Muratec MFX-2530 Quick Reference

Muratec MFX-2530 Quick Reference

Muratec mfx-2530: reference guide
Hide thumbs Also See for MFX-2530:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Quick
Quick
Reference
Reference
Sending a fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Canceling commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Basic copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Reduce/Enlarge copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Using the bypass tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Duplex copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Clearing document jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
Clearing printout jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page
for MFX-2530
2
4
6
8
10
14
16
18
22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFX-2530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Muratec MFX-2530

Summary of Contents for Muratec MFX-2530

  • Page 1: Table Of Contents

    Clearing document jams ......page Clearing printout jams ....... page for MFX-2530...

  • Page 2: Fax

    Sending a fax Press to change to Fax mode. Set the document as follows: When setting the document in the ADF 1. Set the document in the ADF face up. 2. Adjust the document guides. Note: The number of the pages you can set in the ADF at one time is 50 sheets.

  • Page 3: Press Start

    Fax Ready Nov 5 2001 13:30 Fax Ready Memory 100% Redial Group Broadcas Enter the fax number. a. Enter the fax number using the numeric keypad. b. Press the one-touch key.* c. Press and enter SPEED DIAL/TEL INDEX the speed-dial number using the numeric keypad.
  • Page 4 Broadcast Press to change to Fax mode. Set the document. (See page 2.) Adjust the resolution and the contrast, if necessary. Press [Broadcas]. Enter the fax number. You can use the numeric keypad, one-touch keys, speed-dial numbers, group numbers and Tel index.
  • Page 5 Transmission Enter fax number. Group Clear Broadcas To add additional fax numbers, repeat steps 3 and 4. Press START Note If you want to erase the fax number you've already entered, select it using the cursor key after pressing [Broadcas]. Then press [Clear].

  • Page 6: Canceling Commands

    Canceling commands Press JOB REVIEW & COMM. CANCEL. If your machine is attempting to perform a command, it will appear on the display. Skip to step 4. Select "Reserved Transmission" using the cursor key and press [Enter]. Select the command you want to cancel using the cursor key.
  • Page 7 2, 4 Press [Erase]. If you want to cancel another command, repeat steps 3–4. To finish, press RESET Note Press [Location] to see the individual numbers within the broadcast in step 3. To return to the previous display, press [Location] again. 2, 3...

  • Page 8: Copy

    Basic copy Copy Press to change to Copy mode. COPY Set the document as follows: When setting the document in the ADF 1. Set the document in the ADF face up. 2. Adjust the document guides. Note: The number of the pages you can set in the ADF at one time is 50 sheets.
  • Page 9 Copy Ready 100% Paper Zoom Sort Select the recording paper and set the advanced copy features, if necessary. Enter the number of copies using the numeric keypad. Press START Note Any time you press , the machine resets the display to the initial screen and RESET press again to return the machine to its initial condition.

  • Page 10: Reduce/Enlarge Copy

    Reduce/Enlarge copy Copy Set the document. (See page 8.) If you want enlarged copies, use the FBS glass. a. Auto Reduce / Enlarge Press to select "Auto". REDUCE/ENLARGE Press [Paper] and select the paper size using the cursor key.
  • Page 11 2a, 3b Copy Ready 100% Paper Zoom Sort 3a, 2b b. Reduce / Enlarge with a preset rate Press [Paper] and select the paper size using the cursor key. If you want your machine to select the appropriate paper automatically, select "Auto". Press REDUCE/ENLARGE Enter the number of copies using the numeric keypad.
  • Page 12 c. Reduce / Enlarge in 1% steps Set the document. (See page 8.) If you want enlarged copies, use the FBS glass. Enter the number of copies using the numeric keypad. Press [Zoom].
  • Page 13 Copy Ready Ppr. Auto 100% Use cursor or numeric keypad to enter ratio. Paper Zoom Sort Enter the desired ratio using the cursor key or the numeric keypad. Press START 2, 4...

  • Page 14: Using The Bypass Tray

    Using the bypass tray Copy Set the document. Place a sheet of paper face down on the bypass tray. Aline the paper guides to the sheet's edges and insert it until it comes to a stop. Press [Ppr.size]. When select the standard paper size Select the desired paper size using the cursor key.
  • Page 15 When select the non standard paper size Press [Other]. Select the desired paper size using the cursor key. Then press [Enter]. Press START Note If you want to use the other type of papers than the plain paper, press [Ppr.Type] after step 4.

  • Page 16: Duplexcopy

    Duplex copy Copy 2-sided documents -> 1-sided copies 2-sided documents -> 2-sided copies* Two facing pages -> 2-sided copies* Press COPY Set the document. Adjust the document type and the contrast, if necessary. Press MENU. Select "DuplexCopy" using the cursor key. Then press [Enter].
  • Page 17 DuplexCopy Use cursor to select item. 1® 2-sided 2® 2-sided 2® 1-sided Book(Face) Book(F&B) Enter 3, 4, 5 Select the type of duplex copy using the cursor key. Then press [Enter]. Select the binding position using the cursor key. Then press [Enter]. Press START.

  • Page 18: Just In Case

    Clearing Just case If the ADF cover is blinking on the LCD Document jam Open & Check the blinking cover. Remove the original document from the machine by turning the green dial right. If you cannot remove the original document, proceed to step 3. Open the inner cover and remove the document by turning the green dial right.
  • Page 19 Lift the document tray and remove the document. Close the inner cover and the ADF cover, making sure both sides are snapped down securely. If this LCD appears, you can continue scanning from the jammed page. If you want to continue, press [Yes]. If you press [No], only scanned pages will be transmitted or copied.
  • Page 20 If the platen cover is blinking on the LCD Open the ADF cover by holding the ADF cover release. Remove the original document from the machine by turning the green dial right or left. If you cannot see the paper under the platen cover, remove the paper from the ADF as shown on pages 32-33.
  • Page 21 If this LCD appears, you can continue scanning from the jammed page. If you want to continue, press [Yes]. If you press [No], only scanned pages will be transmitted or copy. Reset the documents from the jammed page and press START Note In Quick memory transmission, the check message will be printed, which has the number...

  • Page 22: Clearing Printout Jams

    Clearing Just case CAUTION The fuser unit becomes very hot. Do not touch the fuser unit when you are removing a paper jam. IMPORTANT Never touch the electrical contacts inside the printer cover and under the drum cartridge, as an electrostatic discharge may damage the machine.
  • Page 23 Remove the jammed paper. Close the printer cover. Open the side cover. Turn the green dial to remove the jammed paper. Cassette Remove the jammed paper. Close the side cover. Pull the cassette toward you and remove the paper in the cassette. Reset the papers and close the cassette.
  • Page 24 When paper is jammed in the bypass tray Open the printer cover by holding the printer cover release ( When paper is jammed in the optional duplex unit Open the duplex unit cover. Remove the jammed paper. Remove the jammed paper. Close the printer cover.
  • Page 25 When paper is jammed in the optional 2-Bin tray or shift tray Open the printer cover by holding the printer cover release ( Open the fuser cover by holding the fuser cover release ( Open the 2-Bin tray cover or the shift tray cover. Remove the jammed paper.
  • Page 26 MEMO...
  • Page 27 Muratec America, Inc. 6400 International Parkway Suite 1500 Plano, Texas 75093 http://www.muratec.com MAI order number: OMFX2530QRG MML item number: D84-90570-60 © Muratec America, Inc. 2001 Printed in Japan.
