Original operating manual
Mounted seeding combination
Avant seeding unit 4002-2
Avant seeding unit 5002-2
Avant seeding unit 6002-2
SmartLearning
www.amazone.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Avant 4002-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amazone Avant 4002-2

  • Page 1 Original operating manual Mounted seeding combination Avant seeding unit 4002-2 Avant seeding unit 5002-2 Avant seeding unit 6002-2 SmartLearning www.amazone.de...
  • Page 2 Please enter the identification data of the implement. The identification data can be found on the rating plate.
  • Page 3: Table Of Contents

    Description of the warning symbols 6.2.1 Coupling the supply lines to the Threaded cartridge front-mounted hopper Mounting frame 6.2.2 Coupling the hydraulic hose lines Universal operating tool 6.2.3 Coupling the power supply MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 4 Checking the RoTeC furrow former Starting work with one part-width 10.1.9 Cleaning the segment distributor section head Using the implement 10.1.10 Checking the top link pin and lower link pin Checking the placement depth MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 5 10.3 Cleaning the implement 11 Loading the machine 11.1 Lashing the machine 11.2 Lifting the implement 12 Appendix 12.1 Bolt tightening torques 12.2 Other applicable documents 13 Directories 13.1 Glossary 13.2 Index MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 7: About This Operating Manual

    CAUTION Indicates a threat with low risk for light or moderately severe physical injuries. 1.1.2 Further instructions CMS-T-00002416-A.1 IMPORTANT Indicates a risk for damage to the implement. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 8: Instructions

    CMS-T-005678-B.1 Reactions to instructions are marked with an arrow. Example: 1. Instruction 1 Reaction to instruction 1 2. Instruction 2 1.1.3.2 Alternative instructions CMS-T-00000110-B.1 Alternative instructions are introduced with the word "or". MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 9: Lists

    Lists without an essential order are shown as a list with bullets. Example: Point 1 Point 2 1.1.5 Item numbers in figures CMS-T-000023-B.1 A framed number in the text, e.g. a 1 , indicates an item number in an adjacent figure. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 10: Other Applicable Documents

    Your suggestions for improvement help us Technische Redaktion to create ever more user-friendly operating manuals. Postfach 51 Please send us your suggestions by post, fax or D-49202 Hasbergen email. Fax: +49 (0) 5405 501-234 E-Mail: td@amazone.de MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 11: Safety And Responsibility

    2.1.2.1.1 Requirements for all persons working with the machine CMS-T-00002310-A.1 If the machine is used improperly, people can be injured or killed. To prevent accidents due to improper use, every person who works with MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 12 Farmers are basically familiar with working with agricultural implements and can instruct agricultural helpers in how to use the implements if necessary. They can perform odd tasks and simple maintenance and repair work on agricultural implements themselves. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 13 Passengers can fall, be run over and severely injured or killed due to machine movements. Ejected objects can hit and injure passengers. Do not let anybody ride on the machine. Do not let anybody climb onto the driving machine. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 14 Non-observance of the technical limits values of the machine can result in accidents and serious personal injury or even death. Moreover, the machine can be damaged. The technical limit values can be found in the Technical Data. Comply with the technical limit values. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 15 Missing warning symbols increase the risk of serious and lethal personal injury. Clean dirty warning symbols. Immediately replace any damaged and illegible warning symbols. Put the intended warning symbols on spare parts. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 16: Knowing And Preventing Dangers

    Never look for leaks with your bare hands. Keep your body and face away from leaks. If liquids penetrate the body, consult a doctor immediately. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 17: Safe Operation And Handling Of The Machine

    Use only suitable tractors for coupling and transporting the implement. When the implement is coupled onto the tractor, make sure that the tractor's connecting device meets the implement requirements. Couple the implement properly to the tractor. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 18 If the machine is not properly prepared for road travel, it can result in serious traffic accidents. Check the lighting and identification for road travel for proper function. Remove coarse dirt from the implement. Follow the instructions in the section "Preparing the implement for road travel". MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 19: Safe Maintenance And Modification

    To ensure that the operating permit remains valid in accordance with national and international regulations, ensure that the specialist workshop only uses conversion parts, spare parts and special equipment approved by AMAZONE. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 20 Remove the ignition key and carry it with you. Remove the key from the battery circuit breaker. Wait until all parts that are still running come to a stop and that hot parts cool down. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 21 Never linger under raised implement parts. If you have to work on or under raised machine parts, lower the implement parts or secure the raised implement parts with a mechanical support or hydraulic locking device. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 22 CMS-T-00002325-B.1 Special equipment, accessories, and spare parts Special equipment, accessories, and spare parts that do not meet AMAZONE requirements can impede the operational safety of the implement and cause accidents. Only use original parts or parts that meet AMAZONE requirements.
  • Page 23: Safety Routines

