Japanese Models (Mtxdot-Jp1) - Multitech MultiConnect xDot Developer's Manual

SPECIFICATIONS AND PIN INFORMATION
Category
Power Requirements
Operating Voltage

Japanese Models (MTXDOT-JP1)

Category
Radio Frequency
ISM Bands
Certifications and Compliance
EMC
Radio
Safety
Transmission
Max Transmitter Power Output (TPO) 19 dBm
Maximum Receive Sensitivity
1
Link Budget
Max Effective Isotropic Radiated
Power (EiRP)
Deep Sleep Current
Category
Receive Sensitivity
Spreading Factor
6
7
8
9
10
11
12
1
Greater link budget is possible with higher gain antenna.
2
RFS_L500: RF sensitivity, Long-Range Mode, highest LNA gain, LNA boost, 500 kHz bandwidth using split Rx/Tx
path.
22
Description
2.4 to 3.57 V
Description
AS920-923 MHz ("AS1")
TELEC, Radio/Telecom Biz Act, Giteki
Japan Giteki, Radio/Telecom Biz Act
IEC 60950-1 2nd Ed AM1 & AM2
-130 dBm
147 dB Point-to-Point
145 dB Point-to-Multipoint
36 dBm
< 2 uA
Description
2
-111 dBm
-116 dBm
-119 dBm
-122 dBm
-125 dBm
-127 dBm
-129 dBm
®
xDot Developer Guide for Japan
