Contec 70 Series Manual page 2

General Specifications
Item
FPD-S71VT-DC1
Environment
Operating temperature *1 0 - 50ºC (0 - 40ºC when using an AC adapter)
Storage temperature -10 - 60ºC
Operating humidity *2 10 - 90％RH (No condensation)
10 - 85％RH (No condensation) (When using the AC
adapter)
Floating dust particles Not to be excessive
Corrosive gas None
Noise Line noise AC line: 2 kV *3, Signal line: 1 kV
resistance (IEC1000-4-4Level3、EN61000-4-4Level3)
Electrostatic Contact : 4 kV (IEC1000-4-2Level2, EN61000-4-2Level2)
withstanding Airborne : 8 kV (IEC1000-4-2Level3, EN61000-4-2Level3)
voltages
Vibration resistance 10 - 57 Hz/Single-side amplitude or 0.075 mm
57 - 150 Hz/1.0 G in the X/Y/Z directions for 40 minutes
each
(Conforming to JIS C0040 and IEC68-2-6)
Shock resistance 10 G in the X/Y/Z directions for 11 ms; Half-sine wave
(Conforming to JIS C0041 and IEC68-2-27)
Structure
Physical dimension (mm) 210(W) x 40(D) x
166(H)
Panel cut dimensions (mm) 199.0(W) x
155.0(H)
Mountable panel thickness 1.6mm - 7mm
Weight 1.3kg
Waterproofing and Front part conforming to IP65
dust-proofing
*1 In the installed angle which is recommended
*2 Wet-bulb temperature 38ºC or lower.
*3 When using the optional AC adapter IPC-ACAP12-02.
Optical Display Specifications
Item Condition
φ=180°
Visual
φ=0°
angle
Display in
(vertical)
CR≥10
φ=+90°
monochrome
Visual
φ=-90°
angle
(horizontal)
Surface
brightness Display in white
(at center)
*1 Surface brightness is a numerical value in a display simple substance.
The brightness that let the touch panel pass serves as about 77% of the above-mentioned
numerical value.
*2 CR = Contrast ratio
o
( θ = 0 )
Left
o
( φ = -90
)
X
Bottom
o
( φ = 0 )
CAUTION
The above optical specification data shows optical
characteristics of the liquid crystal in the display; the data
does not represent the actual view on the display or its
viewing angles.
FPD-L71ST-DC1, FPD-H71XT-DC1
Specification
FPD-L71ST-DC1 FPD-H71XT-DC1
316(W) x 46.5(D) x 373(W) x 46(D) x
256(H) 304(H)
303.0(W) x 358.0(W) x
243.0(H) 289.0(H)
2.8kg 4.1kg
Specifications (25ºC Typ. Value)
FPD-S71VT-DC1 FPD-L71ST-DC1 FPD-H71XT-DC1
50deg 50deg 50deg
70deg 70deg 60deg
70deg 70deg 75deg
70deg 70deg 75deg
2 2
550cd/m 350cd/m 250cd/m
Measurement direction
Z
θ
Top
o
( φ = 180 )
φ
Module
Right
o
( φ = 90
)
Y
Options
Screen protective sheets
IPC-CV6
IPC-CV12
IPC-CV15
Display cable only for DVI-D
IPC-DVI/D-020
IPC-DVI/D-050
Display cable only for LVDS
FPD-26M26M-005 : LVDS cable (0.5m)
FPD-26M26M-020 : LVDS cable (2m)
FPD-26M26M-050 : LVDS cable (5m)
Conversion cable for SBC *1
FPD-20F26F
FPD-30F26F
*1 LVDS cable FPD-26M26M-005, FPD-26M26M-020 or FPD-26M26M-050 is required
separately.
Driver
IPC-SLIB-01
*2 You can download the driver from the CONTEC Web site (free of charge)
Others
IPC-ACAP12-02
2
IPC-SND-03
Recommendation Cable (Maker: SANWA SUPPLY INC.)
KU20-2H
KU20-5H
Packing List
Name
Flat panel display
Three-point sems screws (M3 x 6)
Power supply connector complete
set (Contact...4, housing...1)
Clamp for preventing cables from
being disconnected
The attachment fittings
AC adapter jack fixed clamp
IPC Precaution List
Waterproof packing Precaution List
Product guide
EU/FCC Declaration of Conformity
(Note) The manual of this product is being offered as PDF file on the CONTEC's Web site.
Each cable for this product is not bundled. Purchase it separately.
Life expectancy of consumable components
(1) Backlight ---
(2) Touch panel --- The operating lifetime of the touch panel
* CONTEC accepts your request for replacing each consumable in these products as a
request for repair (at an additional cost). Contact your local retailer or CONTEC sales
office.
: 6.5-inch [FPD-S71VT-DC1] screen
protective sheets (10 sheets)
: 12.1-inch [FPD-L71ST-DC1] screen
protective sheets (10 sheets)
: 15-inch [FPD-H71XT-DC1] screen
protective sheets (10 sheets)
: DVI-D cable (2m)
: DVI-D cable (5m)
: LVDS connector conversion cable
(20-pin header connector)
: LVDS connector conversion cable
(30-pin header connector)
: Driver & Utility Soft Set (CD-ROM version)
*2
: AC ADAPTER (DC12V)
Input : Voltage is 90 - 264VAC, current is
1.3A or less
(when the input voltage is 100VAC)
Output : Voltage is 12VDC, current is 4A.
: Desk stand
: USB cable for touch panel (2m)
: USB cable for touch panel (5m)
FPD-S71VT-DC1 FPD-L71ST-DC1
Pcs. Pcs.
1 1
1 1
1 set 1 set
2 1
4 6
1 1
1 1
1 1
1 1
1 1
Display brightness decreases over time
with use. The operating life of the
backlight (brightness reduced to 50% of
original) is 50,000 hours for all models.
(Assuming continuous operation at 25
degrees centigrade.)
is at least 1 million touches (as tested by
mechanical touching under 300g of force
at a rate of two presses per second).
Ver.1.11
FPD-H71XT-DC1
Pcs.
1
1
1 set
3
8
1
1
1
1
1
2
