Item # 1002 691 860
1002 691 861
Model # FCS80208AHST
USE AND CARE GUIDE
BELLEVILLE PADDED 3-PIECE HIGH BISTRO SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
aced in Hampton Bay through the purchase of this bistro set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BELLEVILLE FCS80208AHST and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY BELLEVILLE FCS80208AHST

Summary of Contents for HAMPTON BAY BELLEVILLE FCS80208AHST

  • Page 1 THANK YOU aced in Hampton Bay through the purchase of this bistro set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Pre-Assembly................3 Table of Contents............2 Planning Assembly..............3 Safety Information ............2 Hardware Included..............3 Product Caution ..............2 Safety Warnings ...............2 Chair Package Contents............4 Warranty ................2 Table Package Contents............5 What is Covered................2 Chair Assembly..............6 Table Assembly............11 What is Not Covered..............2 Care and Cleaning............13 Safety Informa...

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size.

  • Page 4: Chair Package Contents

    Pre- Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair back Right arm Left arm Chair seat Back bar Front bar...
  • Page 5 Pre- Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Tile Table rim Leg connector Table leg HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.

  • Page 6: Chair Assembly

    Chair Assembly Attaching the chair arms to the chair seat Attach the right arm (B) to the front of the chair seat (D) using an M6x30 combination bolt (BB). Attach the right arm (B) to the back of the chair seat (D) using M6x20 combination bolts (AA). Repeat this step to attach the left arm (C) to the chair seat (D).
  • Page 7 Chair Assembly (continued) Attaching the chair back to the chair arms Insert M6x30 combination bolts (BB) through the chair back (A), and into the chair arms (B and C). NOTE: Loosely tighten all bolts using the hex wrench (DD). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8 Chair Assembly (continued) Securing the back bar Secure the back bar (E) to the two arms (B and C) using M6x20 combination bolts (AA).
  • Page 9 Chair Assembly (continued) Securing the front bar Secure the front bar (F) to the two legs (B and C) using M6x20 combination bolts (AA). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Chair Assembly (continued) Tightening all bolts Once all bolts are in place, fully tighten all bolts. Ensure all connections are secure before use.
  • Page 11 Table Assembly Connecting the table legs Place the table rim (H) upside down on a soft surface. Align the holes on the table legs (J) to the holes on the table rim (H) and secure the legs in place using M6x20 combination bolts (AA). NOTE: Loosely tighten all bolts using the hex wrench (DD).
  • Page 12 Table Assembly (continued) Connecting the leg connector to the table legs Align the holes of the leg connector (I) with the holes on the inside of each table leg (J). Connect the leg connector (I) to the table legs (J) using M6x15 combination bolts (CC). NOTE: Loosely tighten all bolts using the hex wrench (DD).

  • Page 13: Care And Cleaning

    Table Assembly (continued) Tightening the bolts Tighten all the bolts. Turn the table right side up. Ensure all connections are secure. Carefully place the tiles (G) on the table. Care and Cleaning For best results, clean the bistro set with a damp cloth and dry the set thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 14 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
