the right side as seen from the front of the printer.
  • Page 23 1. Assembly and Ink Filling 2. Attach the control box and the left stay. Procedure Place the control box (A) on the right stand leg. Assemble the motorized media holder (B) by passing it through the rear of the right stand leg. Place the holder outside the printer.
  • Page 24 1. Assembly and Ink Filling Fully tighten the bolts in the order of Place the left stay on the left stand leg in the same manner as the control box. Temporarily tighten the four bolts on the left stay. IMPORTANT After temporarily tightening the bolts, position the stay in the same manner as the control box.
  • Page 25 1. Assembly and Ink Filling 3. Attach the media holders. Procedure Position the motorized media holder as shown in the figure. Be sure to pass this holder behind the stand. Place the two shafts on the arms. Attach the motorized media holder to the shafts. Pass the front shaft through the motorized media holder.
  • Page 26 1. Assembly and Ink Filling Lower the levers (A) to secure the left and right media holders. Leave approximately 100 mm (3.94 in.) of space from the edges. Attach the shaft clamps, securing the shafts with two bolts. IMPORTANT Ensure the media holders do not get caught in the shaft clamps. Installation...
  • Page 27 1. Assembly and Ink Filling 4. Attach the cable clamps and the cable. Procedure Attach seven cable clamps to the positions shown in the figure. The two clamps on the side of the machine are used for the power cord and the Ethernet cable and will be used later.
  • Page 28 1. Assembly and Ink Filling Installation...
  • Page 29 1. Assembly and Ink Filling 5. Install the dancer roller. Procedure Raise the dancer roller and place it on the stand legs. MEMO The dancer roller has no particular front and rear orientation. On the right side of the dancer roller, bring the flat surface of the shaft (A) toward you, and then tempo- rarily tighten the bolt.
  • Page 30 1. Assembly and Ink Filling Fully tighten the bolt on the right side (A), followed by the left side (B) of the dancer roller. Installation...

  • Page 31: Step 5: Installing The Drain Bottle

    1. Assembly and Ink Filling Step 5: Installing the Drain Bottle Procedure Remove the drain pad. Discharged fluid used in the inspection when the printer was shipped may remain. Exercise cau- tion. Install the drain funnel. Screw the drain funnel all the way into the hole where the drain pad was attached. IMPORTANT Use caution to turn the bottle without applying excessive force.
  • Page 32 1. Assembly and Ink Filling Insert the hooks (A) into the grooves (B), matching the status indicated in the figure. Connect the drain bottle stand connector to the unit. Stand up the drain bottle stand so it is vertical , and then slide it in the direction indicated in the figure Stand up the drain bottle stand until the hooks come completely free from the grooves.
  • Page 33 1. Assembly and Ink Filling Fully tighten the two bolts to secure the drain bottle stand. Install the drain bottle in the bottle stand. Installation...

  • Page 34: Step 6: Removing The Retainers

    1. Assembly and Ink Filling Step 6: Removing the Retainers IMPORTANT • Make sure to remove all the retainers. Any that remain may cause faulty operation or breakdown when the power is switched on. • Store the retainers because they are needed again when transporting the machine. Procedure Open the front cover.

  • Page 35: Step 7: Connecting The Cables

    1. Assembly and Ink Filling Step 7: Connecting the Cables WARNING Perform this task with all power switches left switched off. Otherwise sudden movement of the machine may cause injury. WARNING Connect to an electrical outlet that complies with this machine's ratings (for voltage, frequency, and current).
  • Page 36 1. Assembly and Ink Filling Installation...

  • Page 37: Step 8: Preparing The Cleaning Liquid And The Ink

    • Be sure to use a new cleaning liquid pouch and new ink pouches. • Never, under any circumstances, use anything other than the specified type of cleaning liquid or ink. • The cleaning liquid pouch and the ink pouches must be purchased separately. Contact your authorized Roland DG http://www.rolanddg.com/...
  • Page 38 1. Assembly and Ink Filling Push the ink pouch until you hear a click as the hook on the pouch is locked. Installation...

  • Page 39: Step 9: Initial Settings And Ink Filling

    1. Assembly and Ink Filling Step 9: Initial Settings and Ink Filling 1. Make the initial settings. Procedure Turn on the main power switch. Tap the operation panel. The operation panel turns on, and the [Language Setting] screen appears. Tap [Language English]. MEMO Default setting: [English] The language selection screen appears.
  • Page 40 1. Assembly and Ink Filling • [Temperature]: °C Tap [Save]. Installation...
  • Page 41 1. Assembly and Ink Filling 2. Fill the machine with ink and cleaning liquid. Procedure Set the pouch tray in which you have set the cleaning liquid pouch in the cleaning liquid slot. Insert the pouch tray as far as it will go. Gently shake the ink pouch for each color.
  • Page 42 1. Assembly and Ink Filling [Ink filling in progress. Please wait.] appears, and the machine is filled with ink. When the ink filling is complete, the top menu appears. Installation...

