Contec IPC-DT 61 User Manual

Ipc series flat panel display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IPC Series
Flat Panel Display
IPC-DT/61 Series
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPC-DT 61 and is the answer not in the manual?

Questions and answers

Related Manuals for Contec IPC-DT 61

Summary of Contents for Contec IPC-DT 61

  • Page 1 IPC Series Flat Panel Display IPC-DT/61 Series User’s Manual CONTEC CO.,LTD.

  • Page 2: Trademarks

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Copyright ............................. i Trademarks ............................i Table of Contents..........................ii Introduction Features ............................... 1 Customer Support ..........................2 Web Site............................2 Limited One-Year Warranty....................... 2 How to Obtain Service ........................2 Liability .............................. 2 Safety Precautions ..........................2 Safety Information ........................
  • Page 4 Power Supply Connection AC input type ........................... 31 DC input type ........................... 32 Power Supply Connector ......................32 AC Adapter Jack........................33 AC adapter code removal prevention fitting ..................34 Screen Adjustment and a Setup Menu Screen ............................. 35 Direct Key............................40 Memory of a Setting Value ......................
  • Page 5 User’s Manual...

  • Page 6: Introduction

    1. Introduction This product is a dual-input (analog RGB and DVI-D), panel-mounted, color TFT LCD display unit for use with host computers such as the CONTEC IPC series and SBCs (single board computers). Features Full-bright, wide-angle-of-visibility type of liquid crystals capable of displaying up to 262,144 colors (16,777,216 colors on the IPC-DT/H61XT-DC1 and AC0) Standard analog RGB input for screen.

  • Page 7: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC Products are warranted by CONTEC CO., LTD.

  • Page 8: Safety Information

    Protect the touch panel against shock to prevent damage. CONTEC is not liable for a product that has been modified by the user. For this equipment, use the dedicated power supply unit if possible. If you connect any other power supply unit, be sure to select the one that satisfies the voltage and current capacity standards.
  • Page 9 (in the case of higher temperatures). CONTEC accepts your request for replacing each consumable in the PANECON-PC as a request for repair (at an additional cost). Contact your local retailer or CONTEC sales office. LCD Display Pixel Drop LCD display may have some pixels being dropped (bright and black spots) below a certain threshold.
  • Page 10 1. Introduction Connecting to a host with an existing touch panel function such as a CONTEC panel computer. This touch panel cannot be used with a touch panel mounted in the host computer. In this case, the touch panel function will be unavailable but screen display will still work normally.
  • Page 11 1. Introduction User’s Manual...

  • Page 12: Specifications

    *1 Optional desk stand IPC-SND-03 allowing desktop installation *2 If the output is from a CONTEC IPC series or SBC series model, an ISA bus type panel link I/F board (ADPLNK(PC)H) is required for some models. Please confirm before purchasing.
  • Page 13 2. Specifications Table 2.2. Power Supply Specifications (DC Input Type) Specification Item IPC-DT/S61VT-DC1 IPC-DT/M61VT-DC1 IPC-DT/L61SVT-DC1 IPC-DT/H61XT-DC1 Power supply input part 4-pin nylon connector for 12 VDC power supply Power supply connector AC adapter jack for 12 VDC power supply AC adapter jack (An optional AC adapter (IPC-ACAP12-01) can be used for 100 - 240VAC input.) Input power supply voltage...

  • Page 14: General Specifications

    2. Specifications General Specifications Table 2.4. General Specifications Item Specification Environment Operating 0 - 50ºC (0 - 40ºC when using an IPC-ACAP12-01 (AC switching adapter)) temperature Storage -10 - 60ºC temperature (20 - 80% when using an IPC-ACAP12-01 (AC switching adapter)) Operating humidity (No condensation allowed) Floating dust...

  • Page 15: Optical Display Specifications

    2. Specifications Optical Display Specifications Table 2.7. Optical Display Specifications Specifications (25ºC Typ. Value) Item Condition IPC-DT/S61VT-DC1 IPC-DT/M61VT-DC1 IPC-DT/L61SVT-DC1 IPC-DT/H61XT-DC1 IPC-DT/M61VT-AC0 IPC-DT/L61SVT-AC0 IPC-DT/H61XT-AC0 Visual angle φ=180° 45deg 50deg 50deg 45deg (vertical) φ=0° 35deg 70deg 70deg 55deg Display in CR≥10 monochrome Visual angle φ=+90°...

