5 – Configuring the RF560VPN

About the Browser Interface

Initial configuration is required in order for you to begin operation. The browser-
based interface eases VPN configuration and management.
About IPSec
The VPN functionality is based on the IPSec protocol and uses 168-bit Triple DES
(3DES) encryption to ensure that your information remains private.

Start the RF560VPN Configuration

1. Connect your workstation.
Be sure your workstation is connected to one of the RF560VPN's LAN ports.
2. Apply power.
Apply power to the RF560VPN RouteFinder and allow the LEDs to stabilize on
the unit.
3. Set the workstation IP address.
The directions for setting your workstation IP address are covered in Chapter 3.
4. Open a Web browser.
·
At the Web browser's address line, type the RF560VPN IP address
(http://192.168.2.1 (This is the default address of your RouteFinder).
·
Press Enter.
Note: Make sure your PC's address is on the same network as the router's address.
and
WINIPCONFIG IPCONFIG
gateway and the MAC address. In Windows 98/Me, type
2000/NT, type
IPCONFIG
14
are tools for finding out a PC's IP configuration: the default
.
Multi-Tech Systems, Inc. RF560VPN Quick Start Guide
Chapter 5 – Configuring the RF560VPN
. In Windows
WINIPCONFIG
