- Page 1 IPC Series FLAT PANEL DISPLAY IPC-DT/L440(PC)TA, IPC-DT/L440(PC)TB User's Manual CONTEC CO.,LTD.
-
Page 2: Trademarks
Copyright 2003 CONTEC CO., LTD. ALL RIGHTS RESERVED No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. -
Page 3: Table Of Contents
Table of Contents Copyright................i Trademarks ..............i Table of Contents ............ii 1.Introduction ..............1 Features ...............1 Limited One-Year Warranty........2 How to Obtain Service..........2 Liability................2 Handling Precautions..........3 About the Manual ............4 2.Specifications ..............5 Function Specifications ...........5 General Specifications .............6 Optical Display Specifications.........7 3.Outside Dimensions and Part Names ......9 Outside Dimensions............9 Part Names ..............10... -
Page 4: Introduction
The display complies with the Panel Link specification and is intended for use with a host computer such as the CONTEC box computer series (BOXPC series) or SBC (single board computer) products. The following two versions of the display are available. -
Page 5: Limited One-Year Warranty
Please obtain a Return Merchandise Authorization Number (RMA) from the CONTEC group office where you purchased before returning any product. * No product will be accepted by CONTEC group without the RMA number. Liability The obligation of the warrantor is solely to repair or replace the product. -
Page 6: Handling Precautions
1. Introduction Handling Precautions Take the following precautions when handling this board. This display is made of the precise electric parts, so do not use or store it in the vicinity of impulse or vibration. - This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other applications that require a very high level of reliability. -
Page 7: About The Manual
1. Introduction - Although the display cable connector is able to rotate, it is not designed to be rotated continuously. Do not rotate the connector frequently as this may cause a fault. - A characteristic of analog touch panels is that the resistance varies with time and with changes in the surrounding conditions (temperature and humidity). -
Page 8: Specifications
2. Specifications 2. Specifications Function Specifications Table 2.1. Function Specifications Item IPC-DT/L440(PC)TA IPC-DT/L440(PC)TB Assembly type Desktop *1 or wall hanging Screen size 12.1 inches Number of pixels 800 x 600 dots Display type TFT color LCD Number of colors 262,144 colors... -
Page 9: General Specifications
2. Specifications General Specifications Table 2.2. General Specifications Condition Specifications Environment Ambient operating 0 - 45°C temperature Ambient storage -10 - 60°C temperature Ambient humidity 20 - 90%RH (No condensation ) Floating dust Normal Corrosive gas None Noise Line noise AC line: 2 kV (IEC1000-4-4Level3, EN61000-4-4Level3) resistance (Host: IPC-BX/M600(PCW)) -
Page 10: Optical Display Specifications
2. Specifications Optical Display Specifications Table 2.3. Optical Display Specifications Item Condition Min. Standard φ = 180° 30deg 50deg Visual angle (vertical) φ = 0° 40deg 70deg Display in CR≥10 φ = +90° monochrome Visual angle 40deg 70deg (horizontal) φ= -90° 40deg 70deg Surface... - Page 11 2. Specifications User’s Manual...
-
Page 12: Outside Dimensions And Part Names
3. Outside Dimensions and Part Names 3. Outside Dimensions and Part Names Outside Dimensions Center of display screen Center of device 75.4 [mm] Figure 3.1. Outside Dimensions of Main Unit User’s Manual... -
Page 13: Part Names
3. Outside Dimensions and Part Names Part Names Touch Panel Power Brightness adjustment control *Brightness adjustment Rotate the brightness adjustment control upwards to increase brightness and downwards to decrease brightness. bright dark PanelLink connector, AC adapter connector, external power supply connector The PanelLink connector can rotate backwards by 90°. -
Page 14: Connector Dimensions And Names
3. Outside Dimensions and Part Names Connector Dimensions and Names 75.4 23.1 11.1 External power supply connector PanelLink connector AC adapter connector External connector type: S2B-XH-A (J.S.T) Applicable connectors: XHP-2 (J.S.T) Figure 3.3. Connector Dimensions and Names User’s Manual... -
Page 15: Panel Link Connector
3. Outside Dimensions and Part Names Panel Link Connector Table 3.1. Panel Link Connector Panel Link interface connector Connector type 10220-6202JL(Manufactured by 3M) Model Pin No. Signal name Pin No. Signal name TX0- TXC- TX0+ TXC+ TX0 SHIELD TXC SHIELD TX2 SHIELD TX1 SHIELD TX2-... -