  • Page 16: Outside Dimensions And Part Names

    3. Outside Dimensions and Part Names 3. Outside Dimensions and Part Names Outside Dimensions IPC-DT/S61VT-DC1 4-M4 TAP (Maximum tapping length : 5mm) XXXXXXXXX MODEL : XXXXXXXXXXXXXXXXXX SERIAL No. : XXXXXXXXXXXXX INPUT : XXXXXXXXXXXXXXXXXX PASS XXXXXXXXX XXXXXXXXX CAUTION! ************* ******0.6N*m*** MENU POWER The screw bolting torque of attachment must be 0.6N-m(MAX)
  • Page 17 3. Outside Dimensions and Part Names IPC-DT/L61SVT-DC1 8-M4 TAP (Maximum tapping length : 5mm) MENU POWER M3 TAP (Maximum tapping 54.5 length : 5mm) [mm] Figure 3.3. Outside Dimensions of Main Unit (IPC-DT/L61SVT-DC1) IPC-DT/H61XT-DC1 ME NU E SC P OWER M3 TAP 8-M4 TAP (Maximum tapping...
  • Page 18 3. Outside Dimensions and Part Names IPC-DT/M61VT-AC0 8-M4 TAP (Maximum tapping length : 5mm) MENU POWER 216.2 67.5 [mm] Figure 3.5. Outside Dimensions of Main Unit (IPC-DT/M61VT-AC0) IPC-DT/L61SVT-AC0 8-M4 TAP (Maximum tapping length : 5mm) MENU POWER 67.5 54.5 [mm] Outside Dimensions of Main Unit Figure 3.6.
  • Page 19 3. Outside Dimensions and Part Names IPC-DT/H61XT-AC0 MENU ES C POWER 8-M4 TAP (Maximum tapping length : 5mm) [mm] Figure 3.7. Outside Dimensions of Main Unit (IPC-DT/H61XT-AC0) User’s Manual...

  • Page 20: Part Names

    3. Outside Dimensions and Part Names Part Names Front Screen & Touch panel MENU POWER Screen adjustment switch POWER LED Right side Left side Back USB touch panel connector Analog RGB connector XXXXXXXXX MODEL : XXXXXXXXXXXXXXXXXX SERIAL No. : XXXXXXXXXXXXX PA S S DVI-D connector INPUT :...
  • Page 21 3. Outside Dimensions and Part Names Front Screen & Touch panel MENU POWER Screen adjustment switch POWER LED Right side Left side Back USB touch panel connector Analog RGB connector DVI-D connector RS touch panel connector AC adapter jack +12VDC power connector Figure 3.9.
  • Page 22 3. Outside Dimensions and Part Names Front Screen & Touch panel MENU POWER Screen adjustment switch POWER LED Right side Back Left side USB touch panel connector Analog RGB connector DVI-D connector RS touch panel connector AC power supply terminals Figure 3.10.

  • Page 23: Analog Rgb Connector

    3. Outside Dimensions and Part Names Analog RGB Connector Table 3.1. Analog RGB Connector Connector type 15-pin HD-SUB (FEMALE) Pin NO. Signal name Pin NO. Signal name N.C. GREEN BLUE N.C. N.C. DDC DATA HSYNC R-GND VSYNC G-GND DDC CLK B-GND RS Touch Panel Connector This connector is RS-232C compliant to be used for touch panel data communication with the host...

  • Page 24: Usb Touch Panel Connector

    3. Outside Dimensions and Part Names USB Touch Panel Connector The USB connector for communication between the host computer and touch panel. Table 3.3. USB Touch Panel Connector Connector type USB Type B (Receptacle) Pin NO. Signal name Pin NO. Signal name DATA+ DATA-...

  • Page 25: Dvi-D Connector

    3. Outside Dimensions and Part Names DVI-D Connector Table 3.4. DVI-D Connect r o Connector DVI-I 24pin Pin No. Signal name Pin No. Signal name TMDS N.C. DATA2- TMDS DATA2+ TMDS DATA2 SHIELD N.C. TMDS N.C. DATA0- TMDS DDC CLK DATA0+ TMDS DATA0...

