White Extending Universal Drop Ceiling
Projector Mount
Instruction Manual
SKU: MOUNT-VP08DP
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vp08dp
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VP08DP
Summary of Contents for Vivo MOUNT-VP08DP
- Page 1 White Extending Universal Drop Ceiling Projector Mount Instruction Manual SKU: MOUNT-VP08DP Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vp08dp GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 29.7 lbs Failure to do so may result in serious injury. (13.5 kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Remove plastic plug from Ceiling Plate (D). STEP 2 Insert 2 toggles at end of Y-Cable with Lock (F) into 2 of the 16 slots on the top of the Ceiling Plate (D), making sure the slots chosen will provide optimal support for the mount with projector. - Page 4 STEP 3 Push Clips (E) down over drop ceiling T-bar to hold the Ceiling Plate (D) down. T-Bar STEP 4 OPTION A: Insert cables through side of Mount (A) if cables will be exposed below ceiling. OPTION B: Insert cables through center of Mount (A) if cables will be hidden above ceiling.
- Page 5 STEP 5 Secure Mount (A) to Ceiling Plate (D) using M6x18mm Bolts (S-A) with M6 Washers (S-B), and tighten with 5mm Allen Wrench (T-B). STEP 6 Secure Bracket (B) to Mount (A) using Threaded Plate (S-G), Plastic Spacer (S-F), M5x12mm Screws (S-C), Small M5 Washer (S-D), Plastic M5 Washer (S-E), and 4mm Allen Wrench (T-A).
- Page 6 STEP 7 Align Mount Arms (C) with mounting holes in projector, and mount to projector using screws (M-A thru M-D), Washers (M-E thru M-H) most appropriate for your projector and a Phillips Screwdriver. NOTE: If your projector has 3 mounting holes, simply remove one of the arms. For mini projectors with a single hole, remove all arms and mount projector directly to Bracket.
- Page 7 STEP 9 Adjust angle and rotation of projector if desired by loosening screws on Assembled Mount using 4mm Allen Wrench (T-A).
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