    If you are not sure if the protective equipment is properly installed and functional, have the protective equipment checked by a qualified specialist workshop. Make sure that the protective devices are properly installed and functional before any work on the implement. Replace damaged protective equipment. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 24 When climbing up and down, never hold onto the control elements. Accidental actuation of control elements can unintentionally activate potentially dangerous functions. When climbing down, never jump off of the machine. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 25: Intended Use

    AMAZONE. Uses other than those specified under the intended use are considered as improper. The manufacturer is not liable for any damage resulting from improper use, solely the operator is responsible. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 26: Product Description

    Road safety bars in parking position Rear-facing lighting in parking position Tramline marker Harrow Seeding coulter Work lights 10 Placement depth adjustment Additional license plate 11 Threaded cartridge 12 Job computer 13 Supply hoses MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 27: Function Of The Implement

    The seeding coulter 4 forms a seed furrow and deposits the metered material in the seedbed. 4.3 Special equipment CMS-T-00004328-C.1 Tramline marker Lighting and identification for road travel LED work lights LED coulter array lighting TwinTeC depth control wheel scraper MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 28: Protective Equipment

    Seed tube monitoring Electric one-sided switching 4.4 Protective equipment CMS-T-00004322-B.1 4.4.1 Road safety bars CMS-T-00010564-A.1 The road safety bars 1 cover the tines of the harrow to protect against injury and damage. CMS-I-00005527 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 29: Warning Symbols

    A warning symbol consists of two fields: Field 1 shows the following: A pictogram depicting the danger area, CMS-I-00000416 surrounded by triangular safety symbol The order number Field 2 shows a pictogram depicting how to avoid the danger. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 30: Description Of The Warning Symbols

    CMS-I-00003657 MD 275 Risk of crushing due to the pack top implement falling over Install the parking supports before you park the pack top implement. MD275 CMS-I-00004915 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 31: Threaded Cartridge

    2 mounts. CMS-I-00003160 For implements with 2 distributor heads, the seeding unit is also connected to the roller frame at each distributor head with an angle bracket 1 . CMS-I-00003161 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 32: Universal Operating Tool

    4.9 Rear lighting and identification for road travel CMS-T-00001498-F.1 Warning signs Reflector, red Rear lights, brake lights, and turn indicators Reflector, yellow CMS-I-00004545 NOTE The lighting and identification for road travel can vary depending on the national regulations. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 33: Electronic Drive Monitoring

    CMS-I-00002953 4.11 Transport frame CMS-T-00004060-B.1 To reduce the tractor rear axle load, the rotary cultivator is connected to the transport frame 1 . CMS-I-00003162 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 34: Additional License Plate

    A maximum of twelve tramline segments can be controlled per distributor head. The tramline segments in the segment distributor CMS-I-00003165 head can be expanded, repositioned or replaced with segments without flaps. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 35: Twintec Coulter

    For soil tillage without seeding, the coulters can be lifted. CMS-I-00004578 The Control 25 depth control wheel 1 has a 25 mm- wide contact area and enables shallow seeding with increased coulter pressure on light soils. CMS-I-00004586 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 36: Coulter Harrow

    4.16 Coulter harrow CMS-T-00006648-A.1 The harrow tines 1 of the coulter harrow cover the deposited metered material evenly with loose soil. The pitch and the height of the harrow tines can be adjusted. CMS-I-00004734 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 37: Exact Following Harrow

    Depending on the implement equipment, a different number of discs can be installed on the implement. The track width and the pitch of the track discs can be adjusted. CMS-I-00003167 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 38: Work Lights

    CMS-I-00003173 The coulter array lighting 1 enables better visibility of the seeding coulters in the dark. The coulter array lighting is switched together with the work floodlights via the control terminal. CMS-I-00003174 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 39: Rating Plate On The Implement

    CMS-I-00004418 The mySeeder app can be obtained from the Apple App Store or the Google Play Store. To do so, use the QR code or the link www.amazone.de/ qrcode_mySeeder. CMS-I-00004417 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 40: Technical Data

