INSTRUCTION AND SAFETY MANUAL XTIRPA
1067mm (42") PORTABLE MANHOLE GUARD SYSTEM
FOR PPE
UNIVERSAL RESCUE SYSTEM
IN-8002
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8002-(en-us)

Advertisement

loading
Need help?

Need help?

Do you have a question about the XTIRPA IN-8002 and is the answer not in the manual?

Questions and answers

Related Manuals for Innova XTIRPA IN-8002

Summary of Contents for Innova XTIRPA IN-8002

  • Page 1 1067mm (42″) PORTABLE MANHOLE GUARD SYSTEM FOR PPE UNIVERSAL RESCUE SYSTEM IN-8002 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8002-(en-us)
  • Page 2 MU8002-(en-us)
  • Page 3 INTRODUCTION WARNING The XTIRPA system is part of a personal protection equipment system for fall protection, work positioning, or rescue, for use in confined spaces. The user must read, understand and follow the manufacturer’s instructions for each com- ponent or part of the complete XTIRPA system. These instructions must be provided to the user of the XTIRPA system.
  • Page 4 and Retrieval Including Secondary Block, conforms to document number MU8002-(en-us). APAVE SUDEUROPE SAS (Headquarters: 8 rue Jean-Jacques Vernazza—Z.A.C. Saumaty- Séon - CS 60193 - 13322 MARSEILLE CEDEX 16) is the notified body involved in the initial production and certification control phase. MU8002-(en-us)
  • Page 5 SYMBOLS Indicates a dangerous situation which, if it not avoided, could lead to death or a dangerous injury. Indicates a dangerous situation which, if it not avoided, could lead to a minor or moderate injury. Indicated the safe working condition. Please read and understand this system’s operating manual before using it.
  • Page 6 Minimum and maximum service temperature. °C °F Maximum working load. Minimum breaking strength (MBS). Required tightening for bolt. Equipment maximum arrest force (MAF). The positioning pins must be installed before use. Minimum breaking strength (MBS) of 22.2 kN (5 000 lbf). n°...
  • Page 7 APPLICATION The XTIRPA system, and its many components and parts (including davit arm and manhole guard), are intended to be used as part of a personal protection equipment system for fall pro- tection, work positioning, personnel handling, materials handling, or rescue, for use in confined spaces.
  • Page 8 RESTRICTIONS a) CAPACITY: The maximum working load for this product is 420 lbs (190 kg). According to (ANSI, OSHA, CSA). According to EC (EN 795 2012), use an EN 360 and/or EN 363 fall protection system or an EN-1496 recovery system. b) The manufacturer attests that anchoring devices have been tested accordingly to the pres- ent European standard and, unless otherwise stipulated, equipment is to be used by only one person using a shock absorber in accordance with regulation EN 355.
  • Page 9 system is intended to be used as per this Instruction and safety manual. For the installation of lifeline cables and ropes on the certified 12kn anchor points of the davit arm, see section 6. IMPORTANT: When used as PPE, the system must be fitted with a device limiting the dynamic forces exerted on the user to a maximum of 6kN (1320 LbF).
  • Page 10 If you have any questions about the use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the Manufacturer PSP INNOVA INC. WARNING: For safety reasons, make sure when using the anti-drop system that you have enough space under the user, so as to avoid injury.
  • Page 11 IMPORTANT: If you have questions about the use, care or suitability of the XTIRPA ystem for your application, please contact the Manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this Instruction and safety manual.
  • Page 12 e) When attaching the EN 361-compliant safety harness with the lifeline cable or rope, it is imperative, in order to avoid the manhole guard toppling over, that the user tie himself to the front of the XTIRPA system. f) Always open the manhole guard to its full capacity before installing davit arm. g) Make sure the lifeline cable or rope is positioned directly over the work area.
  • Page 13 m) It is imperative to supply all information in sufficient quantity to assure that different equip- ment articles are compatible when assembled as system. n) Life expectancy of the XTIRPA system and its components will be determined based on the conclusions of periodic and monthly inspections which will determine whether or not the product may remain in service.
  • Page 14 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the Manufacturer’s Instruction and safety manual. Ensure that the markings are visible at all times. b) Before each use, carefully inspect the XTIRPA system and all components and parts there- of.

  • Page 15: Warranty

    WARRANTY The XTIRPA system, offered by the Manufacturer, Innova Public Utility Products, Inc., is war- ranted against all defects in workmanship and materials for a (2) two-year period from the date of delivery, and this warranty only applies to the XTIRPA system’s initial buyer.
  • Page 16 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA system is part of a personal fall arrest, work positioning, personnel handling, material handling or rescue system for use in confined spaces. The XTIRPA system is intended to act as a support structure or anchor for these uses. The user must read, understand and follow the manufacturer’s instructions for each component or part of the complete XTIRPA system.
  • Page 17 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the Manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label of the XTIRPA system in the maintenance and inspection log of this Instruction and safety manual.
  • Page 18 IMPORTANT: Always open the manhole guard to its full capacity before installing davit arm. A) Remove both handle pins from their locations. B) Install the receptacle of the davit arm on the integrated mast of the manhole guard. A) Lock all with the first handle pin. B) Install the inferior leg of the davit arm between the eyelets of the manhole guard and lock with the second handle pin.
  • Page 19 WARNING: It is strictly prohibited to use the material /positioning winch as a fall arrest, when the winch is positioned on the bottom mounting bracket located under the davit arm. WARNING: Only adaptors and brackets that are approved, certified and recommended by the manufacturer are to be used with the XTIRPA system.
  • Page 20 IMPORTANT: An EN 361-compliant fall protection harness is the only body support device allowed to be used for fall protection. WARNING: The Manufacturer’s Instruction and safety manual must be followed for proper use and maintenance of this product. Alterations or misuse of this product or failure to fol- low instructions may result in serious injury or death, for which the Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses against the Manufacturer derived therefrom.
  • Page 21 THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS MUST BE KEPT CLEAN AND LEGIBLE AT ALL TIMES SERIAL NUMBER LABEL Product serial number Product number Manufacturing date Manufacturing batch number MU8002-(en-us)
  • Page 22 CALCULATION DIAGRAM Anchor point Elastic deformation Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 5’ (1.5 m) Minimum safe distance = 3.3’ (1 m) MU8002-(en-us)
  • Page 23 MU8002-(en-us)
  • Page 24 MU8002-(en-us)
  • Page 25 NOTES MU8002-(en-us)
  • Page 26 NOTES MU8002-(en-us)
  • Page 28 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Granby, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 Xtirpa is a registered trademark of Innova Public Utility Productions Inc. www.xtirpa.com used under license in Canada MU8002-(en-us)_rev04.01...
