Installer manual
(Translation of original
EN
instructions)
N420665B - Rev. 00 - 06/2022
Outdoor unit
eHPoca - 3in1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eHPoca and is the answer not in the manual?

Questions and answers

Summary of Contents for Innova eHPoca

  • Page 1 Installer manual (Translation of original instructions) N420665B - Rev. 00 - 06/2022 Outdoor unit eHPoca - 3in1...
  • Page 2 By following the suggestions contained in this manual, the product that you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity This unit complies with the European directives: • RoHS2 Directive 2011/65/EU2 on the restriction of •...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS General information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p. 6 1.1 About the manual .
  • Page 4 3.8.1 Preliminary warnings ........p. 16 3.9 Installation minimum distances .
  • Page 6: General Information

    GENERAL INfORMATION GENERAL INFORMATION 1�1 About the manual This manual was written to provide all the explanations for The white numbers in black marks indicate a se- the correct management of the appliance. ries of actions to be carried out in sequence. The black letter in white identifies an image when This instruction manual forms an integral part of the there are several images in the same figure.
  • Page 7: Manual Organisation

    GENERAL INfORMATION ment containing certain fluorinated greenhouse gases It contains general information and important warnings (f-gas licence). that should be known before installing and using the ap- pliance. Technical Service Centre Expert and qualified person authorised directly by the Product presentation manufacturer to carry out all routine and supplementa- It addresses all recipients.
  • Page 8: Basic Rules Of Security

    GENERAL INfORMATION Do not place flammable objects (spray cans) within 1 If refrigerant gas escapes, aerate the room abundantly metre of the air outlet. and leave. Call the Technical Assistance Service or pro- fessionally qualified personnel as soon as possible and Avoid proximity to sources of ignition in continuous do not intervene on the appliance yourself.
  • Page 9: Product Presentation

    PRODUCT PRESENTATION PRODUCT PRESENTATION 2�1   I dentification The appliance can be identified by the rating plate: 1� Technical rating plate Technical rating plate Tampering with, removal of, or lack of identification This shows the technical and performance specifications of plates will not allow for the safe identification of the the appliance.
  • Page 10: Description Of The Appliance

    1� for models 5 - 7 - 9 2� for models 12 - 15 - 18 (model 18 only for eHPoca) 2�3 Description of the appliance The outdoor unit are designed for vertical outdoor instal- Model 18T refers to indoor unit only eHPoca.
  • Page 11: List Of External Components

    PRODUCT PRESENTATION 3in1 3 in1 size matchability Indoor unit Single-phase outdoor unit Three-phase outdoor unit 2�4 List of external components 2�4�1 Outdoor unit 1� fan grille 2� Connections panel 3� Access panel...
  • Page 12 INSTALLATION INSTALLATION 3�1 Preliminary warnings This section is dedicated to the Installer. The fea- Be sure to use the supplied or specified installation tures of the installer are described in the "Recipi- parts. Use of other parts may cause the unit to come to ents"...
  • Page 13 INSTALLATION 3�3 Dimensions and weights with packaging 3�3�1 Outdoor unit 05-M 07-M 09-M 12-M 12-T 15-M 15-T 18-T Models m.u. Dimensions and weights with external unit packaging Total widh 1055 1055 1055 1055 1055 1055 1055 1055 Total height 1136 1136 1136 1556...
  • Page 14 INSTALLATION 3�4�2 Movement methods The product can be handled as follows: Only in exceptional cases can the unit be moved man- • using a fork lift or a transpallet which can bear its ually for short distances using the handles provided on weight the packaging.
  • Page 15 INSTALLATION • in a dry and clean place • check that no water is present in the hydraulic sys- • in a closed environment protected from atmospheric tems elements • do not remove the protection of the heat exchanger • insulated from the ground by crossbars or pallets •...
  • Page 16 INSTALLATION 3�7 Handling without packaging 3�7�1 Preliminary warnings – lift from the base of the packaging The unit can be moved manually for short distances. The appliance must be handled only by qualified per- In this case it is necessary to check carefully that the sonnel, adequately equipped and with equipment suit- weight of the unit does not exceed the regulations in able for the weight and dimensions of the appliance.
  • Page 17 INSTALLATION Models m.u. 12 T 18 T Distance A ≥ 150 ≥ 150 ≥ 150 ≥ 150 ≥ 150 ≥ 150 ≥ 150 ≥ 150 Distance B ≥ 250 ≥ 250 ≥ 250 ≥ 250 ≥ 250 ≥ 250 ≥ 250 ≥...
  • Page 18 INSTALLATION Use concrete or a similar material to make the base, Ordinarily, ensure a base height of 5 cm or more. We and ensure good drainage. In this case, prearrange vi- recommend always using a condensate collection tray bration damping blocks in order to prevent the trans- and drain pipe, or in regions with cold winters, ensure mission of the vibrations.
  • Page 19 INSTALLATION Plan the route of the pipeline so as to reduce the length Checks for the presence of refrigerant and number of bends as much as possible for best per- • The area must be checked with an appropriate re- formance of the system.
  • Page 20 INSTALLATION • the pipes of the charging equipment are as short as Check if there are no leaks of refrigerant before leaving possible to minimise the amount of refrigerant the site. • the cylinders are kept in a vertical position Label the system when charging is complete.
  • Page 21: Outdoor Unit

