Chapter 5 – Specifications and Pin Information

MTXDOT Specifications

Category
General
Compatibility
Interfaces
CPU Performance
CPU
Max Clock
Flash Memory
EEPROM
SRAM
Backup Register
Physical Description
Weight
Dimensions
RF Connectors
-UFL Models
-TRC Models
Environment
Operating Temperature
Storage Temperature
Humidity
®
xDot Developer Guide for Japan
Description
LoRaWAN 1.0.4 specifications
Note that pin functions are multiplexed.
Up to 19 digital I/O
Up to 10 analog inputs
2 DAC outputs
I2C
SPI
Wake pin
Reset pin
Full UART
mbed/simple UART (RX & TX only)
mbed programming interface
32 MHz
32 MHz
256 KB, with xDot library 136 KB available; with AT firmware, 56 KB available
8 KB, available 6 KB
32 KB
128 byte, available 88
0.0001 oz. (0.003g)
Refer to Mechanical Drawings for Dimensions.
U.FL
Trace Connection
-40° C to +85° C
-40° C to +85° C
20%-90% RH, non-condensing
SPECIFICATIONS AND PIN INFORMATION
