  • Page 1 Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.

  • Page 3: Table Of Contents

    Block Diagram ................................20 Schematics .................................. 21 Chapter 5 – Design Considerations......................... 28 Noise Suppression Design ............................28 PC Board Layout Guideline ............................28 Electromagnetic Interference ............................ 28 Electrostatic Discharge Control........................... 29 USB Design ................................. 29 Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 4: Chapter 1 - Developer Kit Introduction

    1 - AU/NZ blade/plug Cables 1 - Micro USB Cable 3 - SMA-U.FL Antenna Cables (attached to developer board) Antennas 1 - 3.3V magnetic GPS Antenna 2 - 700-2600 MHz Antennas Customer Notices Quick Start Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 5 DEVELOPER KIT INTRODUCTION Additional One promotional screwdriver Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 6: Chapter 2 - Board Components

    BOARD COMPONENTS Chapter 2 – Board Components Developer Board Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 7: Developer Board Connectors

    Dragonfly model. (Not available for SocketModems.) QuickConnect Socket (for Dragonfly devices). JP98 Serial Disconnect Header. JP197 J-Link Header. Reset Button. Use to reset the processor of the device attached to the board. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 8: Led Indicators

    Above the SMC-USB connector LED9 Above the SMC-USB connector LED10 Above the SMC-USB connector LED11 Above the SMC-USB connector LED12 Above the SMC-USB connector LED13 Above the SMC-USB connector LED14 Above the SMC-USB connector Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 9: Chapter 3 - Installation And Operation

    To install the SIM card: With the contact side facing down, align the notched edge as shown on the Dragonfly’s SIM holder and slide the SIM card completely into the SIM holder. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 10: Installing A Socketmodem On The Developer Board

    Installing a SocketModem on the Developer Board To install a SocketModem: Remove the screws from the developer board. Align the SocketModem on the developer board as shown. Secure the SocketModem with the screws you removed in Step 1. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 11: Installing A Dragonfly On The Developer Board

    Installing a Dragonfly on the Developer Board To install a Dragonfly: Remove the screws from the developer board. Align the Dragonfly on the developer board as shown. Secure the Dragonfly with the screws you removed in Step 1. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 12: Arduino Shield

    Dragonfly on the developer board before installing the Arduino shield. To use an Arduino Shield with a Dragonfly Disable the developer card’s serial port. Align the Arduino Shield on the developer board as shown. It will overlap the Dragonfly Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 13: Dragonfly Arduino Pins

    D9 (PB13) Ground D8 (PB1) Ground D7 (PA8) D6 (PA1) A0 (PC2) D5 (PA9) A1 (PC0) D4 (PA7) A2 (PC4) D3 (PA0) A3 (PB0) D2 (PB15) A4 (PC1) D1 (PA2) A5 (PC9) D0 (PA3) Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 14 D9 (PB10) Ground D8 (PB0) Ground D7 (PG7) D6 (PA1) A0 (PC2) D5 (PA9) A1 (PC13) D4 (PA7) A2 (PC4) D3 (PA0) A3 (PE6) D2 (PB15) A4 (PA6) D1 (PA2) A5 (PG8) D0 (PA3) Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 15: Mdot Arduino Pins

    INSTALLATION AND OPERATION mDot Arduino Pins Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 16: Installing An Arduino Shield With A Socketmodem

    Move Jumper 3-4 to Jumper 5-6 Move Jumper 7-8 to Jumper 9-10 Mount the MTSMC device on the Arduino shield as shown in the following image. Connect the Arduino Shield to the developer board. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 17: Attaching Power Supply Blades

    Insert the latch on the blade into the notch on the power supply. Slide the lock down and hold it while you press the blade in place. Then, release it. 1 - Latch 2 - Notch 3 - Sliding lock Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 18: Sma To U.fl Cables

    Finger tighten the antenna to the SMA connector. Attach the U.FL connector from the cable to the connector on the device. G = GPS (may not apply to your device) M = Main D = Diversity Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 19: Chapter 4 - Block Diagram And Schematics

    BLOCK DIAGRAM AND SCHEMATICS Chapter 4 – Block Diagram and Schematics Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 20: Block Diagram

    BLOCK DIAGRAM AND SCHEMATICS Block Diagram Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 21: Schematics

    BLOCK DIAGRAM AND SCHEMATICS Schematics Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 22 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 23 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 24 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 25 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 26 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...
  • Page 27 BLOCK DIAGRAM AND SCHEMATICS Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 28: Chapter 5 - Design Considerations

    A commonly used design aid is to place footprints for these components and populate as necessary during performance/EMI testing and certification. Decouple the power cord at the power cord interface with decoupling capacitors. Methods to decouple power lines are similar to decoupling telephone lines. Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide...

  • Page 29: Electrostatic Discharge Control

    Take precautions to avoid exposure to electrostatic discharge during handling. MultiTech uses and recommends that others use anti-static boxes that create a faraday cage (packaging designed to exclude electromagnetic fields). MultiTech recommends that you use our packaging when returning a product and when you ship your products to your customers.
