ELI Touch Screen Calibration in
Summary:
This guide will show you how to calibrate your ELI touch screen in a Windows 10 environment. We will
use the Tablet PC Settings menu to calibrate your ELI. This OS level touch screen calibration data will be
saved on the host machine, so if the ELI unit is moved to another host machine, the calibration will need
to be redone.
This method has been tested and confirmed working on the following ELI units:
•
ELI70-CR
•
ELI70-IPHW
•
ELI121-CRW
Target Device(s):
•
ELI Device .....................................................................................................................................
Required Software:
•
Windows 10
Contents
1. Connecting to the Board ............................................................................... 2
2. Calibrating your ELI ....................................................................................... 3
3. Website and Support .................................................................................... 5
Rev. 1.0 May 17, 2018
www.teamfdi.com
Windows 10
Windows 10 Calibration Guide
FDI_AN_ELI_001
1.0
May 17, 2018
Website
Page 1
Advertisement
Table of Contents
Related Manuals for FDI ELI70-IPHW
Summary of Contents for FDI ELI70-IPHW
- Page 1 ELI unit is moved to another host machine, the calibration will need to be redone. This method has been tested and confirmed working on the following ELI units: • ELI70-CR • ELI70-IPHW • ELI121-CRW Target Device(s): • ELI Device .............................
- Page 2 ELI43-Cx Linux Calibration Linux Calibration Guide 1. Connecting to the Board 1. Connect your HDMI source to the HDMI input on the ELI. 2. Connect your 12V power supply to the power input on the ELI. 3. Connect your USB to the mini USB touch output on the ELI. Figure 1 –...
- Page 3 ELI43-Cx Linux Calibration Linux Calibration Guide 2. Calibrating your ELI The following steps will guide you through performing an OS-level touch screen calibration for computers using Windows 10. After the display is detected, the display settings must be changed to set the ELI as a secondary display.
- Page 4 ELI43-Cx Linux Calibration Linux Calibration Guide 5. Press the Windows button, , then type “calibrate” to search. Figure 4. Finding the Calibration Utility 6. Click on Calibrate the screen for pen or touch input. 7. In the menu that pops up, find the ELI device in the dropdown menu. In our example, ELI70- CR is the first display option, however, it may not always be the first option.
- Page 5 Hit ESC to exit once calibration starts. The calibration option should now be available on ELI. 10. Once you have finished, click Yes to save the calibration permanently. 3. Website and Support Support: • FDI Support home page: ..............http://www.teamfdi.com/support • FDI Forums: ..................http://www.teamfdi.com/forum Rev. 1.0 May 17, 2018...
