C H A P T E R Introduction Th e ADInstruments Blood FlowMeter is one of a family of stand-alone instruments, designed to measure blood cell perfusion levels in the microcirculatory beds of skin and other tissues. Th is Blood FlowMeter...
Th is owner’s guide describes how to set up and begin using your Blood FlowMeter. Topics discussed included how to connect the hardware, perform a simple power-up test and calibration of the Blood FlowMeter. Th e appendices provide technical information about the Blood FlowMeter and look at some potential problems and their solutions.
Probe connected and laser operating Probe Input Connector Th e Blood FlowMeter is a single channel device and provides one probe input connector. Th e input connector is a polarized (keyed) multi-pin connector with optical interfaces for the fi ber optics in the probe cable. Th e probes are designed to push and click into the connector.
AC supplies. Connection of power valid when used in conjunction with the to the Blood FlowMeter is via a mini DIN connector. All power at this point power supply provided. is low voltage.
CD. Follow the onscreen instructions. Next, install the Blood FlowMeter Device Enabler Th e Blood FlowMeter Device Enabler is a soft ware add-on for LabChart soft ware. Place the CD for the ADInstruments Blood FlowMeter Device Enabler in the CD drive of your computer.
Blood FlowMeter are turned off . Connect the power supply output of the external supply to the power input of the Blood FlowMeter. Make sure that this connector is pushed all the way in, as it does not have a locking facility.
When the power has been connected, turn on the power switch on the rear panel of the Blood FlowMeter. Th e Power indicator on the front of the Blood FlowMeter should glow green and you should hear a double beep from the unit to indicate that it has initialized.
+ 5 V (+100 %) Temperature Warning If the internal temperature of the Blood FlowMeter moves outside the operating temperature range of the device, then it will emit a double beep every 16 seconds. If this occurs, the instruments should be moved to a cooler environment for proper operation.
Probe Calibration Th e Blood FlowMeter is designed to be easily confi gured and calibrated for new probes. Th is operation requires a MLA191 Calibration Kit, which includes a controlled concentration of latex spheres in suspension. It is important to follow the instructions provided with the Calibration Kit as calibration of probes is not possible without it and should not be attempted.
Th e following sections describe how to use the Blood FlowMeter with a PowerLab data acquisition unit (BNC connection) and LabChart soft ware. It is assumed that you know how to connect the Blood FlowMeter to your PowerLab system and that you are familiar with the LabChart soft ware.
An example of what you should see is shown in Figure 2–3. Th is fi gure also shows a typical waveform from the LDF output. You can use a fi lter Low pass setting to remove any unwanted noise. You should not use the AC coupled feature as this will result in an incorrect measurement of blood perfusion units.
Cleaning Warning: Do not spray, pour or spill any liquid on the Blood FlowMeter, its accessories, connectors, switches or openings in the enclosure. Do not submerse the instrument in liquid.
Th e probe connectors must be kept clean and free from dust. Connectors should be inspected before each use. Dust can be removed from the connectors using an air-duster. Th e integrity of probes may be checked by holding the probe end to a source of bright diff use light, for example a lamp, and inspecting the connector end.
• 70% alcohol in water Th e disinfectant manufacturer’s recommended immersion times should be used. Sterilization Only some of the dedicated perfusion probes may be sterilized by moist heat (steam). For further details please contact your ADInstruments representative. Blood FlowMeter Owner’s Guide...
Page 28
In the majority of cases, the problem can be fi xed by checking connections and or resetting the Blood FlowMeter. Very rarely will there be an actual problem with the Blood FlowMeter. Th is appendix will help you to determine what kind of fault you have and an appropriate solution.
Contact your ADInstruments representative for help. Th e Blood FlowMeter does not produce any laser output when the power is A faulty probe connection. • Make sure the probe is properly connected to the system by pushing its connector fi rmly into the front panel socket.
Page 30
Th ere is no signal output from the Blood FlowMeter No power to the Blood FlowMeter. • Check that the Power indicator on the Blood FlowMeter is on. Th e probe is not plugged in correctly. • Check the probe is connected correctly.
A P P E N D I X Technical Aspects Blood fl ow in the skin performs an essential role in the regulation of the metabolic, hemodynamic and thermal state of the individual. Despite the fact that the skin is the body’s largest and most accessible organ, the measurement of cutaneous microcirculatory blood perfusion has until quite recently proved a formidable task.
Th is is performed using a photo diode detector. Th e frequency and magnitude of the alternating component of the photocurrent from this device (i.e. the power spectral density) is related to the mean velocity and concentration of blood cells present in the measuring volume. Blood FlowMeter Owner’s Guide...
LDF signal. How it Works Th e Blood FlowMeter determines the blood fl ow perfusion by illuminating the surface of the skin with laser light and measuring the backscattered light. Various calculations are then performed on the returned signal which is then turned into a continuous signal that represents the blood perfusion in the illuminated area.
What the Blood FlowMeter Measures Th e Blood FlowMeter is a laser Doppler fl owmeter whose primary purpose is to measure real-time microvascular red blood cell (RBC) perfusion (otherwise known as RBC fl ow or RBC fl ux). Laser Doppler signals are recorded in BPU which is a relative units scale defi ned using a carefully controlled motility standard.
BPU must be considered as strictly relative. Zero BPU Th e zero reading of the Blood FlowMeter has been obtained by calibrating the system against a special static scattering material where no movements occur. In such cases the back-scattered light processed by the Blood FlowMeter contains no Doppler shift ed frequencies and a true zero is obtained.
Page 36
Under these conditions, artifacts should be minimized by controlling vibration reaching the measurement site and the Blood FlowMeter. Th is may be achieved by placing the ventilator on a separate table and on a vibration absorbing medium. Blood FlowMeter Owner’s Guide...
A P P E N D I X Specifi cations Doppler Flow Specifi cations Mode: Continuous laser Doppler fl owmetry Primary measurand: Microvascular blood perfusion (Relative RBC Flux) LDF units: Relative units (0-5000 Blood Perfusion Units, corresponding to 0-5 V output) BSC units: Relative units (0-100% corresponding to 0-5 V output)
(2.70" × 9.45" × 10.2") Weight: 2.5 kg Power requirements: 240 V or 120 V (internally set) @ 15 W Operating temperature: 5-35 °C Operating humidity: 0-70% (non-condensing) ADInstruments reserves the right to alter these specifi cations at any time. Blood FlowMeter Owner’s Guide...
