This product is only suitable for well insulated spaces or occasional use.
To be left with the customer after demonstrating the features of the Solution electric fire.
The complete installation must be carried out in accordance with current Standards and Local
Codes. The instructions in this manual must be followed to ensure safe operation of the appliance.
It should be noted that the requirements and this publication may be superseded during the life of
the Fireplace - please refer to www.solutionfires.co.uk for up-to-date instructions.
The product complies with the European Safety Standards EN60335-2-30 and the European
Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These cover
the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
Instruction Manual
eTronic 800 Slimline
eTronic 1500 Slimline
Sept 2022 V6
Advertisement
Table of Contents
Related Manuals for Solution FIres eTronic 800 Slimline
Summary of Contents for Solution FIres eTronic 800 Slimline
- Page 1 Instruction Manual eTronic 800 Slimline eTronic 1500 Slimline This product is only suitable for well insulated spaces or occasional use. To be left with the customer after demonstrating the features of the Solution electric fire. The complete installation must be carried out in accordance with current Standards and Local Codes.
-
Page 2: Table Of Contents
Setting the Weekly Timer ............................ Thermal Safety Cut-Out ............................Light Emitting Diode ............................Cleaning, Servicing and Maintenance ......................Correct Disposal of this Product......................... Battery Replacement Remote Control ......................Troubleshooting..............................Solution Fires Warranty............................Exploded View ..............................17-18 Replaceable Parts .............................. 17-18 Wiring Diagram .............................. -
Page 3: Important Safety Advice
Important Safety Advice When using electrical appliances, basic precautions should be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • WARNING: If the appliance is damaged, check immediately with your retailer before installation and operation. -
Page 4: Technical Parameters
All batteries must be disposed of at your local recycling point. Technical Parameters Information requirements for electric local space heaters Model identifier(s): eTronic 800 Slimline & eTronic 1500 Slimline Item Symbol Value Unit... - Page 5 Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. Technical Data Voltage 220-240V AC ~50-60 Hz Max Power 1700-2000W Gross Weight (kgs) eTronic 800 Slimline = 25.5kg / eTronic 1500 Slimline = 49.5kg Efficiency Rating...
-
Page 6: Installation & Operating Instructions
Installation and Operating Instructions Box Contents: NOTE: Hardware not shown to actual size. Ref. Description Quantity Fireplace Top Wall bracket (A) Various Long Screw (CC) Various Wall Anchors (EE) Various Remote control AAA Batteries 1set (2pcs) Planning Assembly Before beginning assembly of product, make sure all parts are present. Compare parts with package contents lists. - Page 7 Installation and Operating Instructions Installation IMPORTANT: Do not connect the appliance until it is properly fixed to the wall and the instruction have been read fully. Ensure the minimum distances are observed. 1. Choosing a Wall Location • Choose a wall location to attach the Top Wall Bracket (A). Position the Top Wall Bracket (A) in the desired location.
- Page 8 Installation and Operating Instructions 4. Hanging the Fireplace • Ensure the Top Wall Bracket (A) is secured into the Wall Anchors. • Lift the Fireplace (a second person may be required), and align the slots on back panel with the hooks on Wall Bracket (A).
- Page 9 Installation and Operating Instructions The unit can be operated either by the key board (located just above the flame screen, on the right side), or using the remote control supplied. For the unit to operate, the manual ON/OFF switch, located on the left side of the grille panel must be switched to the “I”...
-
Page 10: Powering The Fireplace
Operating Instructions Continued NOTE: The functions below can be controlled either by the keyboard or remote control. Before using either control method, please ensure that the manual ON/OFF switch is to the “I” position. Powering ON/OFF the Fireplace Press the Power button to supply power to all functions of the fireplace. The current room temperature in the vicinity of the fireplace will be shown on the display. -
Page 11: Open Window Device Function
Operating Instructions Continued Open Window Device Function - Additional Hidden Functions This appliance has an open window detection function, When the heater is on operation (H1 or H2), if the ambient temperature drops 5°C within 10 minutes, the digital display will show . -
Page 12: Setting The Time And Day (24 Hour Clock)
Operating Instructions Continued (Remote Control) Setting the Time & Day (24 Hour Clock) 1. Press the Power button to turn the unit on. 2. Press & hold the Time Setting button for two seconds to display the time & day - see Fig 12 (no numbers shown as time not set). -
Page 13: Thermal Safety Cut-Out
Thermal Safety Cut-Out A thermal safety cut-out is incorporated in the heater to prevent damage due to overheating. This can happen if the heat outlet is restricted in any way. The heater will switch on once the obstruction has been removed and the heater has cooled. -
Page 14: Battery Replacement Remote Control
Battery Replacement Remote Control Battery information - see Fig. 18 1. Slide open the battery cover on the back of the remote control. 2. Install AAA batteries into the remote control. 3. Replace the battery cover. Discard leaky batteries Dispose of batteries in the proper manner according to local regulations. -
Page 15: Troubleshooting
Troubleshooting (IF IN DOUBT isolate the appliance and seek professional advice) The unit does not switch on: • Check main power on/off switch is on and orange light on flame screen illuminates. • Check the battery in the remote control handset. •... -
Page 16: Solution Fires Warranty
Solution Fires Warranty All Solution Fires come with a standard 1 year parts Should you experience problems with your Solution warranty extendable to 2 years on registration. Any Fire, any claim must be submitted to the Solution fire purchased outside of our authorised dealer... -
Page 17: Exploded View
Exploded View - eTronic 800 Slimline Replaceable Parts Description Part Number Front Glass 22 03 210 Flame Screen 22 03 213 Flame LEDs 22 03 215 Fuel Bed LED Strip 22 03 216 Motor 22 03 217 Remote Handset 22 03 120... - Page 18 Exploded View - eTronic 1500 Slimline Replaceable Parts Description Part Number Front Glass 22 03 220 Flame Screen 22 03 223 Fuel Bed LED Strip 22 03 227 Flame LEDs 22 03 225 Remote Handset 22 03 120 Power Supply 22 03 229 Motor 22 03 231...
-
Page 19: Wiring Diagram
Wiring Diagram... - Page 20 www.solutionfires.co.uk info@solutionfires.co.uk CAPITAL FIREPLACES LTD, Unit 12-17 Henlow Trading Estate, Henlow Camp, Bedfordshire, SG16 6DS. UK.
