Micro Developer Board LEDs
LED
LED1
LED3/SDA
LED2/PWR
LED4/PROXY
®
xDot
Developer Guide for Japan
Description
User-definable LED.
Programming Status.
Power, blue light when the board has power.
LED for the proximity sensor, which is next to it (labeled U14 on the top assembly
diagram).