  • Page 43: Installing The Cutting Tool

    2. Installing the Cutting Tool This operation is unnecessary if you will not use the cutting tool. Tighten the cutting carriage screw lightly when no cutting tool is installed. Keeping the screw firmly tightened causes the cutting tool insertion hole to become gradually smaller, making installation difficult.

  • Page 44: Installing The Cutting Tool

    2. Installing the Cutting Tool Installing the Cutting Tool Procedure Tap [Maintenance]>[Blade Replacement]. Tap [Execute]. The cutting carriage moves to a position where the blade can be installed. When the message [Open the front cover.] appears on the screen, open the front cover. Loosen the cutting carriage screw in the order shown in the figure.
  • Page 45 2. Installing the Cutting Tool Close the front cover. Tap [Finish All]. This completes the installation of the cutting tool. Installation...

  • Page 46: Network Settings

    3. Network Settings The IP address of this machine can be assigned automatically from a DHCP server. If there is a DHCP server on your local network, no network settings are required. After connecting a LAN cable, carry out Setting the Software RIP(P.
  • Page 47 3. Network Settings to the right of [Subnet Mask]. The numeric value input screen appears. Enter the subnet mask. Tap [OK]. to the right of [Default Gateway]. The numeric value input screen appears. Enter the default gateway. Tap [OK]. Tap [Save]. to go back to the original screen.

  • Page 48: Directly Connecting To The Computer

    3. Network Settings Directly Connecting to the Computer This section explains the setting procedure for connecting one computer and one machine. Step 1: Setting the Computer's Network Procedure Log on to Windows as the [Administrator] or a member of the [Administrators] group. Display the network connections screen.
  • Page 49 3. Network Settings Select [Use the following IP address]. Enter the information as shown below, and then click [OK]. Item Address to enter IP address 192.168.0.XXX Subnet mask 255.255.255.0 Here, "XXX" can be any number from 1 to 254. However, be sure to specify a number that is differ- ent from the numbers used for other computers and devices.
  • Page 50 3. Network Settings a. [OK] in the [Internet Protocol Version 4 (TCP/IPv4) Properties] window b. [Close] in the [Ethernet Properties] or [Wi-Fi Properties] window c. [Close] in the [Ethernet Status] or [Wi-Fi Status] window Installation...
  • Page 51 3. Network Settings Step 2: Make the Network Settings on the Printer Procedure Set the IP address. Tap [System Information]>[Network]. Tap [Obtain IP Address Automatically] to turn it off. next to [IP Address]. Set the IP address (192.168.0.XXX). "XXX" represents a number from 1 to 254. However, be sure to specify a number that is differ- ent from the setting you made in Step 1 and from the numbers used for other computers and devices.
  • Page 52 3. Network Settings Tap [OK]. Tap [Save]. If you are using the computer and the machine on a one-to-one basis, this completes the set- tings to make on the printer. Go back to the original screen. Then, proceed to Setting the Software RIP(P. 55).

  • Page 53: Downloading And Installing Software

    A connection to the Internet is required to download and install the software. Among the various pieces of software to use with this machine, first download and install Roland DG Con- nect Hub on the computer to connect to the machine. Then, install the other required software.

  • Page 54: Installing The Software

    4. Downloading and Installing Software Installing the Software IMPORTANT A setup video for Roland DG Connect Hub is available in the explanation window for Roland DG Connect that you Downloading Roland DG Connect Hub(P. 52) opened in step 4 of .
  • Page 55 Roland DG Connect Hub to the notification area. Although Roland DG Connect Hub is no longer dis- played, it is still running. The icon of Roland DG Connect Hub is displayed at all times in the notification area while this software is running.

  • Page 56: Setting The Software Rip

    4. Downloading and Installing Software Setting the Software RIP For information on how to connect the printer after installing VersaWorks, see the VersaWorks Installation Guide. Installation...

  • Page 57: Appendix

    Appendix Location of the Power Rating and Serial Number Label ..........57 Specifications ...................58 Appendix...

  • Page 58: Location Of The Power Rating And Serial Number Label

    Location of the Power Rating and Serial Number Label Right Side Serial number This number is required when you seek maintenance, servicing, or support. Never peel off the label. Power rating Use an electrical outlet that meets the requirements for voltage, frequency, and amperage given here. Appendix...

  • Page 59: Specifications

    10 to 300 mm/s (0.39 to 11.8 in./s) 30 to 500 gf Blade force Blade Type Roland CAMM-1 series blade Offset 0.000 to 1.500 mm (0.0 to 59mil) Software resolution (when cutting) 0.025 mm/step (0.98 mil/step) Print heater set temperature: 30 to 45°C (86 to 113°F) Media heating system Dryer set temperature: 30 to 55°C (86 to 131°F)