    INSTALLATION Outdoor unit 05-M 07-M 09-M 12-M 12-T 15-M 15-T 18-T Models m.u. Outdoor unit refrigerant gas data Refrigerant Refrigerant charge 1,80 1,80 1,80 3,05 3,05 3,05 3,05 3,05 Suction “SAE Liquid “SAE 3�11�3 Connection of piping Preliminary warnings Use a wheel pipe cutter only to cut the pipes clamping it in short lengths so as not to crush the pipe.
  • Page 22: Insulation Of Pipes

    INSTALLATION – flare the pipe ends using the special tool Opening Closing – Lubricate the connecting thread with oil for coolant 1� Service fitting cover cap 2� Shut-off valve shaft Do not use any other type of lubricant. 3� Refrigerant pipe fitting 4�...
  • Page 23: Pneumatic Vacuum

    INSTALLATION 3�11�7 Pneumatic vacuum High pressure Low pressure To create a pneumatic vacuum in the circuit: 1� Pressure reducer 2� Nitrogen cylinder – keep the shut-off valves of the outdoor unit in the 3� Pressure gauge unit closed position 4� Three-way valve service fitting High pressure Low pressure...
  • Page 24: Condensate Drain

    INSTALLATION – close it after 6 seconds so that a small amount of re- At the end of the check, remove any residue of the soap frigerant enters the circuit and water solution from the pipes. – search for the leak using a soap and water solution Do not use the same vacuum pump with different re- –...
  • Page 25: Power Line Dimensioning

    INSTALLATION 3�12�1 Preliminary warnings for the electrical connection, use a cable that is long enough to cover the entire distance without any con- All operations of an electrical nature must be carried nection. Do not use extension cables. Do not apply oth- out by qualified personnel having the necessary legal er loads on the power supply.
  • Page 26 INSTALLATION 05-M 07-M 09-M 12-M 12-T 15-M 15-T 18-T Models m.u. Electrical data of outdoor unit Power supply V/ph/Hz 230-1-50 230-1-50 230-1-50 230-1-50 400-3-50 230-1-50 400-3-50 400-3-50 total input power 2,57 3,39 3,90 5,50 5,80 6,15 6,45 6,80 Maximum absorbed current 12,00 16,40 18,00...
  • Page 27: Connection

    INSTALLATION Connection diagram 1� Unit power supply 230/1/50 0 400/3/50 depending on model 2� Protection switch (not supplied) 3� Power cable 4� Outdoor unit 5� Power line 6� Indoor unit 7� Heating element kit Connection terminal blocks Connection To make the connection: –...
  • Page 28 INSTALLATION Single-phase connection terminal blocks U�I� Neutral Indoor unit connection 230V AC Lines Unit power supply Earth connection Protective switch U.I. 230V AC Three-phase connection terminal blocks U�I� Neutral Indoor unit connection L1/L2/L3 Lines 400V AC Unit power supply Earth connection Protective switch U.I.
  • Page 29: Putting It Into Service

    PUTTING IT INTO SERVICE PUTTING IT INTO SERVICE 4�1 Preliminary warnings This section is dedicated to the Technical Service Using a mobile phone near the appliance is prohibited. Assistance. The features of the Technical Ser- Perform the following checks: vice Assistance are described in chapter "Recipi- •...
  • Page 30 PUTTING IT INTO SERVICE In the case of an additional charge, the amount of the total High pressure Low pressure charge given by the sum of the factory charge and the add- 1� Pressure gauge unit ed charge must be indicated. 2�...
  • Page 31: Maintenance

