AF-650 GP/AF-600 FP Profibus DP Instruction Manual
The AF-650 GP GSD file is now imported and will be accessible via the fol-
lowing path in the hardware catalog:
3
Open a project, set up the hardware and add a PROFIBUS master system.
Select AF-6 Series then drag and drop it onto the PROFIBUS in the hardware
diagram.
A window for the address of the AF-6 Series now appears. Select the ad-
dress from the scroll-down list. Note that this address setting must match
the previous address setting in PB-18 Node Address.