  • Page 26: Hardware Setup

    4. Hardware Setup 4. Hardware Setup Installation Requirements To maintain the ambient temperature within the installation environment requirement range, provide a gap of 30mm or more between the main unit and any adjacent equipment. Side view Panel 30mm or more(above) Bottom view 30mm or more(Side) Interface surface...
  • Page 27 4. Hardware Setup Panel thickness range: 1.6 to 7mm [mm] Figure 4.3. IPC-DT/M61VT-DC1, IPC-DT/M61VT-AC0 Panel Cut Dimensions R1 or less Panel thicknes range: 1.6 to 7mm [mm] Figure 4.4. IPC-DT/L61SVT-DC1, IPC-DT/L61SVT-AC0 Panel Cut Dimensions R1 or less [mm] Panel thickness range: 1.6 - 7mm Figure 4.5.

  • Page 28: Attaching The Fitting Used To Attach To The Main Unit

    4. Hardware Setup Attaching the Fitting Used to Attach to the Main Unit (1) Hold the main unit from the outside of the panel. Figure 4.6. Attaching the Fitting Used to Attach to the Main Unit < 1 / 2 > (2) Hold the attach from the inside of the panel.
  • Page 29 4. Hardware Setup User’s Manual...

  • Page 30: Connection To The Host Computer

    5. Connection to the Host Computer onnection to the Host Computer Purchase individual connection cables as they are not bundled with this equipment. Analog RGB Connection Connect the analog RGB input on this unit to the analog RGB connectors on the host computer. Table 5.1.

  • Page 31: Dvi-D Connection

    Connect the DVI-D input on this unit to the DVI-D connector on the host computer or the PanelLink connector. You can use a CONTEC IPC series or SBC (single board computer) as the host computer. In this case, settings are required on each host computer.
  • Page 32 5. Connection to the Host Computer When connecting to a PC-686E(PC)-LV To use this SBC board with the display, set the on-board rotary switch as shown below. Table 5.4. Rotary Switch Setting Number IPC-DT/S61VT-DC1 IPC-DT/M61VT-DC1 IPC-DT/L61SVT-DC1 IPC-DT/H61XT-DC1 IPC-DT/M61VT-AC0 IPC-DT/L61SVT-AC0 IPC-DT/H61XT-AC0 CAUTION When using this board, also use an ISA bus type panel link I/F board (ADPLNK(PC)H).
  • Page 33 5. Connection to the Host Computer When connecting to a IPC-BX/M600(PCW) Series If using this box computer, set the "Embedded" - "CRT/FPD" BIOS setting to "AUTO Select" or "SW Select". If you select "SW Select", set the switch (S1) on the box computer board as shown below. Table 5.7.

  • Page 34: Touch Panel Data Communications

    CONTEC CAUTION The RS-232C cable is not required if using the DVI-D input with a CONTEC host computer because the DVI-D interface includes the RS-232C signal lines. Note that connecting the RS-232C cable causes the touch panel to stop working.
  • Page 35 5. Connection to the Host Computer User’s Manual...

  • Page 36: Power Supply Connection

    6. Power Supply Connection 6. Power Supply Connection Two versions of this product are available that use AC input and DC input respectively for the power supply. The power supply connector consists of a terminal block on the AC input type and a power supply connector and AC adapter jack on the DC input type.

  • Page 37: Dc Input Type

    6. Power Supply Connection DC input type Power Supply Connector When connecting the power supply, ensure that the supply satisfies the specifications below. Power supply voltage: +12VDC 5% Power supply capacity: 2.5A or more The table below lists the pin specifications of the power connector on the back of the equipment. Table 6.2.

  • Page 38: Ac Adapter Jack

    6. Power Supply Connection AC Adapter Jack The AC adapter jack is used to connect the AC adapter [IPC-ACAP12-01] available as an option. Do not connect any AC adapter other than the option. +12V Figure 6.1. AC Adapter Jack User’s Manual...

  • Page 39: Ac Adapter Code Removal Prevention Fitting

    6. Power Supply Connection AC adapter code removal prevention fitting (1) Insert the plug of AC Adapter. (2) Tighten the screws on the attachment fitting. Figure 6.2. Code Removal Prevention Fitting User’s Manual...

