Metallurgical Motorized Microscope
With Auto-Focus System
BS-6020DRF/DTRF
User Manual
It is recommended strongly that you study this manual thoroughly before using the microscope. Retain
this manual in an easily accessible place near the work desk for future reference.
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS-6020DRF and is the answer not in the manual?

Questions and answers

Related Manuals for BestScope BS-6020DRF

Summary of Contents for BestScope BS-6020DRF

  • Page 1 Metallurgical Motorized Microscope With Auto-Focus System BS-6020DRF/DTRF User Manual It is recommended strongly that you study this manual thoroughly before using the microscope. Retain this manual in an easily accessible place near the work desk for future reference.

  • Page 2: Table Of Contents

    Contents Contents Contents Contents Contents User Notice ………………………………………………………… 2 1. Components ……………………………………………………4 2. Assembly ………………………………………………………6 3. Adjustment ………………………………………………………15 4. Observation Steps ………………………………………………16 5. Adjustment Operation …………………………………………17 6. Control Box Menu Setting ………………………………………24 7. Observation Methods …………………………………………27 8. Specification ……………………………………………………29 9. Troubleshooting Guide……………………………………………30...

  • Page 3: User Notice

    User User Notice Notice User User Notice Notice User Notice Ⅰ..Safety Safety Safety Safety note note note note The microscope has been adjusted at the factory according to the standard slide, and all components are in the right initial position. If you want to use non-standard slide, please refer to Chapter 6, "Control Box Menu setting ", and section 6-2-6 to re-adjust.
  • Page 4 6. When using, if the microscope is splash by liquid, cut off the power at once, and wipe up the moisture. 7. Do not disassemble any parts of the microscope. That will affect the function or decline the performance of the microscope. 8.

  • Page 5: Components

    1. 1. 1. 1. Components Components Components Components 1. Components Front View . Name Of Components Lamp House Camera Video Adapter Light Path Selector Lever Filter Insertion Slot (The filter Eyepiece(Ocular) 目镜 滤色片插槽 should be inserted from the （从左侧插入） left) ND 滤色片拉杆...
  • Page 6 1. 1. 1. 1. Name Name Name Components Components Name Of Of Components Components Control Panel ① Display Panel ⑩Function Buttons ②Z-axis Lift Wheel ⑧ Real-Focus Button Cancel Cancel Cancel Cancel ○ RTF OFF ⑨ RTF Status Indicator ZAxis LUM ZAxis ZAxis ZAxis ●...

  • Page 7: Assembly

    2 2 2 2 ..Assembly Assembly Assembly Assembly 2. 2. 2. 2. Assembly Assembly Assembly Assembly 2.1 Assembly Diagram 2.1 Assembly Diagram The following figure shows the installation sequence of the components. The number in the figure shows the assembly steps.
  • Page 8 2.2 Assembly Step 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.1 Installing Stage Support Device Before installing the device, be sure to adjust the coarse focus knob. Make the guide board (see figure 1)down to the limit position, so you can install the mechanical stage support device easily.
  • Page 9 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.2 Installing the reflected light brightfield / darkfield illuminatior Installing the reflected light illuminator (fig.4) on the head of microscope body (fig.5), and turn to a proper position, then screw down the bolt⑥ to fix it.
  • Page 10 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.4 Installing the Lamp House Installing Installing Installing Installing the the Lamp Lamp Lamp Lamp House House House House 1 1 1 1 (indecent (indecent (indecent (indecent light light...
  • Page 11 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.5 Replacing the the Lamp ★ The specified specified halogen halogen Lamp Lamp Lamp is is is is the the 2 2 2 2 4V The specified specified halogen halogen Lamp...
  • Page 12 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.6 Installing the lead screw platform ① Adjust the coarse focus knob. Make the stage support device (Fig.13 ③ )down to the lowest position,soyou can install the lead screw platform easily.
  • Page 13 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step 2.2.8 Installing the Vedio Adapter ① ② ③ Insert the video adapter (Fig.15 ①) into the trinocular viewing unit, then screw down the bolt ② to fix them.( as shown in fig.15). 2.2.9 Installing the Eyepiece Fig.15 Insert the eyepiece (Fig.15 ③) into the eyepiece...
  • Page 14 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step ④ 2.2.12 Connection Cable and Power Cord cable cable cords cords vulnerable vulnerable The cable cable cords cords are are vulnerable vulnerable when when when when benting benting benting...
  • Page 15 2 2 2 2 ..Assembly Assembly Assembly Assembly 2.2 Assembly Step Do use use the the specified specified specified specified power power power power cord cord cord cord allthe allthe allthe allthe time. time. time. time. Do not not plug plug...

  • Page 16: Adjustment

    3 3 3 3 ..Adjustment 3 3 3 3 ..Adjustment Adjustment Adjustment Adjustment Adjustment Adjustment Adjustment 视度调节环 Diopter Ring Optical Switch Push Rod 光路切换推拉杆 ND Filter Lever Interpupillary 瞳距刻度 Distance Scale 平台控制触摸板 Platform Control TouchPad Operate Keyboard 操作键盘...

  • Page 17: Observation Steps

    4 4 4 4 ..Observation 4 4 4 4 ..Observation Observation Observation Observation Steps Steps Steps Observation Observation Steps Observation Steps Steps Steps Steps Install microscope followingthe assembly steps. Turn on the power switches on the main body and the control boxes eparately ( as shown as ①...

