- Page 1 OWNER’S MANUAL Model 675 100 GALLON SPRAYER Forage Harvester 010-0675 REV 6/22...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE INSTALLATION INSTRUCTIONS FOR JOHN DEERE 6000 SERIES INSTALLATION OF FENDER SUPPORT INSTALLATION OF TANK AND FRAME INSTALLATION OF THE CONTROLS MOUNTING OF THE SPOUT NOZZLE ASSEMBLY INSTALLATION OF CHUTE LUBE BAR CONNECTING THE SPOUT AND CHUTE NOZZLE PLUMBING INSTALLATION INSTRUCTIONS FOR CLAAS JAGUAR SERIES INSTALLATION OF FENDER SUPPORT TANK AND FRAME... -
Page 3: Installation Instructions For John Deere 6000 Series
INSTALLATION INSTRUCTIONS FOR JOHN DEERE 6000 SERIES INSTALLATION OF FENDER SUPPORT FOR 10 AND 50 SERIES ONLY 1. Open the right side access door behind and right wheel and underneath the fender. With this access door open, the C channel can be seen looking inside and up. 2. -
Page 4: Installation Of The Controls
INSTALLATION OF THE CONTROLS 1. Locate the rocker switch provided in the parts box. The switch is to be located in position 8(shown below.) Knock out the panel plug in position 8. Connect the switch to the connector labeled 534. (If the 534 label is not found, look for the connector having a brown wire #231.) Snap the rocker switch into the panel with tank symbol forward and refer to the operator’s manual for the switch operating information. -
Page 5: Installation Of Chute Lube Bar
INSTALLATION OF CHUTE LUBE BAR 1. The spray bar will be located in the transition chute before the blower box, similar to the location shown in the diagram. Six holes will have to be drilled in the feed chute- four 9/16” holes for the spray nozzles and two 3/8”... -
Page 6: Installation Instructions For Claas Jaguar Series
INSTALLATION INSTRUCTIONS FOR CLAAS JAGUAR SERIES INSTALLATION OF FENDER SUPPORT 1. Locate the bolts in sided the panel of the fender (behind tire on the right fender.) 2. Remove the two bolts and slide the support up to them. 3. Tighten the bolts back down. 4. -
Page 7: Controls
CONTROLS 1. Locate the control box on the beam between front and side window. 2. Connect the wires with two quick connects to the pump located on the tank frame. 3. For New Claas choppers (830, 850, 870, 890, and 900, plug power cord into back of control box and the other end into a “T”... -
Page 8: Installation Instructions For New Holland Fx Series
INSTALLATION INSTRUCTIONS FOR NEW HOLLAND FX SERIES TANK AND FRAME INSTALLATION 1. Remove outer handrail on right hand fender of machine. Note that the front part of handrail will remain on machine. 2. Drill a hole in the angle iron bracing on backside of tank. Drill 9/16” hole in bottom leg of angle iron 15-5/8”... -
Page 9: Gauge And Hoses
GAUGE AND HOSES 1. Mount gauge in a location visible from the operator’s seat. 2. Run the hose from the pump to the gauge. 3. Run the hose from the gauge to the nozzle assembly. 4. Place check valve in line between the gauge and the nozzle (arrow pointing to tip). CONTROLS 1. -
Page 10: Box Adjustment
BOX ADJUSTMENT Electronic units control application rate by regulating pump speed. The control box is factory set, but from time to time may require readjustment. First TURN OFF POWER. Second, remove the control box cover. Lastly, turn the power back on and make the following adjustments: 1. -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS The model 675 is compatible with water, bacterial inoculants, enzymes, and organic acid crop preservatives. All of these liquids are similar to water in weight and viscosity, so the charts below will be accurate within 10% for all products used if the system is functioning properly. Always verify application by checking product used against desired application per hour. -
Page 12: Trouble Shooting Checks
TROUBLE SHOOTING CHECKS PROBLEM POSSIBLE CAUSE SOLUTION Pump will not run. 1. Circuit breaker tripped on 1. Check for short, low voltage, and electronic unit. reset breaker. 2. Pump locked up. 2. Clean or rebuild pump if motor is 3. Damaged wire. 3. -
Page 13: Parts Breakdown
675 PARTS BREAKDOWN FOR SADDLE, TANK, PARTS BAG, AND HOSE Ref Description Part # 100 Gallon tank 005-9206 Saddle 001-6701 Tank strap 001-4402 Tank lid 005-9022C Tank lid gasket 005-9022CG Tank fitting 005-9100 Ref Description Part # Ref Description Part # Bolt- ¼”... -
Page 14: For The Gauge And Control Box Assembly
675 PARTS BREAKDOWN OF THE GAUGE AND CONTROL BOX ASSEMBLY Ref Description Part # Pump lead Control box complete 030-0457 Control box u-bracket 001-2012E Circuit breaker 006-2111 Control box knobs 008-0923 Gauge 002-2207Z Straight fitting 003-A1412 Gauge holder bracket 001-6704... -
Page 15: Model 6704 For John Deere 6000 Series
MODEL 6704 FOR JOHN DEERE 6000 SERIES Description Part # Description Part # Fender support 01-6705F Plug 006-6763 Jaco nut 003-JN14 Straight fitting 003-A1414 Jaco straight 003-JA1418 Straight fitting 003-A1412 Nozzle holder 001-6712A Female disconnect 004-1207H Nozzle base 001-6712B Quick connect 004-4710 004-K2-SS 003-TT14... -
Page 16: Model 6705 For Claas Jaguar Series
MODEL 6705 FOR CLAAS JAGUAR SERIES Description Part # Description Part # Fender support 001-6705Z 004-XR11002VS Power lead - modified 006-4580 004-XR11004VS Elbow fitting 003-EL1412 004-XR11008VS Check valve 002-4564F 004-11015-SS Nozzle body 004-4744 Nozzle cap 004-4745 Strap 001-4216 Plug 006-6763 Jumper wire 006-4582 Toggle switch... -
Page 17: Model 6706 For New Holland Fx Series
MODEL 6706 FOR NEW HOLLAND FX SERIES Description Part # Description Part # Tank support 001-6606B 004-5002-SS Lube nozzle holder 001-6501A 004-5004-SS Nozzle cap 004-4745 004-5008-SS Nozzle body 004-4744 004-5015-SS Lube nozzle insert 001-6501B Quick disconnect 004-4710 Tip check 004-4468 Hose clamp 003-9003 Straight fitting... -
Page 18: Notes
OPTIONAL SPOUT NOZZLE ASSEMBLY FOR JOHN DEERE 6000 SERIES Ref. Description Part # Nozzle holder 001-6712A Nozzle base 001-6712B Jaco fitting 003-JA1418 Jaco nut 003-JN14 Hose 002-9006 Washer 004-1207W Female disconnect 004-1207H Straight fitting 003-A1414 Hose clamp 003-9002 004-K1-SS 004-K4-SS 004-K2-SS 1-13 Complete assembly 030-6712... - Page 19 Harvest Tec, LLC. within 30 days of the failure. Parts must be returned through the selling dealer and distributor, transportation charges prepaid.
