Appendix C Specifications
Specifications

Single Bio Amp

Input

Connection type:
Input configuration:
Input impedance:
Isolation:
Amplification ranges:
Gain accuracy:
Six-pin DIN/MS socket to fit 3-lead Bio Amp
cable (Tronomed D-1340)
1 isolated differential channel with isolated
ground reference
Ω
200 M differential, 30 pF (no cable) or
500 pF (supplied Bio Amp cable and leads) to
isolated ground
4000 V (50 Hz for 1 minute)
rms
± 5 μV to ±100 mV full scale in 14 steps
(combined PowerLab and Bio Amp)
± 100 mV
± 50 mV
± 20 mV
± 10 mV
± 5 mV
± 2 mV
± 1 mV
± 500 μV
± 200 μV
± 100 μV
± 50 μV
± 20 μV
± 10 μV
± 5 μV
± 1.5% all ranges