    5.3 Soil tillage tool CMS-T-00004355-C.1 Seeding unit Dimensions with RoTeC coulters with TwinTeC coulters Cutting disc diameter 32 cm 40 cm Placement depth 0 cm to 6 cm 0 cm to 6 cm MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 41: Permitted Mounting Categories

    Starting at 118 kW / 160 PS Avant 5002-2 seeding unit Starting at 147 kW / 200 PS Avant 6002-2 seeding unit Starting at 176 kW / 240 PS Electrical system Battery voltage 12 V Lighting socket 7-pin MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 42: Noise Development Data

    On right in direction of travel Up the slope and down the slope Up the slope Down the slope 5.10 Lubricants CMS-T-00002396-B.1 Manufacturer Lubricant ARAL Aralub HL2 FINA Marson L2 ESSO Beacon 2 SHELL Retinax A MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 43: Preparing The Machine

    Total weight of front-mounted implement or front ballast Permissible total weight of rear-mounted implement or rear ballast Distance between the centre of gravity of the front-mounted implement or the front ballast and the centre of the front axle MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 44 T b 0,2 T b Vmin Vmin Vmin CMS-I-00000513 2. Calculate the actual front axle load. × × - × G a b T b G c + d Vtat Vtat Vtat CMS-I-00000516 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 45 Tyre load according to according to capacity for two tractor operating calculation tractor tyres manual ≤ Minimum front ballasting ≤ Total weight ≤ ≤ Front axle load ≤ ≤ Rear axle load MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 46: Coupling The Implement

    CMS-I-00000121 Type of actuation Function Symbol Latching Permanent oil circulation Oil circulation until action is Momentary executed Free oil flow in the tractor control Floating unit MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 47 Risk of injury or even death If the hydraulic hose lines are incorrectly connected, the hydraulic functions may be faulty. When coupling the hydraulic hose lines, observe the coloured markings on the hydraulic plugs. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 48 4. Route the hydraulic hose lines with sufficient freedom of movement and without chafing points. CMS-I-00001045 5. Depending on the implement equipment, couple the pressureless return flow 1 of the front hopper onto the soil tillage implement. CMS-I-00007203 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 49: Coupling The Power Supply

    2. Couple the lower links 1 from the tractor seat. 3. Couple the top link 2 . 4. Check whether the top link catch hooks 3 and lower link catch hooks 4 are correctly locked. CMS-I-00001225 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 50: Coupling The Avant Seeding Unit

    CMS-I-00003131 3. Install the bolts 1 on all of the brackets 2 . The brackets are connected to the roller frame. 4. Put on the nuts 3 and tighten them. CMS-I-00003177 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 51 3 on both sides. 14. Unfold the soil tillage implement with the coupled seeding unit. 15. Park the soil tillage implement with the coupled seeding unit on a level surface. CMS-I-00003116 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 52 18. Connect the supply line 1 for the rotary cultivator monitoring. CMS-I-00003128 19. Connect the "green" tractor control unit of the soil tillage implement 2 to the Comfort hydraulic system of the seeding unit 1 . CMS-I-00003127 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 53 1. Slowly drive the tractor with the coupled soil tillage implement under the seeding unit. 2. Slowly lift the soil tillage implement. The bracket 1 is resting on the roller frame 2 of the soil tillage implement. CMS-I-00007099 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 54 3. Install the bolts 1 on all of the brackets 2 . The brackets are connected to the roller frame. 4. Put on the nuts 3 and tighten them. CMS-I-00003177 5. Swivel up the distributor head. 6. Install the bolts 1 . CMS-I-00007114 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 55 3 on both sides. 15. Unfold the soil tillage implement with the coupled seeding unit. 16. Park the soil tillage implement with the coupled seeding unit on a level surface. CMS-I-00003116 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 56: Installing The Lighting On The Seeding Unit

    CMS-I-00007103 6.2.7 Installing the lighting on the seeding unit CMS-T-00004441-B.1 NOTE For road travel with the seeding combination, the lighting of the soil tillage implement must be installed on the seeding unit. MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 57 7. Establish the electrical connection 2 . 8. Install the second lighting holder 6 . CMS-I-00003223 9. Align the lighting holders 1 and 2 . 10. Tighten the nuts. 55 mm 55 mm CMS-I-00003221 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
  • Page 58: Preparing The Implement For Operation

    The lighting must be folded before the implement is unfolded. Depending on the implement equipment, the lighting is folded either manually or hydraulically. For implements without hydraulically folding lighting, move both lighting panels 1 into parking position. CMS-I-00007407 MG6545-EN-GB | E.1 | 29.09.2022 | © AMAZONE...
