Item # 1001 869 382
Model # FCS80231RL
USE AND CARE GUIDE
BELLEVILLE GLIDER
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this glider. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY FCS80231RL
Summary of Contents for HAMPTON BAY FCS80231RL
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
- Page 2 Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Assembly ............... 5 Warranty ................
- Page 3 Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Part Description Description Quantity Quantity Sling bucket Right arm Left arm Glider base...
- Page 5 Assembly CONNECTING THE GLIDER ARMS TO THE SLING BUCKET Attach the right arm (B) to the front of the sling bucket (A) using an M6x20 combination bolt (AA). Attach the right arm (B) to the back of the sling bucket (A) using M6x30 combination bolts (BB). Repeat above steps to attach the left arm (C) to the sling bucket (A).
- Page 6 Assembly (continued) CONNECTING THE GLIDER BASE TO THE ARMS Attach the glider base (D) to the glider arms (B & C) using M6x18 countersunk bolts (CC) and M6 plastic washers (DD). NOTE: Loosely tighten all the bolts using the hex wrench ( EE).
- Page 7 Assembly (continued) TIGHTENING ALL BOLTS AND CHECKING THE GLIDER Once all of the bolts are in place, fully tighten the bolts. Turn the glider right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
