INSTRUCTION AND SAFETY MANUAL
XTIRPA Buddy Roc Pro Mast
IN-5032
MUST BE READ AND UNDERSTOOD BY THE USER
BEFORE EACH USE
INNOVA Public Utility Products, Inc., 1040 BOUL. INDUSTRIEL,
GRANBY, QUEBEC, CANADA
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.ca
P.
Number: MU5032-002ANG Rev1 2017