  • Page 40: Screen Adjustment And A Setup

    7. Screen Adjustment and a Setup 7. Screen Adjustment and a Setup The equipment has screen adjustment switches [MENU], [+], and [-]. Use these switches to adjust the screen. (For the locations of the switches, see “Part Names” in Chapter 3.) When using the equipment for the first time or after changing the output screen mode of the host computer, execute AUTO ADJUST first on the menu screen.
  • Page 41 7. Screen Adjustment and a Setup DISPLAY ADJUST: Adjusts the display position. Selecting this item displays a sub-menu. Use [+] and [-] to move between items and [MENU] to select. S C R E E N M A N A G E R H .
  • Page 42 7. Screen Adjustment and a Setup COLOR CONTROL: Adjusts the color temperature. Selecting this item displays a sub-menu. Use [+] and [-] to move between items and [MENU] to select. You can select USER COLOR MODE to adjust RED, GREEN, and BLUE manually. S C R E E N M A N A G E R 9 3 0 0 6 5 0 0...
  • Page 43 7. Screen Adjustment and a Setup TOUCHPANEL: Select this item to adjust the status of the touch panel. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made. S C R E E N M A N A G E R O N / O F F D I S P L A Y I D...
  • Page 44 7. Screen Adjustment and a Setup INPUT SOURCE: Selects the input signal. Selecting this item displays a sub-menu. Use [+] and [-] to move between items and [MENU] to select. S C R E E N M A N A G E R A N A L O G R G B D V I A N A L O G R G B...

  • Page 45: Direct Key

    7. Screen Adjustment and a Setup Direct Key CONTRAST Pressing the [+] key when the menu is not displayed opens the contrast adjustment screen. BRIGHTNESS The brightness of the backlight can be adjusted by pressing the [+] and [-] keys without the menu screen displayed.

  • Page 46: Led Indicators

    8. LED Indicators 8. LED Indicators The POWER LED on the front face indicates each state of the display as follows: Table 8.1. LED Indicators LED status Description The power supply off or the equipment not started normally Green(ON) Normal operation Green Power save mode (Flashing)
  • Page 47 8. LED Indicators User’s Manual...

  • Page 48: Touch Panel

    Before the touch panel can be used, touch panel driver software must be installed. Note that the driver software is not bundled with this product. Purchase the one separately or download it from the CONTEC’s web site. For further details, refer to the READ_ME file for each driver.

  • Page 49: Usb Multi-Touch Panel

    Figure 9.2. Example of connection of a USB multi-touch panel You can use a CONTEC IPC-PT/600 series panel computer as the host PC. In this case, the ID of the touch panel in the panel computer is fixed at ID7. Set the IDs of the external displays in the range USB ID0 - USB ID6 (a maximum of seven external displays can be connected).

  • Page 50: Display Mode

    10. Display Mode 10. Display Mode This equipment supports the following display modes: Table 10.1. Analog RGB Input - Display Modes Display Horizontal Vertical Video Number of Dot clock frequency frequency pixels (dot) (MHz) mode (kHz) (Hz) Ο Ο Ο Ο...
  • Page 51 10. Display Mode CAUTION The number of display pixels in the LCD is 640 x 480 dots on the IPC-DT/S61VT-DC1, IPC-DT/M61VT-DC1, and IPC-DT/M61VT-AC0 models, 800 x 600 dots on the IPC-DT/L61SVT-DC1 and IPC-DT/L61SVT-AC0 models and 1024 x 768 on the IPC-DT/H61XT-DC1 and IPC-DT/H61XT-AC0 models.

  • Page 52: Options

    11. Options 11. Options Screen protective sheets IPC-CV6 : 6.4-inch screen protective sheets (10 sheets) IPC-CV : 10-inch screen protective sheets (10 sheets) IPC-CV12 : 12.1-inch screen protective sheets (10 sheets) IPC-CV15 : 15-inch screen protective sheets (10 sheets) Cable IPC-DVI/D-020 : DVI-D cable (2m) IPC-DVI/D-050...
  • Page 53 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [09142007] [04202004] Management No. A-46-795 [09142007_rev7] Part No.

This manual is also suitable for:

Ipc-dt/65 seriesIpc-dt/61 seriesIpc-dt/s61vt-dc1Ipc-dt/m61vt-dc1Ipc-dt/m61vt-ac0Ipc-dt/l61svt-dc1 ... Show all
