- Page 1 MultiModem ® CDMA & EDGE Internal Wireless Modem MTZPC-C MTZPC-E User Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes. Check Multi-Tech’s Web site for current versions of our...
-
Page 3: Table Of Contents
Repair Procedures for International Customers (Outside U.S.A. and Canada)... 28 Repair Procedures for International Distributors ... 29 Replacement Parts ... 29 APPENDIX A - WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) STATEMENT... 30 Multi-Tech Systems, Inc. MultiModem User Guide Contents ... 4 ODEM ... 5 ... -
Page 4: Chapter 1: Description And Specifications
Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes. Check Multi-Tech’s Web site for current versions of our product documentation. -
Page 5: Package Contents
VSWR Typical Radiated Gain Frequency RX Frequency TX RF Power Stand Impedance VSWR Typical Radiated Gain Multi-Tech Systems, Inc. MultiModem User Guide Chapter 1 - Description and Specifications Modem Only • One MultiModem • This Quick Start Guide CDMA 800... -
Page 6: Specifications
Network: PTCRB Network: CDG 1 & 2 AT Command Compatible AT Command Compatible Carrier approved Carrier approved Embedded TCP/IP stack CDG 1 and 2 network certified CDMA IS-95A, IS-95B backwards compatible Two years Two years Multi-Tech Systems, Inc. MultiModem User Guide... -
Page 7: Chapter 2: Installation
Activating your Wireless Account Multi-Tech – A Certified National Activation Agent Multi-Tech Systems, Inc. is a certified national activation agent for Cingular and Sprint wireless. For more information about available data plans and to purchase and activate a wireless data account, contact Multi-Tech at 888-288-5470. -
Page 8: Install Your Modem
8. Fasten the retaining bracket to the system chassis with the screw saved in step 3. 9. Replace the system cover. 10. Attach the antenna to the threaded SMA connector on the PCI bracket. 11. Power up the system. MTZPC-E Multi-Tech Systems, Inc. MultiModem User Guide... -
Page 9: Driver Installation (Windows Xp/2003/2000)
2. The Found New Hardware Wizard with “This wizard helps you install software for: PCI Serial Port screen appears. Click Install from a list or specific location (Advanced). Click Next. Multi-Tech Systems, Inc. MultiModem User Guide Chapter 2 - Installation... - Page 10 Select Include this location in the search: option. Click the Browse button and browse to the location of the CDROM drive, usually CD Drive (D:\). Click on the Drivers folder. Click Next. Multi-Tech Systems, Inc. MultiModem User Guide...
- Page 11 Select the “No, not this time”, because Windows wants to search the Internet. Click Next. 8. The Found New Hardware Wizard with “Multifunction Device screen appears. Click Install from a list or specific location (Advanced). Click Next. Multi-Tech Systems, Inc. MultiModem User Guide Chapter 2 - Installation...
-
Page 12: Part B: Installing Your Wireless Modem
Select Include this location in the search: option. Click the Browse button and browse to the location of the CDROM drive, usually CD Drive (D:\). Click on the Drivers folder. Click Next. 10. The Hardware Installation with The software you are installing for this hardware: Multi-Tech Communications Port screen is displayed. - Page 13 This COM port usually is the last one displayed in this screen. Click Next. 17. The Windows Logo Testing screen appears with MultiTech Systems MTZPC-C Wireless Modem for a CDMA modem or MTZPC-E for an EDGE modem.