  • Page 18: Adjustment Operation

    5. Adjustment Operation 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation 5.1 Turn on the power 5.1 Turn on the power 1.Turn on the power switches on the main body and the control boxes eparately ( as shown as ① in Fig.20 and ②...
  • Page 19 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation 5.4 Place the Specimen ② ① ③ Place Specimen 5.4 Place Place Place the the Specimen Specimen Specimen 1. Fix the specimen (fig.25②) to the sample by plasticine (fig.25 ③...
  • Page 20 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation 5.5 Adjust the Interpupillary Distance 5.5 Adjust the Interpupillary Distance The interpupillar distance range: 48mm～75mm. When observing with two eyes, hold on the left and right prism holder, turn the axis, adjust the interpupillary distance until the left and right fields of view coincide completely.
  • Page 21 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation 5.8 Switch the Optical Path When the optical switch push rod of the trinocular 5.8 Switch the Optical Path viewing unit ( fig.32 ① ) is pushed in, all the light enter the binocular tube, so you can do the binocular observation.
  • Page 22 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation Usable Filters Applications Turns the illumination light into daylight. Color temperature conversion filter Used in general observations and color photography. Green filter Enhanced contrast in monochrome observation. Used in monochrome photography Yellow filter Contrast filter for observation of semiconductor wafers...
  • Page 23 5 5 5 5 ..Adjustment Adjustment Adjustment Operation Operation Adjustment Operation Operation 5.11 Select the Light Path of the Trinocular 5.11 Select the Light Path of the Trinocular Tube Tube Slide the mirror selector lever (fig.36 ① ) toward the indication of the mirror for the desired observation method.
  • Page 24 5 5 5 5 ..Adjustment Adjustment Operation Adjustment Operation Adjustment Operation Operation 5.13 Center the Aperture Iris Diaphragm 5.13 Center the Aperture Iris Diaphragm (AS) (AS) 1. Slide the mirror selector lever (fig.36 ①) to “BF”. 2.

  • Page 25: Control Box Menu Setting

    6.Control Box Menu Setting 6.Control 6.Control Menu Menu Setting Setting 6.Control 6.Control Box Box Menu Menu Setting Setting 6.1 Main Menu 6.1 Main Menu You can enter the Main Menu Setting by pressing 1.Moto 1.Moto 1.Moto 1.Moto 2.Sensor 2.Sensor 2.Sensor 2.Sensor the OK key.
  • Page 26 6.Control 6.Control Menu Menu Setting Setting 6.Control 6.Control Box Box Menu Menu Setting Setting 6.2 Sub Menu 6.2.3 LUM SET(initial brightness setting) LUM SET is used to set the startup Luminance Initial Luminance: Initial Initial Initial Luminance: Luminance: Luminance: value. The value can be set from 0 to 99. Use up and down arrow, or roll the Z-Axis Wheel to change the value.
  • Page 27 6. 6. 6. 6. Control Control Control Menu Menu Setting Setting Control Box Box Menu Menu Setting Setting 6.2 Sub Menu 6.2.6 AF SET ( Auto Focus reference position setting) 5X-AF 5X-AF 10X-AF 10X-AF 20X-AF 20X-AF 20X-AF > > > > 5X-AF 5X-AF 10X-AF 10X-AF 20X-AF...

  • Page 28: Observation Methods

    7. 7. 7. 7. Observation Observation Observation Metheods Metheods 7. Observation Metheods Observation Metheods Metheods Relected Light Brightfield/Darkfield Observation 7.1 Relected Relected Relected Light Light Light Brightfield/Darkfield Brightfield/Darkfield Brightfield/Darkfield Observation Observation Observation 7.1 Relected Light Brightfield/Darkfield Observation ◎ The following flow shows the basic operating procedure for reflected light brightfield or darkfield observation.
  • Page 29 7.2 Reflected Light Simplified Polarized Light Observation 7. 7. 7. 7. Observation Observation Observation Metheods Metheods Observation Metheods Metheods 7.2 Reflected Light Simplified Polarized Light Observation 1. Setting the Analyzer and Polarizer (Fig. 15). 2. Place the specimen on the stage and adjust the focus by moving the stage up or down. Now simplified polarized lightobservation can be started.

  • Page 30: Specification

    Specification Specification Specification Specification Specification Specification Specification 8.1 Configuration table of the microscope 8.1 Configuration table of the microscope . Specifications BS-6020DRF BS-6020DTRF Infinite Optical System Optical system ● ● Exceed wide field ocular EW10X/22, tubeΦ30 Eyepiece (Ocular) ● ●...

  • Page 31: Troubleshooting Guide

    9. Troubleshooting Guide 9. 9. 9. 9. Troubleshooting Troubleshooting Troubleshooting Guide Guide Troubleshooting Guide Guide 9.1 Optical Part 9.1 Optical Part REASON REASON REASON REASON FOR PROBLEM PROBLEM SOLUTION SOLUTION PROBLEM PROBLEM SOLUTION SOLUTION PROBLEM PROBLEM PROBLEM PROBLEM The aperture or field iris Open aperture field...
  • Page 32 9. 9. 9. 9. Troubleshooting Troubleshooting Troubleshooting Guide Guide Troubleshooting Guide Guide 9.2 Mechanical Part 9.2 Mechanical Part REASON REASON REASON REASON FOR PROBLEM PROBLEM PROBLEM PROBLEM SOLUTION SOLUTION SOLUTION SOLUTION PROBLEM PROBLEM PROBLEM PROBLEM tension adjustment Loose properly collar is too tight The coarse focus knob is hard to run Pre-focusing...
  • Page 33 BestScope BestScope International International Limited Limited company company reserve reserve the the right improvements improvements improvements improvements on on the...
