This product is only suitable for well insulated spaces or occasional use.
To be left with the customer after demonstrating the features of the electric stove.
The instructions in this manual must be followed to ensure safe operation of the appliance. It should be
noted that the requirements and this publication may be superseded during the life of the Stove - please
refer to www.solutionfires.co.uk for up-to-date instructions.
Aug 2023 - V4
Instruction Manual
eTronic S52 (Bassington Stove)
eTronic S53 (Blackthorn Stove)
Advertisement
Table of Contents
Related Manuals for Solution FIres eTronic S52
Summary of Contents for Solution FIres eTronic S52
- Page 1 Instruction Manual eTronic S52 (Bassington Stove) eTronic S53 (Blackthorn Stove) This product is only suitable for well insulated spaces or occasional use. To be left with the customer after demonstrating the features of the electric stove. The instructions in this manual must be followed to ensure safe operation of the appliance. It should be noted that the requirements and this publication may be superseded during the life of the Stove - please refer to www.solutionfires.co.uk for up-to-date instructions.
-
Page 2: Table Of Contents
Technical Parameters ..........................Cleaning ............................... Thermal Safety Cut-Out ..........................Light Emitting Diode ............................. Battery Replacement Remote Control ..................... Troubleshooting ............................Servicing and Maintenance ........................Correct Disposal of this Product ......................... Solution Fires Warranty ..........................Parts Diagram ............................... Replaceable Parts ............................ -
Page 3: Important Safety Advice
Important Safety Advice When using electrical appliances, basic precautions should be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: � WARNING: If the appliance is damaged, check immediately with your retailer before installation and operation. - Page 4 � This appliance is supplied with a power lead complete with a moulded 13 Amp UK three-pin plug to connect into a standard UK socket outlet. This appliance must be earthed. The plug must be easily accessible after siting the appliance. Should a new fuse be required, consult a competent person to establish the reason for the fuse operating.
-
Page 5: Operating Instructions
Operating Instructions Manual Control: This appliance can be operated manually using the controls situated inside the door, below the fuel bed. Preset Heater Standby Power • POWER ON/OFF SWITCH: This rocker switch, located on the right hand side of the controls, is used to switch the mains supply to the appliance on or off. - Page 6 Operating Instructions Remote control: Sliding the door down on the remote control will reveal the Smart Control panel which offers additional functions. Otherwise using the basic remote buttons will operate the fire in the same way as the manual control buttons. (DISPLAYED WHEN STOVE IS SWITCHED ON TIMER SETTING...
- Page 7 Operating Instructions IMPORTANT NOTE: To switch Heating function on with Timer function, the target temperature must be set above room temperature, before setting timer. Setting the Timer function: The timer function allows the stove to be programmed for automatic use over a 7 day period. 1.
-
Page 8: Product Specification
Product Specification 520mm 345mm 306mm 519mm 308mm... -
Page 9: Technical Parameters
Technical Parameters Information requirements for electric local space heaters Model identifier(s): S53 Stove Item Symbol Value Unit Item Unit Type of heat input, for electric storage local space Heat output heaters only (select one) manual heat charge control, with [N/A] Nominal heat output integrated thermostat Minimum heat output... - Page 10 Technical Parameters Seasonal space heating energy efficiency Description Value Seasonal space heating energy efficiency in active mode-n 40.0% s,on For electric local space heaters-n 100.0% The electric to primary energy conversion coefficient-CC Correction factor accounting for a positive contribution to the seasonal space heating energy efficiency of electric storage local space heaters due to adjusted contributions for options for heat 0.0% storage and output;...
-
Page 11: Cleaning
Cleaning Battery Replacement NOTE: Allow the fire to completely cool Remote Control before cleaning it. 1. Switch off and unplug from the power Battery information - see Fig. 35 supply before cleaning. 1. Slide open the battery cover on 2. Using a soft, dry cloth, carefully clean the back of the remote control the exterior surface of the product. -
Page 12: Troubleshooting
Troubleshooting (IF IN DOUBT isolate the appliance and seek professional advice) The unit does not switch on: • Check main power on/off switch is on and orange light on flame screen illuminates. • Check the battery in the remote control handset. •... -
Page 13: Servicing And Maintenance
Servicing and Maintenance • There are no user-serviceable components to this appliance – do not attempt to service the appliance. If there are issues that cannot be resolved with your appliance, then please contact your retailer. • Hard floor covering in particular, but all floor covering cause fluff that can be drawn into the air intakes. -
Page 14: Solution Fires Warranty
Solution Fires, in the event of a warranty claim, are either subject to normal wear and tear or reserves the right to either replace the goods... -
Page 15: Parts Diagram
Parts Diagram Replaceable Parts Description Part Number Description Part Number Rotisserie (Single) Temperature Sensor 22 03 178 22 03 184 Fan Heater Assembly Power Supply PCB 22 03 174 22 03 165 Log Retainer 22 03 185 Main PCB 22 03 164 Remote Handset Infrared Sensor 22 03 168... - Page 16 www.solutionfires.co.uk info@solutionfires.co.uk CAPITAL FIREPLACES LTD, Unit 12-17 Henlow Trading Estate, Henlow Camp, Bedfordshire, SG16 6DS. UK.
