1 Introduction

1.1.1 Copyright, Limitation of Liability and Revision Rights
This publication contains information proprietary to GE. By accepting and using this manual the user agrees that the information contained herein will be used
solely for operating equipment from GE or equipment from other vendors provided that such equipment is intended for communication with GE equipment
over a PROFIBUS serial communication link. This publication is protected under the Copyright laws.
GE does not warrant that a software program produced according to the guidelines provided in this manual will function properly in every physical, hardware
or software environment.
Although GE has tested and reviewed the documentation within this manual, GE makes no warranty or representation, either express or implied, with respect
to this documentation, including its quality, performance, or fitness for a particular purpose.
In no event shall GE be liable for direct, indirect, special, incidental, or consequential damages arising out of the use, or the inability to use information con-
tained in this manual, even if advised of the possibility of such damages. In particular, GE is not responsible for any costs including but not limited to those
incurred as a result of lost profits or revenue, loss or damage of equipment, loss of computer programs, loss of data, the costs to substitute these, or any claims
by third parties.
GE reserves the right to revise this publication at any time and to make changes in its contents without prior notice or any obligation to notify previous users of
such revisions or changes.

1.2.1 Safety Note

The voltage of the adjustable frequency drive is dangerous whenever connected to line power. Incorrect installation of the motor, adjusta-
ble frequency drive or network may cause damage to the equipment, serious personal injury or death. Consequently, the instructions in this
manual, as well as national and local rules and safety regulations, must be complied with.
1.2.2 Safety Regulations
1. The adjustable frequency drive must be disconnected from line power if repair work is to be carried out. Make sure that the line power supply has
been disconnected and that the necessary time has passed before removing motor and line power plugs.
2. The [OFF] key on the control panel of the adjustable frequency drive does not disconnect the equipment from line power and is thus not to be used as
a safety switch. 3. Correct protective grounding of the equipment must be established, the user must be protected against supply voltage, and the
motor must be protected against overload in accordance with applicable national and local regulations.
3. Correct protective grounding of the equipment must be established, the user must be protected against supply voltage, and the motor must be pro-
tected against overload in accordance with applicable national and local regulations.
4. The ground leakage currents are higher than 3.5 mA.
5. Protection against motor overload is not included in the factory setting. If this function is desired, set F-10 Electronic Overload to data value Electronic
Overload trip or data value Electronic Overload warning. Note: The function is initialized at 1.16 x rated motor current and rated motor frequency. For
the North American market: The Electronic Overload functions provide class 20 motor overload protection in accordance with NEC.
6. Do not remove the plugs for the motor and line power supply while the adjustable frequency drive is connected to line power. Make sure that the line
power supply has been disconnected and that the necessary time has passed before removing motor and line power plugs.
7. Please note that the adjustable frequency drive has more voltage inputs than L1, L2 and L3 when load sharing (linking of DC intermediate circuit) and
external 24 V DC have been installed. Make sure that all voltage inputs have been disconnected and that the necessary time has passed before
commencing repair work.
