SERVICE MANUAL
NF96DV Gas Furnace - Downflow
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, personal injury
or loss of life. Installation and service must be performed
by a licensed professional HVAC installer (or equivalent),
service agency or the gas supplier.
CAUTION
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
WARNING
Electric shock hazard.
Can cause injury or death. Before attempting
to perform any service or maintenance, turn
the electrical power to unit OFF at disconnect
switch(es). Unit may have multiple power
supplies.

Table of Contents

Technical Specifications - NF96DV .............................2
Parts Arrangement.......................................................5
Unit Components .........................................................6
Heating Components .................................................12
Placement and Installation ........................................17
Joint Cementing Procedure .......................................18
Venting Practices .......................................................19
Vent Piping Guidelines ..............................................22
Condensate Piping ....................................................35
Start-Up .....................................................................40
Heating System Service Checks ...............................41
Proper Ground and Voltage .......................................44
Typical Operating Characteristics ..............................45
Maintenance ..............................................................46
Wiring and Sequence of Operation ...........................49
