- Page 1 ORIGINAL INSTRUCTIONS ROBOT VACUUM CLEANER FHAR28 INSTRUCTION MANUAL CAUTION: Read the instructions before using this machine!
-
Page 2: Table Of Contents
CONTENT 1. IMPORTANT SAFETY INFORMATION……………………….……………….3 2. PRODUCT AND CONTENTS……………………….…………………………..6 3. OPERATING INSTRUCTIONS………………………………….………………7 4. SMART VACUUM CLEANER CARE…………………..………………………15 5. TROUBLESHOOTING………………………………………..………………….16 6. SPECIFICATIONS………………………………………………………………..20 7. DISPOSAL…………………………………………………………………………20 8. DECLARATION OF CONFORMITY……………………………….…………21 9. WARRANTY……………………………………………………………………….22 10. PRODUCT FAILURE……………………………………………………………23 11. WARRANTY EXCLUSIONS………………………..….…………………….24... -
Page 3: Important Safety Information
1. IMPORTANT SAFETY INFORMATION This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 unit provided with the appliance. ⚫ The appliance must only be supplied at safety extra low voltage corresponding to the marking on the appliance. 1.1 USER CAUTIONS ⚫ The Smart Vacuum Cleaner is for indoor use only. Do not use the Smart Vacuum Cleaner outdoor, commercial or industrial environments.
- Page 5 ⚫ Do not place anything on top of the Smart Vacuum Cleaner. ⚫ Be aware that the Smart Vacuum Cleaner moves on its own. Be careful when walking in the area that the Smart Vacuum Cleaner is operating in to avoid stepping on it.
-
Page 6: Product And Contents
with wet hands. ⚫ Always remove the Smart Vacuum Cleaner from the Charging Dock before cleaning or maintaining it. ⚫ The Smart Vacuum Cleaner contains Li-ion rechargeable batteries, be sure to never open, pierce or damage the batteries. ⚫ Do not wet the battery compartment. ⚫... - Page 7 2.2 ACCESSORIES...
- Page 8 2.3 CHARGING DOCK...
-
Page 9: Operating Instructions
2.4 REMOTE CONTROL 3 OPERATING INSTRUCTIONS 3.1 NOTES BEFORE CLEANING Before using the Smart Vacuum Cleaner, pick up objects like clothing, loose papers, pull cords for blinds or curtains, power cords and any fragile objects. - Page 10 If the room to be cleaned contains a balcony, a physical barrier should be used to prevent access to the balcony and ensure safe operation. 3.2 USING THE SMART VACUUM CLEANER 1. Plug in the Charging Dock and place the remaining wire inside the bottom of the Charging Dock. Note: Failure to place the remaining wire inside the Charging Dock, may cause the vacuum cleaner to pull on the wire while charging or cleaning.
- Page 11 3) Install Side Brushes Attach the Side Brushes to the bottom of the Smart Vacuum Cleaner by pressing a brush into each slot until it clicks. 4) Turning on the Smart Vacuum Cleaner ⚫ Switch the power button at the bottom of the unit to the ON position. ⚫...
- Page 12 6) Pause Cleaning Cycle ⚫ To pause the Smart Vacuum Cleaner during a cleaning cycle, press the button on Smart Vacuum Cleaner or press the button on the Remote Control. ⚫ To resume the cleaning cycle, press button again. ⚫ To send Smart Vacuum Cleaner back to the Charging Dock, press button on the Remote Control.
- Page 13 ⚫ At various times throughout the cleaning cycle, the Smart Vacuum Cleaner will touch up around the edges of the room, as well as chair legs and other furniture to help with the navigation. ⚫ The Smart Vacuum Cleaner will continue this process until it cleaned the entire area. If the battery gets low before finishing the cleaning cycle, the Smart Vacuum Cleaner will return to the Charging Dock to recharge.
- Page 14 4) Manual Cleaning You can manually control the Smart Vacuum Cleaner to clean an area by using the directional buttons on the remote control. 5) Controlling the Smart Clean Rob Vac via the Smart Life APP Search “Smart Life” in the APP store or Google Play to download. 1) Use the Smart Life app to control the Smart Vacuum Cleaner To enjoy all the Smart Vacuum Cleaner available features, it is recommended to control your Vacuum Cleaner via the app.
-
Page 15: Smart Vacuum Cleaner Care
1500ms) Lamp off Wi-Fi configured successfully but not connected to router/ Wi-Fi shut down Lamp on (Solid green) Wi-Fi configured successfully and have connected to router 4 SMART VACUUM CLEANER CARE To keep the Smart Vacuum Cleaner running at peak performance, perform the following care procedures. - Page 16 4) Air-dry the filter completely before use. 3) Rinse filters with water. 4.3 CLEANING SMART VACUUM CLEANER’S SIDE BRUSH 1) Remove the Brush 2) Clean the brush and the brush stand and reinstall the brush. 4.4 CLEANING THE SMART VACUUM CLEANER’S ANTI-DROP SENSORS AND CHARGING CONTACTS ⚫...
- Page 17 4.5 CLEANING THE SMART VACUUM CLEANER ANTI-COLLISION SENSOR Use a clean, dry microfiber or soft cotton cloth to wipe any debris that has accumulated in the round sensor opening on the right side of the bottom surface. Do not spray cleaning solution directly into the sensor opening.
-
Page 18: Troubleshooting
5.TROUBLESHOOTING The Smart Vacuum Cleaner will tell you if something is wrong with a two-tone distress sound followed by a message. The indicator will also blink or be solid red. Please refer to the chart below to troubleshoot and resolve the Smart Vacuum Cleaner problem. If the problem is not resolved, please contact our customer service department for further assistance. - Page 19 beeps hanging over a drop or it is stuck surface, start in a new location. on a dark surface Otherwise, wipe its anti-drop Sensors with a dry cloth. The Smart Vacuum Cleaner Ensure there are no obstacles in cannot return to its Charging Dock front of the charging dock or Four or starting position.
-
Page 20: Specifications
•Clean the sensors carefully with a dry cloth. Smart Vacuum •Restart the Smart Vacuum Cleaner by turning the power switch off and Cleaner movements or path are abnormal. 6. SPECIFICATIONS Product Model FHAR28 Input 19Vd.c. 0.6A Battery Voltage 14.4 Vd.c. Power Consumption Battery Type 14.4 Vd.c. -
Page 21: Declaration Of Conformity
8. DECLARATION OF CONFORMITY BUILDER SAS 32, rue Aristide Bergès -Z1 31270 Cugnaux - France Tel. +33 (0) 5.34.502.502 Fax: +33 (0) 5.34.502.503 ROBOT VACUUM CLEANER FHAR28 Serial number: xxxxxxx This declaration of conformity is issued under the sole responsibility of the manufacturer. -
Page 22: Warranty
9. WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 23: Product Failure
10. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. •... -
Page 24: Warranty Exclusions
11. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 25 BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France Made in PRC 2022...
