FDI ELI121-CRW Quick Start Manual

Getting your ELI up and running quickly!

1. Introduction

About ELI
ELI® is Future Designs, Inc.'s family of long-life, plug-and-play embedded displays. ELI products are true modular
embedded display solutions that require no engineering or lead-time. All ELI products are compatible with a wide
range of single board computers including Raspberry Pi, BeagleBone Black and Windows-based units. FDI designed
ELI as an embedded display option that requires minimal development time to help customers reach production
quickly. Once a product is in production, FDI's 10-15 year ELI product availability guarantee helps ensure
production schedules without the risk of expensive or time consuming redesigns. Learn more about ELI at
TeamFDI.com/ELI.

ELI Compatibility

ELI products are compatible with most single board computers, PCs and operating systems. The table below
illustrates the results of FDI's compatibility tests with popular operating systems and platforms. Our results, as
indicated in the table, demonstrate ELI's versatility but the table is not exhaustive. ELI products are designed to
work with any single board computer that has an HDMI or DVI output. To submit a question about ELI's
compatibility with a platform or operating system that is not included in the table, contact a member of the FDI
support team at Support@teamfdi.com.

2. Required Equipment (Not Provided)

1. HDMI Cable (Type A Male) to connect to the ELI for the video signal
2. USB Cable (Mini USB Type B) to connect to the ELI for the touch screen operation
3. 12V DC power input, 2.1mm, center positive, 1.2A min
4. Your choice of computer, SBC, or PC, with digital video output (HDMI or DVI) and USB port for touch input
12/27/2016
ELI121-CRW
Quick Start Guide
Copyright ©2016, Future Designs, Inc.
1
Page
Revision 1.02