    MAINTENANCE MAINTENANCE Routine maintenance is essential to keep the device always efficient, safe and reliable over time. 5�1 Preliminary warnings This section is dedicated to the Technical Service Smoking in the vicinity of the appliance is prohibited. Assistance. The features of the Technical Ser- Using a mobile phone near the appliance is prohibited.
  • Page 32 MAINTENANCE • the conditions of the structure Poor fastenings cause abnormal noises and vibrations. Treat any rusty parts with paints suitable to eliminate or reduce the rust. Other recommended checks: • tightening of terminals • clean the battery • check of safety devices •...
  • Page 33: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING 6�1 Preliminary warnings Refer to the manual of the indoor unit for trouble- shooting and solutions. Interventions must be carried out by a qualified install- er or a specialised Technical Assistance Centre. Do not intervene personally.
  • Page 34: Technical Information

    TECHNICAL INfORMATION TECHNICAL INFORMATION 7�1 Technical data eHPoca eHPoca Models m.u. Refrigerant gas data Suction “SAE Liquid “SAE Electrical data Power Supply V/ph/Hz 230-1-50 230-1-50 230-1-50 230-1-50 400-3-50 400-3-50 Degree of protection outdoor unit IPX4 Sound data Sound pressure in heating mode...
  • Page 35: Operating Limits

    TECHNICAL INfORMATION 7�2 Operating limits Heating External air temperature (°C) –20 –25 Water temperature system supply (°C) Integration by electrical heaters or boilers The area represented by the graph is simplified. It may be more advantageous depending of outdoor and working conditions.
  • Page 36 TECHNICAL INfORMATION Domestic hot water mode External air temperature (°C) –20 –25 Sanitary hot water tank temperature (°C) PDC off. Integration by electrical Heating be means of heaters or boilers electrical heaters, boiler or solar integration The areas represented by the graph marked by back- up heater are simplified.
  • Page 37: Dimensions

    TECHNICAL INfORMATION 7�3 Dimensions eHPoca / 3in1 / 3in1 Built-in 05-M 07-M 09-M 12-M 12-T 15-M 15-T 18-T Models m.u. Dimensions and weights of outdoor unit Total widh Total height 1416 1416 1416 1416 1416 Total depth Net weigth 65,0...
  • Page 38: Models 5M - 7M - 9M

    TECHNICAL INfORMATION Models 5M - 7M - 9M 84,5 109,5 Models 12M - 12T - 15M - 15T - 18T 84,5 109,5...
  • Page 39: Electrical Diagrams

    TECHNICAL INfORMATION 7�4 Electrical diagrams Models 5M - 7M - 9M...
  • Page 40: Models 12M - 15M

    TECHNICAL INfORMATION Models 12M - 15M...
  • Page 41: Models 12T - 15T - 18T

    TECHNICAL INfORMATION Models 12T - 15T - 18T...
  • Page 42: System Log Box

    SYSTEM LOG BOx SYSTEM LOG BOX 8�1 System log box 01. Registro dell’impianto Obbligo di documentazione Tutti gli interventi eseguiti sulla pompa di calore, come manutenzione, riparazione o prova di tenuta, devono essere documentati e la relativa documentazione deve essere conservata per cinque anni.
  • Page 43 SYSTEM LOG BOx . Registro dell’impianto I seguenti dati relativi - Dati dell’impianto all'impianto vanno - Tipo e caratteristiche dell’acqua di riempimento documentati: - Rapporti su riparazioni e manutenzioni - Quantità di refrigerante Dati dell’impianto: _____________________________________________________________ Nome del conduttore dell’impianto _____________________________________________________________ Indirizzo _____________________________________________________________...
  • Page 44 SYSTEM LOG BOx 03. Registro dell’impianto Sul circuito frigorifero della pompa di calore sono stati eseguiti i seguenti interventi di manutenzione e prove di tenuta ai sensi della normativa (del regolamento (CE) n. 303/2008 - Categoria I): Data - Risultati della manutenzione Nome dell’azienda Firma del tecnico - Refrigerante prelevato / aggiunto (in kg)
  • Page 45 NOTE...
  • Page 46 NOTE...
  • Page 47 NOTE...
  • Page 48 INNOVA S.r.l. Via I Maggio 8 - 38089 Storo (TN) - ITALY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...