Page 16: Ac Adapter Connector (Dc-In Connector)
AC Adapter Connector (DC-IN Connector) The power supply jack for connecting the AC switching adapter. Do not use any AC adapter other than the correct CONTEC adapter (IPC-ACAP12-01) which is available as an option. Table 3.2. AC Adapter Connector (DC-IN Connector) -
Page 17: External Power Supply Connector
3. Outside Dimensions and Part Names External Power Supply Connector Table 3.3. External Power Supply Connector Connector type S2B-XH-A(JST) * Cable connectors Compatible connector : XHP-2 (JST) Pin No. Signal name Compatible contact : SXH-001-P0.6N(AWG#26-22) SXH-001-P0.6(AWG#28-22) +12V SXH-002-P0.6(AWG#30-26) Output: +12V, Current: 3.5A Note! When using an external power supply to supply +12VDC, ensure that the power on sequence is as follows. -
Page 18: Installation Procedure
4. Installation Procedure 4. Installation Procedure Securing the AC cord holder (1) Insert the plug from the AC adapter. Figure 4.1. Securing the AC Cord Holder < 1 / 3 > (2) Tighten the screw securing the AC cord holder. Figure 4.2. - Page 19 4. Installation Procedure Attaching the display unit Two different methods are available for attaching the display unit. (1) Hang display on screws Insert four M4 or equivalent truss screws or bind screws in the wall at the positions shown below. Use screws with large-diameter heads so as to securely hold the display unit.
- Page 20 4. Installation Procedure (2) Attach using screws from the rear of the panel Drill 4mm holes at the six locations on the panel shown below. Center of display screen Center of device Figure 4.6. Hole Positions Use M3 screws to attach the display using the six mounting holes. Note that the depth of the screw holes in the display may be no more than 4mm.
-
Page 21: Installation Cautions
4. Installation Procedure Installation Cautions (1) Dimension restriction when mounting in a recessed wall location 50mm Front Cable *: PanelLink cable DVI - panel link conversion display cable Side view Figure 4.8. Mounting in a Recessed Wall Location (2) Bending limit for cable 20mm 60mm or more Figure 4.9. -
Page 22: Connection To The Host Computer
5. Connection to the Host Computer 5. Connection to the Host Computer If using IPC or SBC products other than those listed here, refer to their respective manuals for details of the settings. PC-686BX(PC)-LV When using with this SBC board, set 1 to 4 of switch U2 on the board to all OFF. - Page 23 5. Connection to the Host Computer PC-586HU(PC)-LV When using with this SBC board, jumper JP8 on the board to all OFF. Note! Use this board along with the ISA bus type of LCD signal conversion board [ADPLNK(PC)H]. IPC-BX/M600(PCW) When using with this box computer, set the CRT/FPD setting in the Embedded window of the BIOS settings to "AUTO Select"...
-
Page 24: System Configuration And Connection Procedure
5. Connection to the Host Computer System Configuration and Connection Procedure To connect the display to a host computer, use the host computer's LCD connector and the connection cables(option). The figure below shows the IPC-BX/M600(PCW) as an example. IPC-BX/M600(PCW) IPC-BX/M630(PCI) Connection cables (option) IPC-BX/M600(PCW) series SPI-6941-LV... - Page 25 5. Connection to the Host Computer User’s Manual...
-
Page 26: Touch Panel
PC via the serial port on the CPU in the controller. When using the touch panel, either download from the CONTEC web site or obtain the IPC-SLIB-01 driver and utility software set CD-ROM (sold as a separate option). - Page 27 6. Touch Panel Communication format - Baud rate 9600 - Data length 8 bits - Parity Even parity - Stop bit 1 bit Notes! - The brightness adjustment function included in the utility program provided with the touch panel driver cannot be used with this display model.
-
Page 28: Options
7. Options 7. Options Double-sided screen protective sheets - IPC-CV12 (12.1-inch screen protective sheets: 10 sheets) Driver - IPC-SLIB-01 Driver & Utility Soft Set(CD-ROM version) Stand - IPC-SND-02 Desktop stand AC adapter - IPC-ACAP12-01 AC adapter with +12VDC output LCD signal conversion board - ADPLNK(PC)H Panel Link I/F board for SBC(ISA bus) Cable - IPC-PL2020-020 : Panel link cable (2 m) *1... - Page 29 7. Options User’s Manual...
- Page 30 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [02152005] [04012003] Management No. A-46-708 [02232005_rev3] Parts No.