-
Page 14: Chapter 3 - Using Your Multimodem
AT commands can be used to operate, configure, and query your modem. A reference guide for EDGE or CDMA commands is included on the MultiModem CD and on the Multi-Tech Web site. The following two commands let you query signal strength and roaming status. -
Page 15: Establishing A Circuit-Switched Data (Csd) Connection
Disconnect: Type: +++ Wait about two seconds to see an OK response. Then type: ATH Multi-Tech Systems, Inc. MultiModem User Guide Chapter 3 – Using Your MultiModem • The phone number you are calling is entered between the displayed brackets. Do not type additional brackets. For example, type only ATD 8585551212. -
Page 16: Using Short Message Services (Sms)
"ALL" Show all d messages. 0 Delete message at location <include the index number. 1 Delete all READ messages. 2 Delete all READ and SENT messages. 3 Delete all READ, SENT, and UNSENT messages. 4 Delete ALL messages. Multi-Tech Systems, Inc. MultiModem User Guide... -
Page 17: Sms Examples For Cdma Modem
Receive Example 2: Receive a SMS message and route directly to TE: at+cnmi=2,2,0,0,0 (set modem to receive SMS and route directly to TE) +CMT:"7632273726","06/03/17,13 :38 :22",129,0,3,0,5 (indication that message was received) TEST2 at+cnma (acknowledge that message was received) Multi-Tech Systems, Inc. MultiModem User Guide... -
Page 18: Sms Examples For Edge Modem
(set to Phase 2+ compatibility) +CSMS: 1,1,1 at+cnmi=2,2,0,0,1 (set to receive SMS messages and directly route to TE) +CMT: "+17632273726",,"06/03/17,09:06:11+00" TEST SMS 2 (message) at+cnma (acknowledge to the network that the message has been received) Multi-Tech Systems, Inc. MultiModem User Guide... -
Page 19: Internet Access
The modem must be getting a proper signal and be showing a network registration through the wireless provider’s network • A PC running Windows XP, 2003, or 2000 with the Multi-Tech drivers installed for your particular model The following instructions are for Windows XP SP2 and Windows 2003. Every PC may have slight differences which may cause the instructions to be different. - Page 20 To disconnect the connection, right click on the connection icon in your system tray at the bottom right-hand corner of your screen. Scroll up and click on Disconnect. You should now be disconnected from the Internet. Important: Multi-Tech Systems, Inc. MultiModem User Guide Make sure that...
-
Page 21: Connecting To The Edge Network For Internet Access
The modem must be getting a proper signal and be showing a network registration through the wireless provider’s network • A PC running Windows XP, 2003, or 2000 with the Multi-Tech drivers installed for your particular model The following instructions are for Windows XP SP2 and Windows 2003. Every PC may have slight differences which may cause the instructions to be different. - Page 22 After clicking on Next, you may or may not be asked to select which modem to use. If you have more than one modem installed in your PC, you will be required to select the proper modem to use. If asked, please select the Multi-Tech wireless modem that has been installed.
-
Page 23: Chapter 4: Troubleshooting And Frequently Asked Questions
Is another program interfering with the communication program? Multi-Tech Systems, Inc. MultiModem User Guide Chapter 4 – Troubleshooting & Frequently Asked Questions Follow “Verifying network registration” procedure to be sure modem is registered on network. End any communication using the command. -
Page 24: Frequently Asked Questions For Cdma Modem
Make sure you have CSD service. • Check registration and signal to make sure the modem is registered and getting good signal: +CREG, +CSQ. • Make sure you went through the activation procedures correctly. Multi-Tech Systems, Inc. MultiModem User Guide... - Page 25 After I set the Q, V, and &S commands followed by &W, if I recycle power or send ATZ to the modem the settings will get set back to default. • Bug in the modem. These commands will not store. Multi-Tech Systems, Inc. MultiModem User Guide Chapter 4 – Troubleshooting & Frequently Asked Questions...
-
Page 26: Frequently Asked Questions For Edge Modem
Check the modem to make sure it is installed and can be queried in the modem’s properties. • Make sure the com port is not being held by another application. Look for the TR light indication. If it is on, most likely another application is holding onto the port. Multi-Tech Systems, Inc. MultiModem User Guide... - Page 27 230,400 bps and above. • If your port supports only 115,200 bps, then you may not see expected EDGE rates. Multi-Tech Systems, Inc. MultiModem User Guide Chapter 4 – Troubleshooting & Frequently Asked Questions...
-
Page 28: Chapter 5: Warranty & Repairs Policies
Chapter 5: Warranty & Repairs Policies Multi-Tech Warranty Statement Multi-Tech Systems, Inc., (hereafter “MTS”) warrants that its products will be free from defects in material or workmanship for a period of two, five, or ten years (depending on model) from date of purchase, or if proof of purchase is not provided, two, five, or ten years (depending on model) from date of shipment. -
Page 29: Repair Procedures For International Distributors
Replacement Parts SupplyNet, Inc., can supply you with replacement power supplies, cables and connectors for selected Multi-Tech products. You can place an order with SupplyNet via mail, phone, fax or the Internet at the following addresses: Mail: SupplyNet, Inc. -
Page 30: Appendix A - Waste Electrical And Electronic Equipment (Weee) Statement
The WEEE Directive covers all Multi-Tech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
